Exor eTOP-IPC 1632P Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EXOR International
Industrial Computing Solutions
Industrial Panel PC
eTOP-IPC 1632P/2132P Series
User Manual
DOWNLOADED FROM WWW.SCATTS.CO.UK
DOWNLOADED FROM WWW.SCATTS.CO.UK
www.exorint.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eTOP-IPC 1632P Series and is the answer not in the manual?

Questions and answers

Related Manuals for Exor eTOP-IPC 1632P Series

Summary of Contents for Exor eTOP-IPC 1632P Series

  • Page 1 DOWNLOADED FROM WWW.SCATTS.CO.UK EXOR International Industrial Computing Solutions Industrial Panel PC eTOP-IPC 1632P/2132P Series User Manual www.exorint.net DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 2: Table Of Contents

    Rear Top ....................7 Dual USB 2.0 Ports .................21 Rear Bottom ..................8 COM1 Port: Serial Port RS232/422/485 ..........22 Rear ....................9 COM2 Port: Serial Port RS232/422/485 ..........22 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 3 Installing a Mini PCIe Module ..............48 Installing the Half-Size Mini PCIe Module ..........50 Installing a Fieldbus Mini PCIe Module ..........51 Installing a Bluetooth Module ...............57 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 4: Preface

    Declaration of Conformity in any form or by any means without the prior written consent from EXOR International S.p.A. The product(s) described in this manual complies with all applicable Disclaimer European Union (CE) directives if it has a CE marking.

  • Page 5: Rohs Compliance

    (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, EXOR has established an engineering and manufacturing task force to implement the introduction of green products.

  • Page 6: Warranty And Rma

    This warranty covers all the products/shipments except for: b. It had been altered by persons other than an authorized EXOR service person or, which have been subjected to misuse, abuse, accident, or 1. Any claimed defect, products that have been repaired or modified by improper installation.
  • Page 7 RMA that EXOR has determined not to be covered by the warranty will Product Repairing be charged the EXOR Standard Repair Fee for the repairing. If a RMA is 1. EXOR will repair defective products covered under this limited warranty determined to be not repairable, customer will be notified and product(s) that are returned to EXOR;...
  • Page 8 Basic Labor Cost and Testing Fee. b. Parts Fee: EXOR will charge for main IC chipsets such as the N.B., S.B., Super-IO, LAN, Sound, Memory, and so on. c. 3rd-party Device Fee: products replacement for CPU, DIMM, HDD, Chassis, and UPS.

  • Page 9: Safety Information

    There is a danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 10: Safety Precautions

    RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. 10. All cautions and warnings on the equipment should be noted. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 11: Technical Support And Assistance

    DOWNLOADED FROM WWW.SCATTS.CO.UK Preface Technical Support and Assistance Conventions Used in this Manual 1. For the most updated information of EXOR products, visit EXOR’s website Warning: at www.exorint.net. Information about certain situations, which if not observed, can cause personal injury. This will prevent injury to yourself 2.

  • Page 12: Package Contents

    Please contact your local distributor for more information. Terminal block Driver CD 3-pin Phoenix Flat Head Screw Contact Plug Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 13: Ordering Information

    GHz, touch screen, 4GB DDR3, 2 x RS232/422/485 and 4 x 4 DI/O with • PROFIBUS Master Interface Module isolated protection, brightness adjustment buttons, optional fieldbus module options • DeviceNet Master Interface Module xiii Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 14: Chapter 1: Product Introduction

    IP66 compliant front panel Support fieldbus module, JMobile HMI, Citect SCADA and CODESYS (optional) Mounting support: panel/wall/stand/VESA 100mm x 100mm Wide range power input 12V~ 30V DC Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 15: Specifications

    – 1x hard drive bay: optional 1x 2.5” SATA HDD or 1x SATA DOM COM #1: RS232/422/485 w/ 2.5kv isolated COM #2: RS232/422/485 w/ 2.5kv isolated Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 16 – 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating) – 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating) – 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 17: Etop-Ipc 2132P

    IP66 compliant front panel Support fieldbus module, JMobile HMI, Citect SCADA and CODESYS (optional) Mounting Support: panel/wall/stand/VESA 100mm x 100mm Wide range power input 12V~ 30V DC Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 18: Specifications

    – 1x hard drive bay: optional 1x 2.5” SATA HDD or 1x SATA DOM COM #1: RS232/422/485 w/ 2.5kv isolated COM #2: RS232/422/485 w/ 2.5kv isolated Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 19 – 1Grms @ sine, 5~500Hz, 1hr/axis (HDD operating) – 2Grms @ sine, 5~500Hz, 1hr/axis (CFast operating) – 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 20: Knowing Your Etop-Ipc Series

    Press to turn-on or turn-off the display Increase Brightness Press to increase brightness of the screen. Decrease Brightness CFast Increase brightness Press to decrease brightness of the screen. Power switch Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 21: Rear Bottom

    Used to connect an analog VGA monitor. 12V-30V DC Input COM 1 Reset 12V-30V Used to plug a DC power cord. DC Input LAN 1 LAN 2 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 22: Rear

    – Sink current: 200 mA max. per channel VESA Mounting Holes These are mounting holes for VESA mount (100x100mm). VESA Mounting Hole VESA Mounting Hole Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 23: Mechanical Dimensions

    DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 1: Product Introduction Mechanical Dimensions ETOP-IPC 1632P 63.75 417.4 (OUTLINE) CUT OUT 345.89 (V/A) 22.21 26.75 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 24: Etop-Ipc 2132P

    DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 1: Product Introduction ETOP-IPC 2132P 62.85 562.4 (OUTLINE) 478.64 (A/V) 22.21 25.85 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 25: Chapter 2: Jumpers And Connectors

    Use correct screws and do not a metal object. Static electricity can damage many of the electronic over tighten screws. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 26: Jumper Settings

    (on) and open (off). Two-Pin Jumpers: Open (Left) and Short (Right) Three-Pin Jumpers: Pins 1 and 2 are Short Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 27: Locations Of The Jumpers And Connectors

    DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors Top View CN14 CN17 VGA1 LAN1 LAN2 USB1 USB2 CN15 CN16 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 28: Bottom View

    DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 2: Jumpers and Connectors Bottom View DIMM1 DIMM2 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 29: Jumpers And Dip Switch Settings

    Clear BIOS 2-3 On ATX Mode 1-2 On: default 2-3 On: default Definition Definition AUTO (AT MODE) RTC Power PWRBT In Manual (ATX MODE) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 30: Dimming Type Select

    Connector location: JP6 SW2-1 SW2-2 Settings Settings PWM Mode 1-2 On 3.3V Analog Mode 2-3 On Default: PWM Definition VCC3 Power for Dimming VCC5 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 31: Panel Resolution Select

    SW1-1 SW1-2 SW1-3 SW1-4 Resolution/Color/Backlight On Model 1920 x 1080/8 bits/High ETOP-IPC 2132P 1366 x 768/8 bits/High ETOP-IPC 1632P Default set to ETOP-IPC 2132P Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 32: Lcd Panel Vdd Power Select

    Connector type: 1x3 3-pin header, 2.54mm pitch Connector location: JP5 Settings 1-2 On 3.3V 2-3 On 1-2 On: default Definition VCC3 Power for VDD VCC5 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 33: Connector Pin Definitions

    1G network link Steady Orange 100Mbps network link 10Mbps or no link Definition Definition Definition Definition LOUT_R LAN1M0+ LAN1M0- LOUT_L LAN1M1+ LAN1M2+ LAN1M2- LAN1M1- LAN1M3+ LAN1M3- Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 34: Lan2 Port

    Definition LAN2M0+ LAN2M0- VCC5 USB0- LAN2M1+ LAN2M2+ USB0+ LAN2M2- LAN2M1- VCC5 USB1- LAN2M3+ LAN2M3- USB1+ USB2 Definition Definition VCC5 USB2- USB2+ VCC5 USB3- USB3+ Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 35: Com1 Port: Serial Port Rs232/422/485

    COM2_RI (Could be COM2_CTS- (Could Reserve (Could be a COM1_RI COM1_CTS- +5V Power Pin) a +12V Power Pin) be a +12V Power Pin) +12V Power Pin) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 36: Reset Button

    Connector location: SW3 Connector type: DB-15 port, 15-pin D-Sub Connector location: VGA1 Definition Definition Definition SYSRST Green SYSRST Blue DDC Data HSYNC VSYNC DDC Clock Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 37: 12V - 30V Dc Power Input

    DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 2: Jumpers and Connectors 12V - 30V DC Power Input Connector type: Phoenix Contact 1x3 3-pin terminal block Connector location: CN17 Definition Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 38: Internal Connectors

    LVDS_DAT0+(Odd) LVDS_DAT4+(Even) LVDS_DAT3+(Odd) LVDS_DAT0-(Odd) LVDS_DAT7+(Even) LVDS_DAT4-(Even) LVDS_DAT3-(Odd) LVDS_DAT7-(Even) LVDS_DAT1+(Odd) LVDS_DAT5+(Even) LVDS_CLK1+(Odd) LVDS_DAT1-(Odd) LVDS_CLK2+(Even) LVDS_DAT5-(Even) LVDS_CLK1-(Odd) LVDS_CLK2-(Even) +12V +12V LVDS_DAT2+(Odd) +12V LVDS_DAT6+(Even) +12V LVDS_DAT2-(Odd) LVDS_DAT6-(Even) Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 39: Panel Backlight Connector

    Connector type: 1x6 6-pin header JST, 2.5mm pitch Connector location: J7 Connector location: J8 Definition Definition Definition Definition VCC5 HUBUSB DM1- BKCTRL HUBUSB DP1+ HUBUSB DM2- HUBUSB DP2+ BKLEN Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 40: Bluetooth Connector

    Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180) Connector location: J6 Connector location: CN3 Definition Definition Definition Definition HUBUSB_DP3+ TX0+ HUBUSB_DM3- TX0- RX0- RX0+ 3.3V Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 41: Sata Dom Power Connector

    Connector type: 1x2 2-pin header, JST 2.5mm pitch Connector type: 1x5 5-pin header JST, 2.0mm pitch Connector location: J2 Connector location: J10 Definition Definition Definition HDD_GND HDD_PWR PWR_GND 5VSB VCC5 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 42: Dio Connector

    DI1~DI4: Isolated digital input pins DO1~DO4: Isolated digital output pins COM: Common pin for connecting inductive loads of isolated output channels DO1~DO4 GND: Isolated ground Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 43: Backlight Control Input Connector

    Connector location: J5 Connector location: J4 Definition Definition Definition Definition Tact Switch input Decreased input PIR IN VCC3 Increased input Light sensor input VCC3 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 44: Sim Card Slot

    Connector location: CN8 Connector type: 1x2 2-pin header, JST 2.0 mm pitch Connector location: J11 Definition Definition Definition UIM_PWR PWRBT UIM_RST UIM_VCCP UIM_CLK UIM_DAT Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 45: Mini-Pcie Slot

    SMB_CLK +1.5V_MINI PCIE_TX3- SMB_DAT PCIE_CLKREQ SIM_PWR PCIE_TX3+ SIM_DAT USB6- GPP_CLK1- SIM_CLK USB6+ GPP_CLK1+ SIM_RST +3.3V_MINI SIM_VCCP +3.3V_MINI MINICARD1_DIS# PCIE_RST# +1.5V_MINI PCIE_RX2- +3.3V_MINI PCIE_RX2+ +3.3V_MINI Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 46: Mini-Pcie Slot

    Definition Definition Definition WAKE0# +3.3V_MINI +1.5V_MINI SMB_CLK +1.5V_MINI PCIE_TX3- SMB_DAT PCIE_TX3+ USB6- GPP_CLK1- USB6+ GPP_CLK1+ +3.3V_MINI +3.3V_MINI MINICARD1_DIS# PCIE_RST# +1.5V_MINI PCIE_RX2- +3.3V_MINI PCIE_RX2+ +3.3V_MINI Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 47: Cfast Card Slot

    Connector location: J13 PC17 Definition Definition SATA_TX1+ SATA_TX1- CFAST_LED1_C CFAST_LED2_C SATA_RX1- PC10 SATA_RX1+ PC11 PC12 CFAST_CDI PC13 VCC3 PC14 VCC3 PC15 PC16 PC17 CFAST_CDO Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 48: Block Diagram

    Audio Codec COM1 RS-232/422/485 ALC886 80 port Super I/O Line-in ITE8783 COM2 RS-232/422/485 HEADPHONE TPS6047A4RHBR Thermal Sensor *2 SPEAKER PS2 KB/MS Voltages *4 FAN *1 Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 49: Chapter 3: System Setup

    UTIO UTIO ION! ION! ION! electric shock or system damage. 1. Remove the mounting screws around the chassis cover and then remove the cover. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 50 2. Remove the mounting screws of the drive bay. 3. Remove the drive bay. The drive bay is used to hold a SATA hard drive. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 51 SATA drive Mounting screw Drive bay Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 52 Connect the SATA data cable and SATA power cable to the connectors on the SATA drive. SATA data cable SATA power cable Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 53: Installing A Cfast Card

    1. The CFast card socket is located on the rear top side of the chassis. 2. Remove the mounting screws on the cover of the CFast socket. CFast card socket Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 54 3. With the label of the CFast card facing up, insert the card until it is 4. Push the CFast card to remove it. completely seated in the socket. CFast card Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 55: Installing A So-Dimm Memory Module

    DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 3: System Setup Installing a SO-DIMM Memory Module 1. Remove the mounting screws around the chassis cover and then remove the cover. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 56 3. Gently lift the motherboard support plate upwards and locate the 2. Remove the mounting screws on the metal support plate. SO-DIMM socket underneath. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 57 5. Push the module down until the clips on both sides of the socket lock into position. You will hear a distinctive “click” sound, indicating the module is correctly locked into position. SODIMM SODIMM socket Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 58: Installing A Sata Dom (Half-Size Only)

    2. The SATA DOM package includes a supporting stud. The stud is used to stabilize the SATA DOM module. Supporting stud Cable SATA DOM Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 59 3. Install the supporting stud. Make sure the stud is fastened in place. 4. Connect one end of the provided cable to the connector on the module. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual...
  • Page 60 6. Connect the other end of the provided cable to the connector on the of the module and then secure the module using the mounting screw main board. you removed in step 1. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 61: Installing A Mini Pcie Module

    The Mini PCIe module package includes the following items: RALINK 802.11b/g/n 2T3R wireless mini card module kit QCOM:Q802XKN Mini PCIe Module 802.11b/g QN-MU-A0028 wireless mini card module kit INTEL112.BNHMWG Antennas RF Cables Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 62 1. Align the mounting holes on the Wi-Fi mini card module to the mounting holes on the Wi-Fi module bracket. Mounting holes Wi-Fi module bracket Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 63: Installing The Half-Size Mini Pcie Module

    2. Secure the module with mounting screws. angle until the gold-plated connector on the edge of the module completely disappears inside the slot. Mini PCIe slot Mini PCIe module Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 64: Installing A Fieldbus Mini Pcie Module

    Dual RJ45 EtherNet/IP EtherCAT DB9 PROFIBUS 5-pin DeviceNet Connector Universal PROFIBUS I/O Bracket Universal DeviceNet I/O Bracket Universal PROFINET, EtherNet/IP and EtherCAT I/O Bracket Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 65 1. Remove the mounting screws around the chassis cover and then remove 2. Remove the Fieldbus I/O cover. the cover. 3. Secure the FBI I/O bracket. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 66 4. Plug the FBI cable to the I/O connector board and run the cable through the hole of the bracket. DB9 Connector Board 5-pin Connector Board Dual RJ45 Connector Board Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 67 DOWNLOADED FROM WWW.SCATTS.CO.UK Chapter 3: System Setup 5. Secure the FBI I/O board. 6. Secure the FBI housing. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 68 7. Insert the Mini PCIe module into the Mini PCIe slot at a 45 degrees 8. Secure the module with mounting screws. angle until the gold-plated connector on the edge of the module completely disappears inside the slot. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 69 9. Plug the FBI cable to the FBI Mini PCIe card. 10. Stick the FBI protocol label onto the front cover of the connector board. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 70: Installing A Bluetooth Module

    The Bluetooth module package includes the following items: Bluetooth module QCOMQBTM400-01(V7) Square rubber pad Module’s backside 2. Connect the cable to the connector on the Bluetooth module. Cable Connector Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 71 3. Remove the mounting screws of the drive bay. 4. Remove the drive bay and locate the Bluetooth connector and mounting hole on the mainboard. Bluetooth connector Mounting hole Mounting screw Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 72 Once the module is secured, connect the cable to the Bluetooth connector. Bluetooth Sticker connector Mounting hole Module’s backside Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 73 9. Mount the other end of the cable to the Bluetooth mounting hole located at the rear top panel of the chassis. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 74: Panel Mounting

    12mm. If the distance between the front bezel and panel mount hole is too wide, it will not fit the panel mount kit. 12mm 12mm ETOP-IPC 1632P ETOP-IPC 2132P Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 75 Panel Do not overtighten the screws to prevent damaging the CAUTION! CAUTION! CAUT CAUT CAUT CAUT CAUTION! UTIO UTION! UTIO UTIO ION! Panel PC. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 76: Chapter 4: Bios Setup

    RAM has lost power, or the system features need to be changed. Video display type and display options Password protection from unauthorized use Power management features Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 77: Default Configuration

    Setup. Load optimized default values. Press the key to enter Setup: Saves and exits the Setup program. Press <Enter> to enter the highlighted sub-menu Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 78 When “ ” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 79: Bios Setup Utility

    +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 80 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59. Access Level Displays the access level of the current user in the BIOS. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 81: Advanced

    +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 82 OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3). Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 83 F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. SATA Controller(s) Enables or disables SATA controller. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 84 If a PS/2 keyboard is not available and you need to use a USB keyboard to install Windows (installation is performed in DOS mode) or run any program under DOS, set this field to Enabled. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 85 Onboard Serial Port 0 Mode This field is used to configure the mode of serial port 0 as RS232, RS422, RS485 or RS485 AUTO. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 86 Onboard Serial Port 1 Mode This field is used to configure the mode of serial port 1 as RS232, RS422, RS485 or RS485 AUTO. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 87 Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Serial Port Enables or disables the serial port. Change Settings Selects an optimal setting for the Super IO device. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 88 Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Serial Port Enables or disables the serial port. Change Settings Selects an optimal setting for the Super IO device. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 89 F4: Save & Exit ESC: Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 90: Chipset

    Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Setting incorrect field values may cause the system to malfunction. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 91 Backlight Control Select The available options are Pyroelectric sensor and Tact Switch. Backlight On/ Off button is functional only in the Tact Switch mode. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 92 SMBus Controller This section is used to disable or enable SMBus controller. High Precision Timer This section is used to configure High Precision Event Timer. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 93: Boot

    NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 94 +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 95: Security

    To exit the Setup utility without saving the changes, select this field then press <Enter>. You may be prompted to confirm again before exiting. You can also press <ESC> to exit without saving the changes. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 96 Restore User Defaults To restore the BIOS to user default settings, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...

  • Page 97: Appendix A: Power Consumption

    3. Measure the power consumption and record it. Total 11.1W 4. Run Burn-in test program and apply 100% full loading. 5. Before and after testing, test the system insulation. Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 98 Standby mode 0.8A Total 9.6W Full-loading mode 1.4A Total 33.6W Standby mode 0.44A Total 10.56W Full-loading mode 1.15A Total 34.5W Standby mode 0.37A Total 11.1W Copyright © 2015 EXOR International S.p.A. All Rights Reserved. eTOP-IPC 1632P/2132P User Manual DOWNLOADED FROM WWW.SCATTS.CO.UK...
  • Page 99 At Scattergood & Johnson Ltd, we pride ourselves on being a technical distributor to specialist industries. Working with a range of quality product suppliers across a number of specialist markets, we are not your average ‘box shifter’ - we are your technical and supply chain partner. We fully support every product we sell - for free! Our internal team and external sales engineers can answer any product or application question, no matter the complexity.
