IONGRID SERIES
GROW LIGHT SYSTEM
USER MANUAL
1

Advertisement

Table of Contents
loading

Related Manuals for AC Infinity ONGRID Series

Summary of Contents for AC Infinity ONGRID Series

  • Page 1 IONGRID SERIES GROW LIGHT SYSTEM USER MANUAL...
  • Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
  • Page 4 MANUAL CODE IG2108X2 PRODUCT MODEL UPC-A IONGRID S22 AC-IGS22 819137021921 IONGRID S24 AC-IGS24 819137022157 IONGRID S33 AC-IGS33 819137022119 IONGRID S44 AC-IGS44 819137022171 IONGRID T22 AC-IGT22 819137021914 IONGRID T24 AC-IGT24 819137022164 IONGRID T33 AC-IGT33 819137022126 IONGRID T44 AC-IGT44 819137022188...

  • Page 5: Manual Index

    Product Contents ................Page 7 Installation ..................Page 8 Power and Setup ................Page 10 Adding More Lights ................ Page 12 Starter Guide ................. Page 13 Programming ................. Page 14 Other AC Infinity Products ............. Page 27 Warranty ..................Page 28...

  • Page 6: Key Features

    KEY FEATURES SAMSUNG LED DIODES EVEN COVERAGE SMART CONTROLLER Built with genuine Samsung Unique halo form factor provides Features 0-100% dimming LM301H full spectrum LEDs wider light spread, maximizing and various time-based running at 100W & 2.7 μmol/j usable growing space while programming.

  • Page 7: Product Contents

    PRODUCT CONTENTS IONGRID S-Series GROW CONTROLLER LIGHT (x1) (x1) IONGRID T-Series GROW CONTROLLER LIGHT (x1) (x1) Included in both S-Series and T-Series EXTENSION STAINLESS STEEL ROPE WOOD SCREWS WIRE VELCRO WIRE HANGER CLIP TIE SET TIE SET CORD (WALL MOUNT) (x1) (x1) (x1)

  • Page 8: Installation

    INSTALLATION STEP 1 Clip the lanyard hooks onto the four anchors located at the corners of the grow light. STEP 2 - SINGLE WIRE HANGER Clip the carabiner onto your grow tent's roof support beams. You may also use a rope clip hanger to hang the grow light lower.
  • Page 9 INSTALLATION STEP 3 - SPLIT WIRE HANGER Release two of the hanger's cords from the carabiner and clip them into a separate carabiner (not included). STEP 4 - SPLIT WIRE HANGER Clip the two carabiners onto your grow tent's roof support beams. You may also use rope clip hangers to hang the grow light lower.
  • Page 10 POWERING AND SETUP STEP 1 Plug the LED driver's cable into one of the controller's ports. *Remove rubber cap STEP 2 Plug the power cord into an AC power outlet to power the grow light and controller.
  • Page 11 POWERING AND SETUP RELOCATING THE CONTROLLER STEP 1 Unplug the connector and unscrew the bolts on the underside to remove the controller from the grow light. Connect the extension cord in between the driver's cord and the controller. This extension cord is intended for use with AC Infinity products only.
  • Page 12 The expansion dongle will allow you to connect 2 or 4 more devices and can be daisy-chained to create more expansion ports (up to 64 units supported with the use of 20 dongles). Intended for exclusive use with AC Infinity controllers built with UIS™ ports. *sold separately...

  • Page 13: Height Adjustment

    STARTER GUIDE The charts below offer suggested mounting heights and light intensities for each stage in the growing process of your preferred method. These factors will vary based on the plant you are growing. Height refers to distance from the canopy (tip of the plant). HEIGHT Seedling Vegetative...

  • Page 14: Mode Button

    PROGRAMMING S-SERIES 1. MODE BUTTON 2. UP/DOWN BUTTON Cycles through each of the controller Adjusts the setting of your current modes: OFF, ON, TIMER TO ON, TIMER mode. Holding this button will lock TO OFF, and CYCLE (ON and OFF). the controller;...

  • Page 15: Controller Modes

    PROGRAMMING S-SERIES CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes and settings: OFF, ON, TIMER TO ON, TIMER TO OFF, and CYCLE. OFF MODE Your grow light will not activate while in this mode. The intensity level set here establishes the minimum intensity level in the other modes.
  • Page 16 PROGRAMMING S-SERIES TIMER TO OFF MODE Use the up/down button to set a countdown to trigger OFF mode. The grow light will shine at the intensity level set in ON mode until the countdown ends. If there is a level set in OFF mode greater than 0, the grow light will shine at that level at the The grow light will shine at the end of the countdown.

  • Page 17: Display Setting

    PROGRAMMING S-SERIES DISPLAY SETTING Adjusts the display brightness and auto-dimming. Press the mode and up/down buttons together to cycle through levels 1, 2, 3, A2 and A3; 3 being the highest brightness setting, while 1 is the lowest. In settings 1, 2 and 3, the display will stay at that brightness level and will not automatically dim the display.

  • Page 18: Other Settings

    OTHER SETTINGS S-SERIES FACTORY RESET Holding the mode and up/down buttons together for 5 seconds HOLD + will reset your controller and restore factory settings. This will clear all user set parameters of each controller mode and setting. CONTROLLER LOCK Holding the up/down button will lock the controller in your current mode.
  • Page 19 PROGRAMMING T-SERIES 1. MODE BUTTON 2. SETTING BUTTON 3. UP/DOWN BUTTONS Cycles through the controller modes: Adjusts the setting of your current Cycles through each of the three OFF, ON, TIMER TO ON, TIMER controller settings: DISPLAY, mode. The up button increases and TO OFF, CYCLE (On and Off) and down button decreases the setting.
  • Page 20 PROGRAMMING T-SERIES CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes: OFF, ON, TIMER TO ON, TIMER TO OFF, CYCLE, and SCHEDULE. OFF MODE Your grow light will not activate while in this mode. The intensity level set here establishes the minimum intensity level in the other modes.
  • Page 21 PROGRAMMING T-SERIES TIMER TO OFF MODE Use the up and down buttons to set a countdown to trigger OFF mode. The grow light will shine at the intensity level set in ON mode until the countdown ends. If there is a level set in OFF mode greater than 0, the grow light will shine at that level at the end of the countdown.
  • Page 22 PROGRAMMING T-SERIES SCHEDULE MODE 1, 2 (ON & OFF) Sets an on clock time and an off clock time schedule for the grow light to follow daily. Use the up and down buttons to first set an on clock time to trigger ON mode, then press the mode button to set an off clock time to trigger OFF mode.

  • Page 23: Controller Settings

    PROGRAMMING T-SERIES CONTROLLER SETTINGS Pressing the setting button will cycle through the controller’s available settings: DISPLAY, CLOCK, and TRANSITION. DISPLAY SETTING Adjusts the display brightness and auto-dimming. Press the up or down button to cycle through levels 1, 2, 3, A2 and A3; 3 being the highest brightness setting, while 1 is the lowest.

  • Page 24: Clock Setting

    PROGRAMMING T-SERIES CLOCK SETTING Adjusts the current clock time. Use the up and down buttons to adjust the time. Once you cycle through 12:00 each time, the units will automatically change to AM or PM. The clock time is located at the center of the display.

  • Page 25: Alert Icons

    PROGRAMMING T-SERIES ALERT ICONS The alert icons are displayed at the top of the screen. Icons may flash when the controller signals an alert to tell you a function or alarm is being triggered. TIMER ALERT Flashes when a countdown has completed in the TIMER TO ON, TIMER TO OFF, CYCLE, or SCHEDULE modes.
  • Page 26 OTHER SETTINGS T-SERIES FACTORY RESET Holding the mode, up, and down buttons together for 5 HOLD + seconds will reset the controller and restore factory settings. This will clear all user parameters in each controller mode and setting. CONTROLLER LOCK Holding the setting button will lock the controller in your cur- rent mode.
  • Page 27 150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Inline Duct Fans The CLOUDLINE series is a line of duct fans designed to quietly ventilate AV rooms and closets, as well as various DIY air circulation and exhaust projects.

  • Page 28: Warranty

    WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
  • Page 29 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
  • Page 32 www.acinfinity.com...
