- Page 1 U89S USER MANUAL ▲This product is suitable for users over 14 years old. ▲Stay away from the rotating propeller ▲Read the <important statement and safety guidelines> carefully.
-
Page 2: Charging Instruction
Ready Before Take Off Drone preparation Front (Prow) A Propeller B Propeller Drone upper Top cover housing A Propeller B Propeller Guards Power Switch Rear (Tail) Camera Front LED(Green) Front LED(Green) Drone bottom housing Rear LED(Red) Rear LED(Red) Drone Battery Charging Instruction Battery power is insufficient in the original plant. -
Page 3: Battery Installation
Battery Installation Battery buckle Install: Put the battery into the battery compartment and push it into position. Remove: Press the battery button and pull the battery back. Transmitter Preparation Phone Holder Jack Return Home / Speed Switching Heading Hold Mode Take Off / Landing Video/Photo / Emergency Stop... -
Page 4: Flight Operations
Mobile Phone Installation ② Pull out upper lamp of the holder and put the phone into the holder, then release the clamp, and the phone will be fixed on the holder. Please make sure that the button on phone is not clamped. ①... -
Page 5: Return Home
Control stick operation Left stick Right stick Go up Forward Backward Go down Counterclockwise Fly to the left turn Fly to the right Clockwise turn Take off After the frequency pairing is successful, press the "take off/land" button, the transmitter will sound "di", and the drone will automatically rises and flies at an altitude of about 1.2 meters. -
Page 6: Heading Hold Mode
Press the "Return Home" button, the transmitter will sound “di”, and the drone will fly back to the users. Pull down the Left Stick slowly to land the drone when the drone fly back and close to the user. The return home function is only available when the drone is in Heading Hold Mode. Make sure the drone is in front of the users. -
Page 7: Speed Switch
Speed Switch Low speed default Press the “Speed Switching” button, the transmitter will sound "didi" to enter the High Speed Mode "H". Press again, the transmitter will sound "di" to enter the Low Speed Mode "L". Low speed: suitable for beginners to practice without wind. High speed: suitable for professional operation in outdoor wind resistance. -
Page 8: Altitude Hold Mode
Flying Trimmer Forward / Backward Trimmer During the flight, if the drone tilts forward, hold down the Hold down left stick in the center button, and push the right stick backwards to adjust. Otherwise push forwards. Left and right side flying trimmer Hold down During the flight, if the drone tilts left, hold down the left stick in the center button, and push the right stick right to... -
Page 9: Parts Replacement
Out of range alarm When the drone is out of the remote control distance, the transmitter will continues to sound “didi...didi...didi” to alarm the user to return the drone immediately. Stuck Protection ① When the propellers get stuck, then activate stuck protection function and the motors stop running. - Page 10 Attention ① Switching sequence. At first, turn on the power of the transmitter, then turn on the power of the drone. After the end, turn off the power of the drone first, and then turn off the power of the transmitter. ②...
-
Page 11: Troubleshooting Guide
Notice to ensure accuracy, if any printing errors, our company reserve the final interpretation right. Manufacturer: SHANTOU CITY CHENGHAI UDIRC TOYS CO., LTD Address: Guangfeng Industrial Zone, Guangyi Street, Chenghai District, Shantou City, Guangdong Province, CN Model: U89S Manufacture time:... -
Page 12: Fcc Note
FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
