2-Phase/5-Phase Stepping Motors
PK Series
OPERATING MANUAL
1
Introduction ................................... 2
2
Safety precautions ........................ 3
3
Precautions for use ........................ 5
4
Preparation ..................................... 6
5
Connection ..................................... 8
6
Installation .................................... 10
7
8
Specifications ............................... 13
9
General specifications ................ 14
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.
HM-7471

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PK Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oriental motor PK Series

Summary of Contents for Oriental motor PK Series

  • Page 1: Table Of Contents

    HM-7471 2-Phase/5-Phase Stepping Motors PK Series OPERATING MANUAL Introduction ........2 Safety precautions ......3 Precautions for use ......5 Preparation ........6 Connection ........8 Installation ........10 Inspection and maintenance ..12 Specifications ....... 13 General specifications ....14 10 Regulations and standards ..

  • Page 2: Introduction

    Introduction Introduction Before using the product Only qualified personnel of electrical and mechanical engineering should work with the product. Use the product properly after thoroughly reading the section “2 Safety precautions” on p.3. In addition, be sure to observe the contents described in warning, caution, and note in this manual. The product described in this manual is designed and manufactured to be incorporated in general industrial equipment.

  • Page 3: Safety Precautions

    Safety precautions Safety precautions The precautions described below are intended to ensure the safe and proper use of the product and to prevent the user and other personnel from exposure to the risk of injury. Use the product only after carefully reading and fully understanding these instructions.
  • Page 4 Safety precautions • Do not use the product beyond the specifications. Doing so may result in injury or damage to equipment. • Keep fingers and objects out of the openings in the product. Failure to do so may result in fire or injury. •...

  • Page 5: Precautions For Use

    Precautions for use Precautions for use z When conducting the insulation resistance measurement or the dielectric strength test, be sure to separate the connection between the motor and the driver. Conducting the insulation resistance measurement or the dielectric strength test with the motor and driver connected may result in damage to the product.

  • Page 6: Preparation

    Preparation Preparation Checking the product Verify that the items listed below are included. Report any missing or damaged items to the Oriental Motor sales office from which you purchased the product. • Motor ................1 unit • Connection cable [0.6 m (2 ft.)] ......1 piece* •...
  • Page 7 Preparation „ 5-Phase PK5 6 4 H - A 4: 42 mm (1.65 in.) Motor frame size 6: 60 mm (2.36 in.) 9: 85 mm (3.35 in.) Motor length Blank: Standard type Motor type H: High-speed type A: Single shaft Shape B: Double shaft Motor identification...

  • Page 8: Connection

    Connection Connection Notes when the connection cable is used (connector-coupled type only) „ When inserting the connector Hold the connector body, and insert it straight and securely. Inserting the connector while it is tilted may cause damage to the terminals or a connection failure. „...
  • Page 9 Connection Connection diagram „ Connector-coupled type (PKE24) The pin numbers of the connector and the lead wire colors of the Oriental Motor connection cable are shown in the figures. z 6 Lead wires type z 4 Lead wires type z Pin arrangement The pins No.2 and No.5 are not used.

  • Page 10: Installation

    Installation Installation Installation location The motor is designed and manufactured to be incorporated in equipment. Install it in a well-ventilated location that provides easy access for inspection. The location must also satisfy the following conditions: • Inside an enclosure that is installed indoors (provide vent holes) •...
  • Page 11 Installation Permissible radial load and permissible axial load Make sure that the radial load and axial load applied to the output shaft do not exceed the permissible values shown in the table below. Permissible radial load [N (lb.)] Permissible axial load Model Distance from output shaft end [mm (in.)] [N (lb.)]...

  • Page 12: Inspection And Maintenance

    Inspection and maintenance Inspection and maintenance Inspection It is recommended that periodic inspections are conducted for the items listed below after each operation of the motor. If any abnormality occurs, discontinue use of the product and contact your nearest Oriental Motor sales office. Inspection item •...

  • Page 13: Specifications

    Specifications Specifications Check on the Oriental Motor Website for the product specifications.

  • Page 14: General Specifications

    General specifications General specifications Degree of protection IP20 Ambient −10 to +50 °C [+14 to +122 °F] (non-freezing) temperature Humidity 85 % or less (non-condensing) Operating environment Altitude Up to 1,000 m (3,300 ft.) above sea level Surrounding No corrosive gas or dust. atmosphere No exposure to water or oil.

  • Page 15: 10 Regulations And Standards

    10 Regulations and standards 10-1 RoHS Directive This product does not contain the substances exceeding the restriction values.
  • Page 16 Tel:1800-806-161 4-8-1 Higashiueno, Taito-ku, Tokyo Technical Support Tel:00 800/22 55 66 22 110-8536 Japan Tel:+81-3-6744-0361 Tel:1800-888-881 www.orientalmotor.co.jp/ja Unit 5 Faraday O ce Park, Rankine Road, Basingstoke, Hampshire RG24 8QB UK Tel:1800-120-1995 (For English) Tel:+44-1256347090 1800-121-4149 (For Hindi) Tel:+33-1 47 86 97 50...
