U95
OPERATING
INSTRUCTIONS
This product supports GPS positioning and is recommended for outdoor flight!
* This wifi camera pinpoint is 5G, please confirm whether the phone is supported.
V1.0
Note
▲This product is suitable for users over 14 years old.
▲Stay away from the rotating propeller
Li-Po Battery Disposal & Recycling
Wasted Lithium-Polymer batteries must not be placed with household
trash. Please contact local environmentalor waste agency or the
supplier of your model or your nearest Li-Po battery recycling center.
Our company's products are improving all the time, design and specifications are
subject to change without notice. All the information in this manual has been
Important
carefully checked to ensure accuracy, if any printing errors, our company reserve
Notice
the final interpretation right.
Advertisement
Table of Contents
Related Manuals for udir/c U95
Summary of Contents for udir/c U95
- Page 1 OPERATING INSTRUCTIONS This product supports GPS positioning and is recommended for outdoor flight! * This wifi camera pinpoint is 5G, please confirm whether the phone is supported. V1.0 Note ▲This product is suitable for users over 14 years old. ▲Stay away from the rotating propeller Li-Po Battery Disposal &...
- Page 2 Drone preparation Front LED Propeller A Propeller B (Blue) Front folding Front folding Obstancle avoidance Power switch switch Rear folding Rear folding Rear LED (Green) Propeller B Propeller A Obstancle avoidance switch Front Camera Front LED (Blue) Optical Fill light flow position switch Battery...
-
Page 3: Drone Battery Charging
Unfolding Instruction ① Folding State ③ ② Front folding arms unfold Rear folding arms unfold Drone battery charging Battery power is low in the original factory, It must be fully charged before use. Connect the batteries of the drone to the charging line of the original plant, and then connect to other USB charging sockets. -
Page 4: Transmitter Preparation
Installation of drone battery Place the battery into the battery compartment along the rear of drone. Disassem: Pull out the battery Press to unlock the lock Transmitter preparation Phone Holder Gimbal Rotary Video Button Photo Indicator light Left stick Right Stick Return Power switch GPS switch... -
Page 5: Transmitter Charging
Transmitter charging Battery power is low in the original factory, It must be fully charged before use. Connect the transmitter with the charging line of the original plant, and then connect other USB charging outlets. When charging, the transmitter indicator flashes circularly, and when charging is completed, the indicator will be on for a long time. -
Page 6: Flight Operations
Flight Operations Mobile phone connect with Drone Download and install APP: RC-Wing This software is suitable for mobile phones in the IOS 9.0 or later and Android 4.4 or later system.For detailed operation, please check the system “HELP” of APP. Transmitter connect with Drone Frequency Pairing Turn on the power. -
Page 7: Compass Calibration
Compass calibration Rotate the drone horizontally until the transmitter sounds "di... "Level correction to complete. When the front navigation light turns to long light and the rear navigation light flashes, enter vertical correction.Rotate the drone vertically until the transmitter sounds "di... "A sound, vertical correction over. - Page 8 GPS Signal Search After the frequency matching is successful, the drone automatically searches for GPS signals. When the blue indicator light of the remote control changes from flashing to long bright, it makes a sound of "di" at the same time, indicating that the GPS connection is successful.
- Page 9 Control stick operation Go up Forward Counter- Clockwise Fly to Fly to clockwise turn the left the right turn Go down Backward Left stick Right stick Return During the flight, press the " " button, and the transmitter will sound "di", and the drone will automatically return to the take-off point.
-
Page 10: Gimbal Adjustment
Speed mode switch Medium speed default Press "H/L" button, the transmitter will sound "di.di.di" to enter high speed mode "H". Press it again, the transmitter will sound "di" to enter low speed mode "L". Press it again, the transmitter will sound "di.di"... -
Page 11: Automatic Return
Fill light switch The fill light is off by default.Press the “ ” button,the transmitter will sound “di” to turn on the fill light,and press again to turn off. Obstancle avoidance switch Obstancle avoidance mode is off by default. Press the “ ”button,the transmitter will sound “di”... -
Page 12: Out Of Range Alarm
Out of range alarm When the drone is out of the remote control distance, the transmitter will continues to sound "didi.didi" to alarm the user to return the drone immediately. Stuck Protection When the propeller is stuck and does not rotate, the drone will start the automatic protection function to stop the motor working. -
Page 13: Parts Replacement
Attention ① Switching sequence. At first, turn on the power of the transmitter, then turn on the power of the drone. After the end, turn off the power of the drone first, and then turn off the power of the transmitter. ②... -
Page 14: Troubleshooting
Troubleshooting Problem Solution The transmitter 1) The battery is low, please charge in time. indicator light is off 2) Please make sure turn on the power. 1) Please refer to the manual to operate again. Unable to 2) Make sure signal interference nearby and keep away. frequency 3) The electronic component is damaged for frequent crash. -
Page 15: Fcc Note
FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 16 WARNING Warning: The product should only be used by adults and children over 14 years. Adult supervision is required for children under 14 years. Hinweis: Dieses Produkt ist für die Erwachsene und die Kinder ab 14 Jahren. Die kinder unter 14 Jahren müssen von Erwachsenen beaufsichtigt werden.
