PROCET PT-PR01G User Manual

PT-PR01G PoE Surge Protector
Ｕｓｅｒ Ｍａｎｕａｌ
www.procetpoe.com
Overview
PT-PR01G is a single-port Ethernet surge protector. Enclosed in an Aluminum Alloy shell, with a
silver color exterior, complemented by an anodized aluminum surface. Enhanced RJ45 socket
exhibits minimal signal attenuation. High-quality Gas discharge tube(GDT). Withstand extreme
environmental conditions within a temperature range of -40 to 85 degrees Celsius. Max Discharge
Current: 10KA (8/20us, 1.25KA per line). Supports power of 120W, 60Vdc(max) Ethernet
equipment.
PT-PR01G can not only work with IEEE802.3af/at/bt/PoE++ standard devices, but also
supports non-standard Ethernet equipment, that well protects your devices against surge
damage.
The common mode surge voltage exceeds 10KV(10/700us) and the differential mode surge
voltage is 1.5KV(10/700us).
Appearance
１ Ｐｒｏｄｕｃｔ Ｄｉａｇｒａｍ
�
�
�.Fixing holes
�.Label
�.PoE input and Output port
�.GND Terminal
�
�
Ｄｅｃｌａｒａｔｉｏｎ
Copyright ©2024 Creative Lianjie Network
Technology Co.Ltd
This document belongs to PROCET company. It is not
allowed to reproduce and modify without the original
author's permission. It is PROCET's policy to improve its
products as new technology components, software , and
firmware at any time. PROCET, therefore, reserves the right
to change specifications without prior notice.
Please follow WEEE (Waste Electrical and Electronic
Equipment) disposal instructions for old electronic
products.Please do not dispose of the old product in your
general household waste bin.
The symbol indicates that the product should not be
discarded as unsorted waste but must be sent to separate
collection facilities for recovery and recycling.
�� MM
2 Dimensions
All rights reserved.
�� MM
