Vertex Standard VX-2100 Series Operating Manual
  1. Manuals
  2. Brands
  3. Vertex Standard Manuals
  4. Two-Way Radio
  5. VX-2100 Series
  6. Operating manual
Vertex Standard VX-2100 Series Operating Manual

Vertex Standard VX-2100 Series Operating Manual

Vertex standard vx-2100 radio-mobile: owners manual
Hide thumbs Also See for VX-2100 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Operating Manual
VX-2100
O
M
PERATING
ANUAL
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong

Advertisement

Table of Contents
loading

Related Manuals for Vertex Standard VX-2100 Series

Summary of Contents for Vertex Standard VX-2100 Series

  • Page 1 VX-2100 PERATING ANUAL VERTEX STANDARD CO., LTD. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K.
  • Page 2 We’re glad you joined the VERTEX STANDARD team. Call on us anytime, because communications is our business. Let us help you get your message across.
  • Page 3 The VX-2100 Series are full-featured FM transceiver designed for flexible mobile and base station business communications in the VHF or UHF Land Mobile bands. These transceiver are designed for reliable business communications in a wide vari- ety of applications with a wide range of operating capability provided by their lead- ing-edge design.

  • Page 4: Front Panel

    Front Panel - All buttons located on the Front Panel are Programmable Function (PF) Buttons, configured according to your network requirements and programmed by your VERTEX STANDARD dealer. The instructions below discribe a typically-con- figured radio. VOL/PWR Knob Turn this control clockwise to turn the radio on and to increase the volume. Turn it counterclockwise into the click-stop to turn the radio off.
  • Page 5 Transceiver Status Indicator The “A” and “B” indicators show current transceiver status, which can be cus- tomized via programming by your VERTEX STANDARD dealer to meet your communications/network requirements. The possible “A” and “B” displays are explained below. TX/BUSY Indicator Indicates transceiver’s Transmit/Receive Status...

  • Page 6: Antenna Socket

    An external loudspeaker may be connected to this 2-contact, 3.5-mm mini-phone jack. : Do not connect either wire of this line to ground, and be certain that the speaker has adequate capability to handle the audio output (12 W) from the radio. VX-2100 S...

  • Page 7: Switching Power On/Off

    If CTCSS or Digital Coded Squelch (DCS) Lockout has been programmed on a channel, the radio can transmit only when there is no carrier being received or when the carrier being received includes the correct CTCSS tone or DCS code. VX-2100 S PERATION OF THE RANSCEIVER...

  • Page 8: Automatic Time-Out Timer

    DVANCED PERATION Programmable Function (PF) Buttons The VX-2100 Series includes six Programmable Function (PF) Buttons. The PF button functions can be customized, via programming by your VERTEX STAN- DARD dealer, to meet your communications/network requirements. Some features may require the purchase and installation of optional internal accessories. The pos- sible PF button programming features are illustrated below, and these functions are explained on the pages to follow.
  • Page 9 CALL 3 Public Address EXT. ACC1 EXT. ACC2 Direct CH#1 Direct CH#2 AF Min Vr Lone Worker HA (Horn Alert) Key Lock : Requires optional unit VX-2100 S DVANCED PERATION PF Button P ---/--- ---/--- ---/--- ---/--- ---/--- ---/--- ---/---...

  • Page 10: Description Of Operating Functions

    Press (or press and hold) the assigned programmable key to select a different chan- nel. CC U /D Press and holding in the assigned programmable key causes the radio to begin step- ping (repeatedly) upward or downward through the channels. DVANCED PERATION C U /D VX-2100 S...
  • Page 11 The scanner will search the two channels; it will pause each time it finds a channel on which someone is speaking. To stop Dual Watch: Press (or press and hold) the assigned programmable key. Operation will revert to the “Dual Watch Start” channel. VX-2100 S DVANCED PERATION...
  • Page 12 Press (or press and hold) the assigned programmable key to set the radio’s transmit- ter to the “Low Power” mode. Press (or press and hold) the key again to return to “High Power” operation when in difficult terrain. VX-2100 S...
  • Page 13 When the Voice Scrambler feature is enabled, press (or press and hold) the assigned programmable key to toggle the voice encryption on and off. The VX-2100 series include an “Emergency” feature which may be useful if you have someone monitoring on the same frequency as your transceiver’s channel.
  • Page 14 Press (or press and hold) the assigned programmable key to turn the Horn Alert function “ON” or “OFF.” If you receive a call from the base station with 2-Tone, 5- Tone or DTMF signaling, horn alert will be activated and your vehicle’s will sound. VX-2100 S...

  • Page 15: Arts (Auto Range Transpond System)

    DVANCED PERATION Press (or press and hold) the assigned programmable key to lock the various aspects of the VX-2100’s keys. The precise lockout configuration must be programmed by your VERTEX STANDARD dealer. ARTS (Auto Range Transpond System) This system is designed to inform you when you and another ARTS-equipped station are within communication range.

  • Page 16: Optional Accessories

    CT-104A Connection Cable for FIF-10A Availability of accessories may vary; some accessories are supplied standard per local requirements, others may be unavailable in some regions. Check with your VERTEX STANDARD Dealer for changes to this list. PTIONAL CCESSORIES ® /GE-STAR ®...
  • Page 17 OTES VX-2100 S...
  • Page 18 OTES VX-2100 S...
  • Page 19 Part 15.21: Changes or modifications to this device not expressly ap- proved by Vertex Standard could void the user’s authorization to oper- ate this device.
  • Page 20 Copyright 2006 Printed in Japan VERTEX STANDARD CO., LTD. All rights reserved. 0603B-AE No portion of this manual may be reproduced without the permission of VERTEX STANDARD CO., LTD.
