- Page 1 PT-PR01G-10 10G PoE Surge Protector Quick Installation Guide www.p rocetpoe.com...
- Page 2 Declaration This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 Overview The installation Guide for PT-PR01G-10 and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product.
-
Page 4: Table Of Contents
able of Contents 1. Introduction 1.1 Introduction...............01 1.2 Appearance...............01 1.3 Specification..............03 2. Installation Preparation 2.1 Package Contents............04 2.2 Installation Toolkits............04 2.3 Inspection................04 3. Installation 3.1 Mounting Installation............. 06 3.2 Inspection................08 Table of Contents... -
Page 5: Introduction
1. I ntroduction 1.1 Introduction PT-PR01G-10 is a single-port Ethernet surge protector. Enclosed in an Aluminum Alloy shell, with a silver color exterior, complemented by an anodized aluminum surface. Enhanced RJ45 socket exhibits minimal signal attenuation. High-quality Gas discharge tube(GDT). Withstand extreme environmental conditions within a temperature range of -40 to 85 degrees Celsius. - Page 6 Side View 1-2 Side View Front View PoE Input Or PoE Output GND Terminal Front View Introduction...
-
Page 7: Specification
1.3 Specification Items Description Input Voltage 60Vdc (Max) Max Discharge Current 10KA(8/20us,1.25KA per line) Maximum Operating Current 1A for 2 pairs, 2A for 4 pairs 120W Maximum Operating Power Protected Line: 1,2,3,4,5,6,7,8 PoE Surge Protection Common Mode Protection Level(10/700us): 10KV Differential Mode Protection Level(10/700us): 1.5KV Data Speed 10/100/1000Mbps, 2.5/5/10Gbps... -
Page 8: Installation Preparation
2.3 Inspection Connect the PT-PR01G-10 with the protected device, and check if the terminal device work normally. Cautions： This device protects Ethernet Equipment with RJ45 port against surge lightning damage. - Page 9 Switch PT-PR01G-10 PT-PR01G-10 GND Terminal GND Terminal Device Connection Caution： We recommend to use Cat5 or higher UTP/STP cables for 100Base-TX Ethernet； We recommend to use Cat5e or above UTP/STP cables for 1000Base-T Ethernet. We recommend to use Cat6 or above UTP/STP cables for 2.5/5/10Gbps Ethernet.
-
Page 10: Installation
3. Installation This product is safe to use wall-mounted installation. 3.1 Wall mounting If it is placed in an outdoor environment, please install the device in a waterproof case with a height of 45cm if possible. 3.1.1Fix the product with screws and tighten them into the screw holes. - Page 11 Backplate Cables Fixing screws Backplate Screws Grounding Cables Lug wires Installation in waterproof case Installation...
-
Page 12: Inspection
3.2 Inspection Inspect the installed equipment before putting it into operation： · Make sure the PD connected can work normal. · Make sure the Ethernet cable connection is correct. Caution： Waterproof Ethernet cables should be with a protective sheath. CAT6 cables are recommended. Installation... - Page 13 Qualification Card PASS Creative Lianjie Network Technology Co.Ltd www.procetpoe.com...
