- Page 1 Verasys Smart Building Hub (SBH300) Installation Guide LC-SBH300-0, LC-SBH300-0LA, LC-SBHPNL-01, LC-SBH300-0C Building Technologies & Solutions LIT-12014293 www.johnsoncontrols.com 2023-08-24 Johnson Controls...
- Page 2 Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
-
Page 3: Table Of Contents
Connecting to the SBH with the Wi-Fi access point.................11 Configuring the Internet connection with Ethernet................11 Configuring the Internet connection Wi-Fi Client................12 Installing the Airwall Agent for SBH300 access................13 Over the air updates..........................14 Smart Equipment Controller updates....................14 Reset button operation and descriptions..................14 Network reset............................14... - Page 4 Canada..............................24 Product warranty............................25 Patents................................25 Single point of contact...........................25 Contact information............................25 Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
-
Page 5: Applications
USB Wi-Fi adapter. You can mount the SBH300 permanently onto a DIN rail or secure it onto a stable, flat surface. Supply power for the SBH300 is provided through the included AC power supply or an external 24 VAC connected to the terminal block plug. -
Page 6: Din Rail Mounting
On the back of the SBH300, extend the two lower mounting clips. Hang the top of the SBH300 to the DIN rail clip. Then press the SBH300 against the DIN rail and hold in place while pushing up on the lower mounting clips to secure the unit. -
Page 7: Wiring
For data transmission and other specifications, see Technical specifications. System bus communications connections To connect the SBH300 to the system bus for communication, use the System Bus adapter on the SBH. Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls... -
Page 8: Usb Ports
Performance of the SBH300 varies based on the amount of traffic it accommodates. USB ports The SBH300 has two USB 2.0 host (type A) ports and one USB 2.0 client (type micro) port. The USB host ports are dedicated for the Wi-fi USB access point. -
Page 9: Connecting A Tmr Coordinator
Important: If the SBH300 is at the end of an MS/TP bus segment, set the End-of-Line (FC EOL) switch to ON. If the SBH300 is not at the end of an MS/TP bus segment, set the End- of-Line (FC EOL) switch to OFF. If you use a shielded cable, do not connect the shield wire to the SBH300. -
Page 10: Connecting A 24 Vac Power Supply
Connect the power cord to a 100 VAC to 240 VAC outlet. Connecting a third-party 24 VDC power supply Before you begin: To power the SBH300 with a locally sourced 24 VDC power supply, use the following power supply equipment: •... -
Page 11: Operation
Smart Building Hub (SBH300) Quick Start Guide (Part No. A16381V57K) included with the SBH300. Read and accept the SBH300 license agreement. The first time you log on to the SBH300, you must change the admin password, Wi-Fi AP Passphrase, and the Wi-Fi AP SSID. -
Page 12: Configuring The Internet Connection Wi-Fi Client
Default: On Configure If you want or need to use the SBH300 with a static IP address, you must set this field to Off. Obtain the IP Address, Subnet Mask, and Default Gateway from your IT Department and fill out the fields manually. When left to On, these fields populate automatically. -
Page 13: Installing The Airwall Agent For Sbh300 Access
To access the SBH300 local UI over Internet with Ethernet or Wi-Fi client, you must install the Airwall Agent on the device that you want to use to connect to the SBH300. The Airwall Agent is an application that provides access to the SBH300 local UI from anywhere and secures your connection with industry standard Zero Trust Based Security. -
Page 14: Over The Air Updates
Note: The Smart Equipment Controller must be at version 4.3.1.24 or later to use the OTA update feature. Reset button operation and descriptions Use the following reset functions on the SBH300 if you lose your password or if you want to restore the unit to factory defaults: •... -
Page 15: Reset To Factory Defaults
This function is for administrators who want to clear all user profiles from a device. The Reset to Factory Defaults function does not change the version of the software. If you run a software upgrade, the SBH300 retains the upgraded software version and does not reset to the factory default version. -
Page 16: Led Test Sequence At Start-Up
• solid when the SBH300 is fully functional. Status indication LEDs The SBH300 uses status LEDs to indicate functional states according to the LED map shown in the following table: Table 6: SBH300 LED designations and operation LED name Color... -
Page 17: Troubleshooting
Table 6: SBH300 LED designations and operation LED name Color Status Description SYSTEM Green Cable is not connected. Flashes with Data is transferring. activity Wi-Fi AP Green Wi-Fi adapter is not connected. On solid The Wi-Fi adapter is connected and client is connected. - Page 18 Check the BACnet settings page on the SBH300 local UI. Refer to the BACnet MS/TP settings section of the Verasys System User Guide (LIT-12012371) for the details about how and when to change these values. Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
- Page 19 Use a cellular modem based internet provider. Device error. Review the Device Diagnostic Info page on the SBH300 local UI. Refer to the Diagnostics section of the Verasys System User Guide (LIT-12012371) Contact technical support. Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
- Page 20 Check your web browser settings and verify that cookies are enabled. Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
- Page 21 Ensure that you enter the password. correct username and password. You are required to change the Wi-Fi AP SSID, Wi-Fi AP password, and UI password the first time you log on to the SBH. Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
-
Page 22: Accessories
USB Wi-Fi Adapter Repair information If the SBH300 fails to operate within its specifications, replace the unit. For a replacement SBH300, contact the nearest Johnson Controls representative. Do not open the SBH300 housing. The SBH300 has no user-serviceable parts inside. -
Page 23: Ul Standard
Operating Control (Optional If Marked On Product) Construction of control and whether the control Independently mounted is electronic TYPE 1 or TYPE 2 action TYPE 1 External Pollution Situation Pollution Degree 2 Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls... -
Page 24: North American Emissions Compliance
L'exploitation est autorisée aux deux conditions suivantes : 1. L'appareil ne doit pas produire de brouillage, et 2. L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls... - Page 25 NO. 32 CHANGJIANG RD NEW THE NETHERLANDS MANCHESTER DISTRICT M40 2WL WUXI JIANGSU PROVINCE UNITED KINGDOM 214028 CHINA Contact information Contact your local Johnson Controls representative: www.johnsoncontrols.com/locations Contact Johnson Controls: www.johnsoncontrols.com/contact-us Verasys Smart Building Hub (SBH300) Installation Guide Johnson Controls...
- Page 26 © 2023 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice. Johnson Controls...
