Chapter 1: Product Introduction
Fieldbus: (protocol interface optional)
Protocol Connector
PROFINET Master
EtherNet/IP Master Dual RJ-45
EtherCAT Master
PROFIBUS Master DB9
DeviceNet Master 5-pin Phoenix Contact Terminal
Audio
AC97 codec: Realtek ALC886-GR
Audio interface: Line-out/Line-in/Mic-in audio Jack
Ethernet
LAN chip: dual Intel ® 82574L Gigabit LAN
Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible
Mechanical & Environment
Color: Pantone 425C\RAL 70 24 front bezel
IP protection: IP66 front
Mounting: panel/wall/stand/VESA 100mm x 100mm
System with panel mounting kit w/ o panel mounting hole
Power input: 12V~30V DC
Power adapter: optional AC to DC power adaptor (+12V, 60W)
Vibration:
– IEC 68 2-64 (w/ HDD)
– 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating)
– 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating)
– 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
Copyright © 2015 EXOR International S.p.A. All Rights Reserved.
DOWNLOADED FROM WWW.SCATTS.CO.UK
Shock:
– IEC 68 2-27
– HDD: 20G@wall mount, half sine, 11ms
Operating temperature: -10°C to 60°C
Storage temperature: -20°C to 75°C
Operating humidity: 10%~90% relative humidity, non-condensing
Dimension: 417.8mm x 312.8mm x 63.75mm
Weight: 6.4kg
Certifications
CE (including EN61000-6-1/EN61000-6-2/EN61000-6-3/EN61000-6-4)
3
