V-400
and
V-450
MICROPHONE
RED (+)
SHIELD
BLACK (-)
GREEN
SHIELDED
WHITE
CABLE
*
V-420
MICROPHONE
WHITE (+)
SHIELD
BLACK (-)
RED
SHIELDED
GREEN
CABLE
*NOTE: V-400/450 and V-420 Microphones are wired differently. See correct diagram above.
VALCOM
V-9939B
MICROPHONE ADAPTER
VALCOM
V-9939B
MICROPHONE ADAPTER
FIGURE 3 – STAND ALONE PAGE SYSTEM
4
V-1094A
INPUT
OUTPUT
-24
+
VP-624B
A/C
+
GND
V-1094A
INPUT
OUTPUT
-24
+
VP-624B
A/C
+
GND
-24
-24
