- Page 1 IONBEAM GREEN PLANT NIGHT CYCLE WORK LIGHT USER MANUAL...
- Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
- Page 4 MANUAL CODE NEG2308X1 PRODUCT MODEL UPC-A IONBEAM GREEN AC-NEG16 819137024380...
-
Page 5: Table Of Contents
Page 8 Installation ..................Page 9 Controller Mounting ............... Page 14 Starter Guide ................. Page 15 Platform ................Page 16 Connecting to UIS ..............Page 17 Programming ................. Page 18 Other AC Infinity Products ............. Page 19 Warranty ..................Page 20... -
Page 6: Product Warning
PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Ensure your power source conforms to the electrical requirements of this product. Read all instructions before installing and using this product. Be careful not to damage or cut the wire insulation (covering) during the installation. Do not permit wires to come in contact with any sharp edges. -
Page 7: Key Features
KEY FEATURES ENHANCED SPECTRUM GREATER FLEXIBILITY PLANT-GENTLE Supports existing blue Optional diffuser evens light Spectrum maintains dark and red LED grow lights to distribution and increases period integrity by providing effectively improve overall coverage area. Easily detach lighting that will not impact lighting quality. -
Page 8: Product Contents
PRODUCT CONTENTS LIGHT LIGHT MOUNTING LIGHT POWER DIFFUSER CONTROLLER ADAPTER (x1) (x1) (x1) (x1) (x1) BAR EXTENSION UIS EXTENSION WOOD SCREWS HOOK AND LOOP WIRE CORD (M-F) CORD (M-M) (WALL MOUNT) CABLE TIES MOUNT (x2) (x1) (x4) (x2) (x2) -
Page 9: Installation
INSTALLATION LIGHT BAR CHAIN ASSEMBLY STEP 1 Connect the light bar's female port to the light controller's male connector. STEP 2 Connect the light controller to the power adapter. EXTENDING THE CHAIN You may connect the included bar extension cords in between any link in this light bar chain to lengthen it. - Page 10 INSTALLATION LIGHT BAR MOUNTING POLE MOUNTING Magnetically mount your light bar directly on your grow tent steel pole. You may also use the included hook and loop cable ties around your light bar and mounting bar to adjust the lighting angle and for extra security.
- Page 11 INSTALLATION LIGHT BAR MOUNTING STEP 1 — WALL MOUNTING Make sure that your mounting area is free from obstruction. Use a mounting bar to mark your drilling holes with the logo facing the wall. STEP 2 — WALL MOUNTING Drill holes into the marked locations.
- Page 12 INSTALLATION LIGHT BAR MOUNTING STEP 3 — WALL MOUNTING If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes.
- Page 13 INSTALLATION LIGHT BAR MOUNTING STEP 5 — WALL MOUNTING Set the light bar magnet ends onto the mounting bar. POWERING THE LIGHT Plug the power adapter into a wall outlet.
-
Page 14: Controller Mounting
CONTROLLER MOUNTING MAGNET MOUNTING Magnetically mount the light controller onto any steel surface. STEP 1 — WALL MOUNTING Locate a spot free of obstruction and secure the anchor into your wall. Twist the wood screw into the anchors. STEP 2 — WALL MOUNTING Use the mounting hole located on the back of the controller for wall mount. -
Page 15: Starter Guide
STARTER GUIDE GROW LIGHT PLACEMENT Place your light bar at the top of your grow space, shining down to provide even coverage over the entire area. Grow devices like inline fans and grow lights can be placed below the light and will not obstruct the light's reach. -
Page 16: Uis Tm Platform
By creating this fully integrated system, you can power and program all your devices together or separately for optimized grow tent management. Your grow system can be regulated using your controller hub or remotely on the AC Infinity app (paired with compatible controllers), where you will have access to automation programming and climate data. -
Page 17: Connecting To Uis Tm
CONNECTING TO UIS IONBEAM LED grow lights can connect with select smart controllers as part of an integrated system using the included UIS extension cord. CONNECTING TO UIS CONTROLLERS Use the included UIS M-M extension cord to connect your light bar(s) to your selected UIS controller via the light controller's side port. -
Page 18: Programming
PROGRAMMING 1. LIGHTING Pressing the light button will increase the light intensity level in 25% increments (25% - 100%), displayed with white LED indicators. Pressing this button at 100% intensity will cycle to 0%. Holding any button will shut off your light bar and the timer. -
Page 19: Other Ac Infinity Products
AC INFINITY PRODUCTS Pruning Shears Stainless-steel gardening shears designed to effectively trim and fine-tune small plants to support healthy growth. The razor sharp blades are coated in non-stick Titanium to prevent resin-buildup through heavy use, and are controlled via spring-loaded handles specially constructed for maximum comfort. -
Page 20: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues. - Page 21 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
- Page 24 www.acinfinity.com...
