To avoid danger of electric shock, unplug from outlet when not in
use and before cleaning. If the supply cord is damaged, it must be
WARNING :
replaced by the manufactory or it's service agent or a similarity
qualified person in order to avoid a hazard.

CONTROLS AND COMPONENTS

1: Control panel:
a: Power on/off button
e: Timer button
2: Handle & Remote control storage
5: Air outlet
9: Water scale 10: Water tank
ASSEMBLY
Take out the two parts of the base from packing box. Then, align the centers of the two
parts of the base and place them in a crossed form. Rotate one of the two bases to
align its hole site and make it stuck correctly (Fig. 1).
b: Child lock button
f: Oscillation button
6: Air intake
11: Water tank handle
(Fig. 1)
3: Cable hook
7: Back housing
3
c: Cooling button
g: Speed button
4: LED display
8: Water tank latch
12: Base 13: Ice box
