Summary of Contents for Aosom 370-304V80
- Page 1 IN230800374V01_US 370-304V80 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
- Page 2 ① ② ③ Car Body Handlebar Handlebar fixing device A ④ ⑤ ⑥ Handlebar fixing device B Front wheel Front guard ⑦ ⑧ ⑨ Mudguard Shock absorber Screw M4*14 ⑩ Open spanner L- type Hex wrench Z- type Hex wrench Hexagonal screw Front guard sticker Charger...
- Page 3 Phillips Screwdriver (Not Included)
-
Page 4: Product Specifications
Product Specifications: Battery: 12V 10AH*2 Drive Motor: 24V 350W*1 (2750RPM) Suitable age: 8-12 years old Maximum weight: 65kg Car Size: 119*64*76.5cm Speed: 8-16km/h Hours of Use: Using 0.5 hours after Charging 8-12 hours Charger: Input: 100V-240V 50/60Hz Output: 24V 1.0A Fuse: Auto-reset fuse Assembly instruction... - Page 5 2.Front guard and mudguard assembly Attach the front guard ❻ to its correct position on the car body, then fasten it using a 4mm*14mm screw ❾. Apply the sticker ⓮ onto the front guard ❻, as shown in the picture. Insert the mudguard ❼...
- Page 6 Place the front wheel ❹ into the front fork, as shown in the picture. Insert two washers (B) on each side, then secure the front wheel by tightening two nuts (C) using the open spanner ❿. Open spanner 4.Handlebar assembly Position the handlebar fixing device B ❹...
- Page 7 5.Battery connection Using the screwdriver, loosen and remove the screws (g) from the bottom. Open the seat and connect the power by matching the two red plugs. Using the screwdriver, reattach the seat with two screws (g). Screwdriver (Not Included) Screwdriver (Not Included)
- Page 8 6.Chain adjustment method If the chain is too loose: - Using the open spanner ❿, turn the big nuts anticlockwise on both sides to loosen them. - Turn the small nuts clockwise on both sides to tighten them. - Check the chain tension by lightly touching it; it should not be too loose or too tight. - Once adjusted, using the open spanner ❿, turn the big nuts clockwise on both sides to tighten them.
- Page 9 7. Brake adjustment method (1) Adjusting the brake lever: - If there is too much travel on the brake, it requires tightening. - Loosen the white nut (d) on the brake lever by turning it anticlockwise, which tightens the brake. (2) Adjusting the brake disk nut: - If the brake still has excessive travel after the lever adjustment, you should focus on the nut (e) near the brake disk.
- Page 10 FUSE The car has an auto-reset fuse. If the car suddenly stops while driving, it is usually due to a sudden surge in current. This causes the fuse to trip automatically. Turn off the ride-on and do not use for eight seconds, so the fuse can reset. Then, turn on the power again.
- Page 11 Operating(function reference diagram) Twist the throttle to accelerate Brake lever High/low speed switch Light switch Power switch Mp3(optional) Short press: Horn Long press: Open / close Mode acceleration sound Short press : story Long press: Volume Short press : music down Long press: volume up Battery indicator light...
-
Page 12: Maintenance
Charging: - Charge the battery for less than 12 hours – charging for longer can cause permanent damage. - Place the DC plug into the power socket, then put the charger into the plug. Never use the product while charging. - This product can be used for one hour –... -
Page 13: Troubleshooting
- Drive on a flat and even surface. If you have any questions, please contact our customer care center. Our contact details are below: 001-877-644-9366 customerservice@aosom.com Imported by Aosom LLC 27150 SW Kinsman Rd Wilsonville, OR 97070 USA MADE IN CHINA...
