03 Other Aspects
3. Disassemble and Install the Battery Cabin
② Install
1. Rotate the knobs on the both sides of the fuselage 90 ° to the deep slot;
危险废弃物
2. Slowly install the battery cabin along the chute under the fuselage. Press down
hard until you hear a "click" sound, and the knobs close in place;
3. Pull the lower sides of the Pressure Plate by hand, pull down to deform the
Pressure Plate ③, make the buckle fasten on the rear bracket;
4. Press down firmly on the chute of the locking assembly. When you hear a
"click" sound, the buckle is snapped into place properly, then the installation is
complete.
