CS-882 OEM
ALARM UPGRADE FOR FACTORY KEYLESS ENTRY
INSTALLATION & OPERATING INSTRUCTIONS
INTRODUCTION
CONGRATULATIONS on your choice of an Alarm Upgrade System by Crimestopper Security Products Inc.
This booklet contains the information necessary for installing, using, and maintaining this system. If any
questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech Support
number below.
*IMPORTANT INFORMATION:
This system does not improve or affect the range of the factory remote keyless entry transmitters.
This is an ADD-ON system only. The arm/disarm range of this system will be identical to that of the
Factory Keyless System's lock/unlock range.
TECH SUPPORT
Mon-Fri 8:00 AM-4:30 PM Pacific Time
(800) 998-6880
REV. A 8/2002 SW: PG30500030CT1
INSTALLATION PRECAUTIONS & WARNINGS
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR
BAGS, ABS BRAKES, BATTERY, ETC.).
DO NOT ROUTE ANY WIRING THAT MAY BECOME ENTANGLED with brake, and gas pedals, steering
column, or any other moving parts in the vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-882OEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CrimeStopper CS-882OEM

Summary of Contents for CrimeStopper CS-882OEM

  • Page 1 CONGRATULATIONS on your choice of an Alarm Upgrade System by Crimestopper Security Products Inc. This booklet contains the information necessary for installing, using, and maintaining this system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech Support number below.

  • Page 2: Component Mounting

    COMPONENT MOUNTING Control Unit: DO NOT mount or wiring harness where they can become entangled with moving parts such as brake/gas/clutch pedals, or the steering column! The control module should be mounted in a concealed location. Do not mount the control unit in the engine compartment. LED: Mount in a visible location on the dashboard or console.
  • Page 3 ORANGE WIRE: (-) NEGATIVE STARTER DISABLE (Armed output) Ground output when system is armed. This output is used for disabling the starter or to activate other optional devices such as scanner LED’s, window control modules, voice modules etc. For starter kill, cut starter wire and connect between 87A and 30 on a relay.

  • Page 4: Wiring: Mini Plugs

    GREEN WIRE: (-) HOOD/TRUNK TRIGGER Connect this wire to a grounding hood / trunk pin switch or to existing factory hood and trunk pin switches that read ground when open. If no existing switches are available, new pin switches may be installed. Note: DO NOT mount new pin switches in water pathways.

  • Page 5: Current Sensing

    If an intruder opens a door and the interior lights turn on, the CS-882 system will detect a current drain and trigger the alarm without having to connect (hardwire) this system to the interior dome light circuit and hood/trunk pin switches.
  • Page 6 DOOR / LOCK & VALIDATION WIRES (TYPICAL INSTALLATION) VALIDATION WIRES ON (MODE A = DIP SWITCHES 1-3 ON): The Validation wires serve as a secondary input to prevent the system from being armed or disarmed simply by pushing the unlock button on the vehicle.

  • Page 7: Programmable Options

    1. Turn the Ignition ON and press the Override/Program button 7 times within 10 seconds. 2. Turn OFF Ignition. LED will flash slowly once per second as and indicator the system is in programming mode. 3. Within 20 seconds, press the Override/Program button the number of times that corresponds to the feature list below.

  • Page 8: Operation

    EMERGENCY OVERRIDE/DISARM If the CS-882 system is armed and you have lost your Factory Keyless Remote or it stops working, you will have to perform an emergency override. Enter your vehicle manually with the key, (this will trip the alarm) turn the Ignition ON, and press override/program button 5 times within 8 seconds to disarm the system.
  • Page 9 FACTORY TRUNK RELEASE SENSING If the CS-882 system is installed in a vehicle with trunk pop or hatch release button on the Factory Remote, there is a special input wire that will prevent the system from triggering if the trunk button on your remote is...

  • Page 10: Wiring Diagram

    +12V PARKING LIGHT OUTPUT #2 CIRCUITS. ORANGE (-) ARMED OUTPUT IGNITION ON & (STARTER DISABLE) CRANKING VOLTAGE STARTER WIRE STARTER WIRING DIAGRAM CS-882 YELLOW/BLACK LED: RED PLUG VALET: WHITE PLUG VALET/ PROGRAM BUTTON STATUS LED PINK ON-BOARD IMMOBILIZER #2 PINK/WHITE...
