PROCET PT-PR01G-DIN User Manual

ＰＴ－ＰＲ01Ｇ－ＤＩＮ
ＤＩＮ Ｒａｉｌ Ｉｎｄｕｓｔｒｉａｌ ＰｏＥ Ｓｕｒｇｅ Ｐｒｏｔｅｃｔｏｒ
Ｕｓｅｒ Ｍａｎｕａｌ
ＷＷＷ．ＰＲＯＣＥＴＰＯＥ．ＣＯＭ

Overview

PT-PR01G-DIN is a single-port industrial PoE surge protector designed for exterior complex
backhaul and networking applications with an IP 40 rated Zinc alloy shell. It supports 8 lines
network signals and provides surge protection for PoE wires for 10KV surge protection. Peak
Surge Current is up to 10KA. It supports 10/100/1000Mbps of data rates. Ideal for 120W(max)
PoE wires and well protects your devices
PT-PR01G-DIN operates from -40°C to +85°C and works with voltage of 60Vdc (max). Either
port can be PoE in or PoE out.
It is connected to network over Cat5e/Cat6 cables with RJ45 connector conveniently and
tightly. This model equipped standard DIN rail mounting bracket, which can easily jam into
the guide rail. The DIN rail as a ground wire to transmit the current to the earth.
Ａｐｐｅａｒａｎｃｅ
１ Ｐｒｏｄｕｃｔ Ｄｉａｇｒａｍ
against surge damage.
�
1.．Ｓｌｉｄｉｎｇ Ｃｌｉｐ
2.ＲＪ45 Ｉｎｐｕｔ ｏｒ Ｏｕｔｐｕｔ
�
Ｄｅｃｌａｒａｔｉｏｎ
Copyright ©2023 Creative Lianjie Network
Technology Co.Ltd
This document belongs to PROCET company. It is not
allowed to reproduce and modify without the original
author's permission. It is PROCET's policy to improve its
products as new technology components, software , and
firmware at any time. PROCET, therefore, reserves the right
to change specifications without prior notice.
Please follow WEEE (Waste Electrical and Electronic
Equipment) disposal instructions for old electronic
products.Please do not dispose of the old product in your
general household waste bin.
The symbol indicates that the product should not be
discarded as unsorted waste but must be sent to separate
collection facilities for recovery and recycling.
�� MM
２ Ｄｉｍｅｎｓｉｏｎｓ
All rights reserved.
�� MM
