- Page 1 IONFRAME SERIES GROW LIGHT SYSTEM USER MANUAL...
- Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
- Page 4 MANUAL CODE IF2212X1 PRODUCT MODEL UPC-A IONFRAME EVO3 AC-IF3K 819137024045 IONFRAME EVO4 AC-IF4K 819137024052 IONFRAME EVO6 AC-IF6K 819137024069 IONFRAME EVO8 AC-IF8K 819137024076 IONFRAME EVO10 AC-IF10K 819137024083...
-
Page 5: Table Of Contents
Starter Guide ................... Page 19 Page 21 UIS™ Platform ................Page 22 UIS™ Compatibility ................. Page 23 Adding More Lights ................. Page 26 Programming ................... Page 31 Other Settings ................. Page 32 Other AC Infinity Products ............... Page 33 Warranty .................. -
Page 6: Product Warning
PRODUCT WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Ensure your power source conforms to the electrical requirements of this product. Check your local code restrictions for additional safety measures that may be needed for a proper code compliant installation. -
Page 7: Key Features
KEY FEATURES SAMSUNG LED DIODES EVEN COVERAGE REMOVABLE DRIVER Commercial-grade Samsung Algorithmically spaced diodes Detachable LED driver allows LM301H EVO LEDs deliver full- achieve wider light spread for for flexible placement along spectrum lighting to achieve optimized use in all grow stages grow tent walls or positioning greater growth rates. -
Page 8: Product Contents
PRODUCT CONTENTS GROW SCHEDULE DRIVER ROPE LIGHT DRIVER CONTROLLER BRACKETS CLIPS (x1) (x2) (x1) (x1) (x2) UIS M-M UIS M-M DRIVER STAINLESS STEEL WIRE HOOK AND CORD, 10 FT. CORD, 2 FT. EXTENSION CORD WIRE HANGERS TIE SET LOOP TIES (x1) (x1) (x1) -
Page 9: Installation
INSTALLATION DRIVER MOUNTING (FRAME) STEP 1 Align the brackets' mounting holes with the driver's mounting points located on the driver's underside, making sure the brackets' legs are pointing up. Secure the brackets by screwing in the driver screws using a Phillips screwdriver. STEP 2 Flip the driver over and place it over the two center columns of your grow light. - Page 10 INSTALLATION DRIVER MOUNTING (FRAME) STEP 3 Connect the driver socket to the grow light connector. This will lock the connection in place. Twist the lock and pull the connector out to disconnect it from the driver's socket.
- Page 11 INSTALLATION DRIVER MOUNTING (WALL) STEP 1 Align the brackets' mounting holes with the driver's mounting points located on the driver's underside, making sure the brackets' legs are pointing down. Secure the brackets by screwing in the driver screws using a Phillips screwdriver. STEP 2 Mark your desired mounting position using the brackets' mounting slots.
- Page 12 INSTALLATION DRIVER MOUNTING (WALL) STEP 3 Drill four holes into the marked locations. Make sure your mounting area is structurally sound and free from obstruction. STEP 4 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes.
- Page 13 INSTALLATION DRIVER MOUNTING (WALL) STEP 5 Align the bracket’s holes with the wall anchors. Screw in four wood screws with a screwdriver or drill to secure the brackets. STEP 6 Connect the driver socket to the grow light connector using the driver extension cord. Twist the lock and pull the connector to disconnect it from the driver's socket.
- Page 14 INSTALLATION HANGING STEP 1 Clip the lanyard hooks onto the four anchors located at the corners of your grow light. STEP 2 Clip the two carabiners onto your grow tent's roof support beams. You may also use rope clip hangers to hang your grow light lower.
- Page 15 INSTALLATION SUPPLEMENTAL LIGHTING IONBEAM LED light bars (not included) can magnetically mount to the frame to adjust the light spectrum, introduce new spectrums (UV/ IR), and increase the light intensity output. STEP 1 Magnetically mount the LED light bars onto the frame of your grow light.
-
Page 16: Powering And Setup
POWERING AND SETUP STEP 1 Plug the power cord into an AC power outlet to power your grow light. STEP 2 Plug one end of the UIS extension cord into the LED driver, and the other end into the schedule controller. You may alternatively use another UIS controller to set smart programming. -
Page 17: Controller Mounting
CONTROLLER MOUNTING STEP 1 — WALL MOUNTING Locate a spot free of obstruction and secure the anchor into your wall. Twist the wood screw into the anchors. STEP 2 — WALL MOUNTING Hang the controller by the screw using the holes on the backside. - Page 18 CONTROLLER MOUNTING MAGNET MOUNTING Magnetically mount the schedule controller onto the frame of your grow light or a controller mounting plate. PLATE MOUNTING* Screw the controller plate bolts into the slot or mounting holes at the upper half of the plate. Hang the controller by the bolts using the holes on the backside.
-
Page 19: Starter Guide
STARTER GUIDE The chart below lists the coverage area of each grow light size in each growth stage. The supplemental CO column refers to sealed grow spaces that use a CO enrichment system with a 1200+ PPM. AREA Vegetative Flowering Supplemental COVERAGE (FT.) Stage... - Page 20 STARTER GUIDE The chart below offers suggested light intensities for each stage in the growing process of your preferred method when hung at least 1 foot above your plant. These factors will vary based on the plant you are growing. LIGHT Seedling Vegetative...
-
Page 21: Uis™ Platform
By creating this fully integrated system, you can power and program all your devices together or separately for optimized grow tent management. Your grow system can be regulated using your controller hub or remotely on the AC Infinity app (paired with compatible controllers), where you will have access to automation programming and climate data. -
Page 22: Uis™ Compatibility
The expansion splitter will allow you to connect 4 devices with a single port and can support addi- tional splitters to create up to 3 tiers of expansion ports (up to 64 units supported with the use of 20 splitters). Intended for exclusive use with AC Infinity controllers with UIS ports. UIS M - F... -
Page 23: Adding More Lights
ADDING MORE LIGHTS AC Infinity UIS controllers are equipped with multiple ports to add more grow lights and share the same programming. Refer to the diagram below to learn how to connect additional units. Smart grow light controllers can program light intensity levels and scheduled activations of all grow lights plugged into its UIS ports. - Page 24 ADDING MORE LIGHTS USING THE SPLITTER Each controller port can support mix-and- matched devices regardless of their size. When using 4-port splitter, plug your first device into Port 1 for the controller to recognize as the primary device. All other devices plugged into the splitter will follow programming intended for the device plugged into Port 1.
- Page 25 ADDING MORE LIGHTS DAISY-CHAINING Each of the included controller's ports can support up to 16 grow lights using a daisy-chain adapter (not included). All grow lights chained together must be from the same series. Plug the male end of the daisy-chain adapter into your device. Connect your UIS controller to the daisy-chain adapter’s INPUT port using a M-M connector cord.
-
Page 26: Programming
PROGRAMMING 1. MODE BUTTON 2. UP/DOWN BUTTON 3. CURRENT TIME Cycles through each of the Adjusts the setting of Displays the current controller modes: OFF, ON, your current mode. time. The internal battery SCHEDULE, SUNRISE/SET, and sustains the clock so it CLOCK. - Page 27 PROGRAMMING CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes and settings: OFF, ON, SCHEDULE, SUNRISE/SET, and CLOCK. OFF MODE Your grow light will not activate while in this mode. The intensity level set here establishes the minimum intensity level in the SCHEDULE mode.
- Page 28 PROGRAMMING PROGRAMMING SCHEDULE MODE (ON & OFF) Sets an on clock-time and an off clock-time schedule for your grow light to follow daily. Press the up or down button to first set up an on clock-time to turn your grow light on, then press the mode button to set an off clock-time to turn your grow light off.
- Page 29 PROGRAMMING SUNRISE/SET SETTING Sets a sunrise and sunset time for your grow light to brighten and dim, respectively. This setting only applies to SCHEDULE mode. Press the up or down button to set a duration between 0:00 – 6:00 hours for your grow light to brighten and dim.
- Page 30 PROGRAMMING CLOCK MODE Adjusts the current clock time. Use the up and down buttons to adjust the time. Once you cycle through 12:00 each time, the units will automatically change to AM or PM. The clock time is located at the center of the display and the upper right hand corner.
-
Page 31: Other Settings
OTHER SETTINGS FACTORY RESET Holding the mode and up/down buttons together for 5 seconds HOLD + will reset your controller and restore factory settings. This will clear all user set parameters of each controller mode and setting. RESET TO OFF/DEFAULT Holding the up and down buttons together for 2 seconds will HOLD + reset the value of your current mode to its default setting. -
Page 32: Other Ac Infinity Products
150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Inline Duct Fans The CLOUDLINE series is a line of duct fans designed to quietly ventilate AV rooms and closets, as well as various DIY air circulation and exhaust projects. -
Page 33: Warranty
WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues. - Page 34 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc. Samsung is a trademark of SAMSUNG ELECTRONICS CO., LTD.
- Page 36 www.acinfinity.com...
