COLT 286 SERVICE MANUAL
OPERATION NOTES
u has finished booting and the C> prompt has appeared, you can use the built-in Setup utility to give
eee
information on your COLT 286 configuration. To run the Setup utility, hold down the Control
and Alt keys and simultaneously press the Esc key. The main menu of the Setup utility will appear and will look like this:
Commodore Setup Utility
Hard Disk Type Inforeation
Date
Laie 1
14
Type Cyln Head Sect W-pc L-zone Size
Diskette 2 306 17 128 30
Hard Disk 1
Hard Disk 2
Video
Coprocessor
Base Memory
Extended Merory
Base memory found:
Extended aeaory found:
Use {, | toselect ites
Use ~»,< to select predefined
values
Use <PgDn> to view sore hard disk
types
Press <Esc> to abort SETUP
Press <End> to exit and update
Press Fi for secondary SETUP window
ROVIMAIAATNANABDAMDOHHAD
FIGURE 1. COMMODORE SETUP UTILITY MAIN MENU
As noted on the Setup screen, you can use the cursor keys and the keyboard to define or change the system configura-
tion, as follows:
© Use the up and down cursor keys to move from option to option in the main menu.
© Use the left and right cursor keys to select the predefined entries for each option. .
© Use the keyboard to type in any information that is not predefined.
2-1
