- Page 1 INSTALLATION GUIDE Electronic Bidet Seat BEYOND TECHNOLOGY Powered by TOTO...
-
Page 2: Precautions Before Installation
Installation Guide Before installation, be sure to read this installation manual and the separate safety precautions sheet. Mount parts properly according to the directions. Precautions before installation ● Turn on the electricity and water supply for the product only after all other installation work is complete. ● Do not damage the connection components on the water supply hose (C-3) ● The water supply pressure range is 0.1MPa <dynamic> - 1.0MPa <static> in Europe and R ussia, and 0.05MPa <dynamic 10L/min or more> - 0.75MPa (static) in China, Asia, Oceania. Use the unit within the said pressure range. ● The temperature of the water supply should be within a range of 0 to 35°C. Make sure the temperature is within this range. ● Working ambient temperature is within the range of 0 to 40°C. Make sure the temperature is within this range. ● If the water shutoff valve (A-6) is supplied with product, be sure to use it. Do not use other water supply hose (C-3) than the one attached to the product. - Page 3 The power plug (C-2) shape, power cord length, voltage, rated power consumption vary depending on the version of the product. Check the appropriate type in the table on the right, and then wire and install the product correctly. Power plug shape Power cord length 0.7m 0.76m 0.7m 220V Voltage 220-240V 840W Rated power consumption 845-855W 840-850W Maximum power consumption Less than 1600W (When the water supply temperature is 0°C) Prepare an outlet position in advance that conforms to the regulations in your country. 300 mm...
-
Page 4: Included Parts
Included Parts China / Asia / Oceania Anti-theft parts for remote control Please ask home owner if they would like the remote control anti-theft kit installed before starting installation. Please leave the anti-theft kit with the owner if it is not installed. -
Page 5: Required Items
Required items Use to prevent damage to the product. Ø = 3mm Ø = 6mm B-10 B-11 China / Asia / Oceania... -
Page 6: Installation Procedure
Installation procedure China / Asia / Oceania... - Page 8 Insert C-1 into A-7 until a click sound is heard. (After C-1 is mounted, make sure that it can not removed even if it is pulled.)
- Page 9 Europe / Russia China / Asia / Oceania...
- Page 10 Remote control mounting 300mm Side wall 250mm 390mm 250mm Rear wall...
- Page 11 Temporarily place the remote control in the position determined in and confirm the signal reception of A-1. Hold down...
- Page 12 Ø = 6mm Ø = 3mm Anchored by magnet.
- Page 13 Anti-theft protection for remote control Ø = 6mm Ø = 6mm Ø = 3mm Ø = 3mm...
-
Page 14: Trial Run
Trial run Open the water shutoff valve (A-6). Hold down Hold down... -
Page 15: Information For The Installer
Measurements 390mm 233mm 134mm 180mm 64mm 220mm 392mm 92° 538mm Information for the installer ● Please explain the features and operation of to the customer ● If the product will not be used for a long time (like when it is installed in an unoccupied, newly constructed building), turn off the breaker on the distribution board or disconnect the power plug. As for “How to dismount the main unit”, please see the separate sheet. - Page 16 VILLEROY&BOCH DEUTSCHLAND Villeroy&Boch AG Unternehmensbereich Bad und Wellness Hauptverwaltung 66693 Mettlach 09-2013 Farbtöne und Abmessungen unterliegen den üblichen Toleranzen. Technische Änderungen und Farbtonanpassungen vorbehalten.
