Summary of Contents for Aosom 370-303V80
- Page 1 IN230800373V02_US 370-303V80 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
- Page 2 Car body Seat Front guard Rear axle Front axle Steering axle Steering wheel rod Front wheel Rear wheel ⑩ Wheel cover Steering wheel Charger Hardware package Wrench Manual 1(spare) M8*85 M5*25 M5*50 M4*12...
- Page 3 Screwdriver (Not Included) Needle-nose pliers (Not Included) Wrench ( Included)
-
Page 4: Product Speci Cations
Product Speci cations: Battery: 12V 7AH*2 Drive Motor: 24V 775#*2(25000RPM) Suitable age: 8-12 years old Maximum weight: 70kg Car Size: 115*77*54cm Speed: 6-13km/h Hours of Use: Using 0.66 hours after Charging 8-12 hours Charger: Input: 100V-240V 50/60Hz Output: 24V 1.0A Fuse: Auto-reset fuse Assembly instruction... - Page 6 3. Front axle assembly Attach the front axle xing tubes to the correct position on the frame. Match the holes on the front axle with those on the tubes. Insert the M8*85 screws from the bottom to the top, add the M6 washers and tighten the 6mm nuts using needle-nose pliers and a screwdriver.
- Page 7 5. Steering axle assembly Insert the steering wheel rod into the tube on the car body. Ensure the holes on the tube and steering wheel rod are aligned. Use a M5*25 screw and a M5 nut to secure them together. You can do this using the needle-nose pliers and a screwdriver. Tube M5 Nut Needle-nose pliers...
- Page 8 6. Steering wheel assembly Insert the steering wheel into the steering axle . Insert a nut into the slot on the steering wheel , then secure them with a 5*50 screw using a screwdriver. 5 *50 screw Screwdriver (Not Included) 7.
- Page 9 8. Battery connection the two 4*1 screws and open the rear cover. Match the two red plugs to establish a connection with the battery. Close the rear cover and secure it using two screws and a screwdriver. Rear cover Screwdriver 4 * 1 screw screw...
- Page 10 9. Seat assembly Attach the seat using a screwdriver. Screwdriver (Not Included) M4*12 screws...
