U39S / U43 / U43S
QUICK START GUIDE
This product supports GPS positioning and is recommended for outdoor flight!
* This wifi camera pinpoint is 5G, please confirm whether the phone is supported.
▲This product is suitable for users over 14 years old.
▲Stay away from the rotating propeller
▲Please read the guidelines before using them, and
follow all security precautions.
Wasted Lithium-Polymer batteries must not be placed with household
trash. Please contact local environmentalor waste agency or the
supplier of your model or your nearest Li-Po battery recycling center.
Our company's products are improving all the time, design and specifications
Important
are subject to change without notice. All the information in this manual has
been carefully checked to ensure accuracy, if any printing errors, our company
Notice
reserve the final interpretation right.
Note
Li-Po Battery Disposal & Recycling
V1.0
Advertisement
Table of Contents
Related Manuals for udir/c U39S
Summary of Contents for udir/c U39S
- Page 1 U39S / U43 / U43S QUICK START GUIDE This product supports GPS positioning and is recommended for outdoor flight! * This wifi camera pinpoint is 5G, please confirm whether the phone is supported. V1.0 Note ▲This product is suitable for users over 14 years old.
- Page 2 Download the Operation Operation Guide tutorial Drone preparation Front Navigation lights (Red) Front folding arm Propeller A Propeller B Drone Power switch battery Battery indicator Propeller B Propeller A Rear folding arm Navigation lights (Green) Rear Bottom view Camera gimbal Tripod Tripod Navigation lights (Red)
-
Page 3: Drone Battery Charging
Unfolding Instruction Folding State 1) Rear folding arms unfold 2) Front folding arms unfold 3) Open the tripod Drone battery charging Battery power is low in the original factory, It must be fully charged before use. Connect the Drone-battery to charging port with included USB charger cable, and then connect to other USB output port (Output: 5V, ≥2A). - Page 4 Installation of drone battery When the drone's battery put into the battery compartment and the contact is connected, it will sound "ka", that it indication the battery is successfully installed. Insert batteries along the tail. Remove: Press the double unlock and pull out the battery backwards. Install an SD card (Not Include) Insert the SD card into the slot in the drone's body.
-
Page 5: Transmitter Preparation
Transmitter preparation Gimbal Rotary Button Video Photo Phone Holder Right Stick Left stick Speed switch Gimbal back to GPS switch central/down Power switch Return/Pause Transmitter power indicator The GPS indicator is White when using ordinary transmitter ( The GPS indicator is Green when using PA transmitter) Transmitter charging Battery power is low in the original factory, It must be fully charged before use. -
Page 6: Flight Operations
Installation of phone holder and phone Pull up Phone Back of transmitter Bottom support clamp Notice: Upper support clamp Don't clip the buttons on the side of the phone. Top of transmitter Place the phone in the upper and bottom support clamps Between, the clamp will automatically clamp the mobile phone . - Page 7 Transmitter connect with Drone Frequency Pairing 1) Press 2 seconds to turn on the power of the transmitter and the indicator will flash, then enter to wait for frequency pairing. Press 2 seconds to turn off the power. Horizontal Ground 2) Press 2 seconds to turn on the power of the drone and the front navigation will keep bright.
-
Page 8: Compass Calibration
Compass calibration When the compass is affected by geomagnetic interference, it will be notified in APP. Please follow the instructions. Unlocking/locking the motor Push the left and right stick inward to the 45° angle simultaneously. ① On standby drone, motor rotation, drone unlocked. - Page 9 Take off Landing After unlocking the motor, During the flight, the left stick the left stick slowly pushes up slowly pull down , and the drone and the drone slowly rises. slowly lands until landing. Press at once, gimbal turn down; Press again, gimbal back to center Return...
-
Page 10: Gimbal Adjustment
GPS ON /OFF GPS is on by default. Long press, the transmitter will sound "di..." to turn off the GPS. After repeated operation, the transmitter will sound "di" to turn on the GPS. Note: this function is only used when the motor is locked. -
Page 11: Low Battery Alarm
Notes for Filming 1) Photos taken will be saved to mobile picture library and drone SD card; Video can be saved in SD card first. 2) The APP must be authorized to read the phone gallery to view the aerial photos. 3) Turn off the power supply of the drone before taking out the SD card. -
Page 12: Automatic Return
Automatic Return When the battery power of the drone is runnign out, there will be an alarm on the APP interface and the navigation light will change from long bright to flash light. This moment, the drone will automatiocally return to the air above take off point. Out of range alarm When the drone is out of the remote control distance, the transmitter will sound "di-di"... - Page 13 Attention 1) Switching sequence. At first, turn on the power of the transmitter, then turn on the power of the drone. After the end, turn off the power of the drone first, and then turn off the power of the transmitter. 2) Improper operation caused the crash.
- Page 14 FCC Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition with out restriction. WARNING Warning: The product should only be used by adults and children over 14 years. Adult supervision is required for children under 14 years.
