- Page 1 ＰＴ－ＰＲ０１Ｇ－ＤＩＮ Ｒａｉｌ Ｉｎｄｕｓｔｒｉａｌ PoE Surge Protector Ｑｕｉｃｋ Ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ www.procetpoe.com...
- Page 2 Ｄｅｃｌａｒａｔｉｏｎ This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
-
Page 3: Introduction
Ｏｖｅｒｖｉｅｗ The installation Guide for PT-PR01G-DIN and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product. -
Page 4: Table Of Contents
Ｔａｂｌｅ ｏｆ Ｃｏｎｔｅｎｔｓ １． Ｉｎｔｒｏｄｕｃｔｉｏｎ 1.1 Introduction..............01 1.2 Appearance..............01 1.3 Specification..............03 ２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ 2.1 Package contents............03 2.2 Installation toolkit............04 2.3 Installation inspection..........04 ３． Ｉｎｓｔａｌｌａｔｉｏｎ 3.1 DIN Rail Installation............. 06 3.2 Cable connection............07 3.3 Inspection................08 Table of Contents... -
Page 5: Appearance
１． Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ ＰＴ－ＰＲ０１Ｇ－ＤＩＮ ｉｓ ａ ｓｉｎｇｌｅ－ｐｏｒｔ ｉｎｄｕｓｔｒｉａｌ ＰｏＥ ｓｕｒｇｅ ｐｒｏｔｅｃｔｏｒ ｄｅｓｉｇｎｅｄ ｆｏｒ ｅｘｔｅｒｉｏｒ ｃｏｍｐｌｅｘ ｂａｃｋｈａｕｌ ａｎｄ ｎｅｔｗｏｒｋｉｎｇ ａｐｐｌｉｃａｔｉｏｎｓ ｗｉｔｈ ａｎ ＩＰ ４０ ｒａｔｅｄ Ｚｉｎｃ ａｌｌｏｙ ｓｈｅｌｌ． Ｉｔ ｓｕｐｐｏｒｔｓ ８ ｌｉｎｅｓ ｎｅｔｗｏｒｋ ｓｉｇｎａｌｓ ａｎｄ ｐｒｏｖｉｄｅｓ ｓｕｒｇｅ ｐｒｏｔｅｃｔｉｏｎ ｆｏｒ ＰｏＥ ｗｉｒｅｓ for １０ＫＶ ｓｕｒｇｅ ｐｒｏｔｅｃｔｉｏｎ． Ｐｅａｋ Ｓｕｒｇｅ Ｃｕｒｒｅｎｔ is ｕｐ ｔｏ １０ＫＡ． Ｉｔ ｓｕｐｐｏｒｔｓ １０／１００／１０００Ｍｂｐｓ ｏｆ ｄａｔａ ｒａｔｅｓ． Ｉｄｅａｌ ｆｏｒ １20Ｗ （ｍａｘ） ＰｏＥ ｗｉｒｅｓ ａｎｄ ｗｅｌｌ ｐｒｏｔｅｃｔｓ ｙｏｕｒ ｄｅｖｉｃｅｓ ａｇａｉｎｓｔ ｓｕｒｇｅ ｄａｍａｇｅ． ＰＴ－ＰＲ０１Ｇ－ＤＩＮ ｏｐｅｒａｔｅｓ ｆｒｏｍ －４０℃ ｔｏ ＋８５℃ ａｎｄ ｗｏｒｋｓ ｗｉｔｈ ｖｏｌｔａｇｅ ｏｆ ６０Ｖｄｃ （ｍａｘ）． Either port can be PoE in or PoE out. Ｉｔ ｉｓ ｃｏｎｎｅｃｔｅｄ ｔｏ ｎｅｔｗｏｒｋ ｏｖｅｒ Ｃａｔ５ｅ／Ｃａｔ６ ｃａｂｌｅｓ ｗｉｔｈ ＲＪ４５ ｃｏｎｎｅｃｔｏｒ ｃｏｎｖｅｎｉｅｎｔｌｙ ａｎｄ ｔｉｇｈｔｌｙ． Ｔｈｉｓ ｍｏｄｅｌ ｅｑｕｉｐｐｅｄ ｓｔａｎｄａｒｄ ＤＩＮ ｒａｉｌ ｍｏｕｎｔｉｎｇ ｂｒａｃｋｅｔ， ｗｈｉｃｈ ｃａｎ ｅａｓｉｌｙ ｊａｍ ｉｎｔｏ ｔｈｅ ｇｕｉｄｅ ｒａｉｌ． Ｔｈｅ ＤＩＮ ｒａｉｌ ａｓ ａ ｇｒｏｕｎｄ ｗｉｒｅ ｔｏ ｔｒａｎｓｍｉｔ ｔｈｅ ｃｕｒｒｅｎｔ ｔｏ ｔｈｅ ｅａｒｔｈ． １．２ Ａｐｐｅａｒａｎｃｅ Ｕｐｐｅｒ Ｖｉｅｗ Sliding Clip Upper View Introduction... - Page 6 Ｓｉｄｅ Ｖｉｅｗ ＲＪ４５ Ｉｎｐｕｔ ｏｒ Ｏｕｔｐｕｔ １－２ Ｓｉｄｅ Ｖｉｅｗ Ｆｒｏｎｔ Ｖｉｅｗ ＤＩＮ Ｒａｉｌ Ｃｌｉｐ １－３ Ｆｒｏｎｔ Ｖｉｅｗ Introduction...
-
Page 7: Specification
１．３ Ｓｐｅｃｉｆｉｃａｔｉｏｎ Ｉｔｅｍｓ Ｄｅｓｃｒｉｐｔｉｏｎ Ｗｏｒｋｉｎｇ Ｖｏｌｔａｇｅ ６０Ｖｄｃ （Ｍａｘ） Ｍａｘ Ｏｐｅｒａｔｉｎｇ ＤＣ Ｃｕｒｒｅｎｔ １Ａ ｆｏｒ ２ ｐａｉｒｓ， ２Ａ ｆｏｒ ４ ｐａｉｒｓ Ｍａｘ Ｏｐｅｒａｔｉｎｇ Ｐｏｗｅｒ １２０Ｗ １０ＫＶ Ｃｏｍｍｏｎ Ｍｏｄｅ Ｐｒｏｔｅｃｔｉｏｎ Ｌｅｖｅｌ（１０／７００ｕｓ）： PoE Surge Protection Ｄｉｆｆｅｒｅｎｔｉａｌ Ｍｏｄｅ Ｐｒｏｔｅｃｔｉｏｎ Ｌｅｖｅｌ（１０／７００ｕｓ）： １．５ＫＶ Ｄａｔａ Ｓｐｅｅｄ １０／１００／１０００Ｍｂｐｓ ＩＥＥＥ８０２．３ ａｆ／ａｔ／ｂｔ ＆ ＰｏＥ ＋＋ ＰｏＥ Ｓｔａｎｄａｒｄ Ｏｐｅｒａｔｉｎｇ Ｔｅｍｐ． －４０℃ ｔｏ ８５℃ Ｏｐｅｒａｔｉｎｇ Ｈｕｍｉｄｉｔｙ ２０％－８０％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ Ｏｐｅｒａｔｉｎｇ Ａｌｔｉｔｕｄｅ Ｕｐ ｔｏ ５０００ ｍｅｔｅｒｓ Ｓｔｏｒａｇｅ Ｔｅｍｐ． －４０℃ ｔｏ ８５℃ １０％－９０％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ Ｓｔｏｒａｇｅ Ｈｕｍｉｄｉｔｙ Ｓａｆｅｔｙ Ａｐｐｒｏｖａｌｓ ＣＥ ＩＰ４０ ＩＰ Ｒａｔｅｄ Ｄｉｍｅｎｓｉｏｎｓ＆ＮＷ ７７．２ｍｍ Ｘ ４５ｍｍ Ｘ １９ｍｍ（１１５ｇ） Ｒｅｇｕｌａｔｏｒｙ Ｃｏｍｐｌｉａｎｃｅ ＲｏＨＳ／ ＷＥＥＥ ＩＥＣ６００６８－２－６ （Ｖｉｂｒａｔｉｏｎ） Immunity ＩＥＣ６００６８－２－２７... -
Page 8: ２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ
２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ２．１ Ｐａｃｋａｇｅ Ｃｏｎｔｅｎｔｓ Ｏｐｅｎ ｔｈｅ ｂｏｘ ｏｆ ｔｈｅ ＰＴ－ＰＲ０１Ｇ－ＤＩＮ ａｎｄ ｃａｒｅｆｕｌｌｙ ｕｎｐａｃｋ ｉｔ， ｔｈｅ ｂｏｘ ｓｈｏｕｌｄ ｃｏｎｔａｉｎ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｉｔｅｍｓ： ＰＴ－ＰＲ０１Ｇ－ＤＩＮ Ｏｐｅｒａｔｉｎｇ Ｍａｎｕａｌ ２．２ Ｉｎｓｔａｌｌａｔｉｏｎ Ｔｏｏｌｋｉｔ Ｔｈｅｓｅ ｔｏｏｌｓ ｍａｙ ｂｅ ｎｅｅｄｅｄ ｄｕｒｉｎｇ ｅｑｕｉｐｍｅｎｔ ｉｎｓｔａｌｌａｔｉｏｎ， ａｎｄ ｓｈｏｕｌｄ ｂｅ ｐｒｅｐａｒｅｄ ｂｙ ｙｏｕｒｓｅｌｆ： ｌｅｖｅｌ ｒｕｌｅｒ， ｍａｒｋｉｎｇ ｐｅｎ， ｃｒａｆｔ ｋｎｉｆｅ， ｗｉｒｅ ｓｔｒｉｐｐｅｒ， ｎｅｔｗｏｒｋ ｐｌｉｅｒｓ， ｉｍｐａｃｔ ｄｒｉｌｌ，ｄｉｆｆｅｒｅｎｔ ｍａｔｃｈｉｎｇ ｄｒｉｌｂｉｔｓ， ｒｕｂｂｅｒ ｈａｍｍｅｒ， ｃｒｏｓｓ ｓｃｒｅｗｄｒｉｖｅｒ， ｗｒｅｎｃｈ， ｌａｄｄｅｒ， ｅｔｃ． ２．３ Ｉｎｓｐｅｃｔｉｏｎ Ｃｏｎｎｅｃｔ ｔｈｅ ＰＴ－ＰＲ０１Ｇ－ＤＩＮ ｗｉｔｈ ｔｈｅ ｐｒｏｔｅｃｔｅｄ ｄｅｖｉｃｅ， ａｎｄ ｃｈｅｃｋ ｉｆ ｔｈｅ terminal ｄｅｖｉｃｅ ｗｏｒｋ ｎｏｒｍａｌｌｙ． Installation Preparation... - Page 9 Ｓｗｉｔｃｈ Ｌｉｇｈｔｎｉｎｇ ＰＴ－ＰＲ０１Ｇ Strike Ｗｉｒｅ －ＤＩＮ Protected Wire ＰＴ－ＰＲ０１Ｇ －ＤＩＮ Protected Wire Ｇｒｏｕｎｄｉｎｇ ２－１ Ｄｅｖｉｃｅ Ｃｏｎｎｅｃｔｉｏｎ Ｃａｕｔｉｏｎ： We recommend to use Cat5 or higher UTP/STP cables for 100Base-TX Ethernet； We recommend to use Cat5e or above UTP/STP cables for 1000Base-T Ethernet. Installation Preparation...
-
Page 10: ３． Ｉｎｓｔａｌｌａｔｉｏｎ
３． Ｉｎｓｔａｌｌａｔｉｏｎ This product is safe for use in a waterproof case and DIN Rail mounts. ３．１ ＤＩＮ Ｒａｉｌ Ｉｎｓｔａｌｌａｔｉｏｎ ３．１．１ Ｓｅｃｕｒｅ ｏｎｅ ｓｉｄｅ ｏｆ ｔｈｅ ｐｒｏｄｕｃｔ ｂｙ ｉｎｓｅｒｔｉｎｇ ｉｔ ｉｎｔｏ ｔｈｅ ｅｄｇｅ ｏｆ ｔｈｅ ｇｕｉｄｅ ｒａｉｌ， ａｎｄ ｓｌｉｄｅ ｔｈｅ ｏｔｈｅｒ ｓｉｄｅ＇ｓ ｌａｔｃｈ ｉｎｔｏ ｔｈｅ ｅｄｇｅ ｏｆ ｔｈｅ ｇｕｉｄｅ ｒａｉｌ ｏｎ ｔｈｅ ｏｐｐｏｓｉｔｅ ｓｉｄｅ． Ａｓ ｓｈｏｗｅｄ ｉｎ ３－１. Ｓｌｉｄｉｎｇ ｌａｔｃｈ ＤＩＮ Ｒａｉｌ Ｒａｉｌ Ｍｏｕｎｔｉｎｇ Ｈｏｌｅｓ ３－１ ＤＩＮ Ｒａｉｌ Ｉｎｓｔａｌｌａｔｉｏｎ Installation... - Page 11 Ｉｆ ｉｔ ｉｓ ｐｌａｃｅｄ ｉｎ ａｎ ｏｕｔｄｏｏｒ ｅｎｖｉｒｏｎｍｅｎｔ， ｐｌｅａｓｅ ｉｎｓｔａｌｌ ｔｈｅ ｄｅｖｉｃｅ ｉｎ ａ ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ ｗｉｔｈ ａ ｈｅｉｇｈｔ ｏｆ ４５ｃｍ ｉｆ ｐｏｓｓｉｂｌｅ． As showed in figure 3-2. Ｂａｃｋｐｌａｔｅ Ｃａｂｌｅ ＤＩＮ Ｒａｉｌ ３－２ Ｗａｔｅｒｐｒｏｏｆ Ｃａｓｅ Ｉｎｓｔａｌｌａｔｉｏｎ Installation...
-
Page 12: Inspection
３．２ Ｃｏｎｎｅｃｔｉｏｎ Ａｆｔｅｒ ｉｎｓｔａｌｌａｔｉｏｎ ｉｓ ｄｏｎｅ， ｔｈｅ ｎｅｘｔ ｓｔｅｐ ｉｓ ｔｈｅ ｃｏｎｎｅｃｔｉｏｎ． Ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｐｒｅｃａｕｔｉｏｎｓ ｓｈｏｕｌｄ ｂｅ ｔａｋｅｎ ｗｈｅｎ ｃｏｎｎｅｃｔｉｎｇ ｔｈｅ Ｅｔｈｅｒｎｅｔ ｃａｂｌｅ： ３．２．１ Ｌａｙ ｔｈｅ ｃａｂｌｅ ａｃｃｏｒｄｉｎｇ ｔｏ ｔｈｅ ｄｅｓｉｇｎ ｒｅｑｕｉｒｅｍｅｎｔｓ． Ｔｈｅ ｃａｂｌｅ ｓｈｏｕｌｄ ｂｅ ｌａｉｄ ｆｉｒｍｌｙ ａｎｄ ｎｅａｔｌｙ， ｗｉｔｈ ｎｏ ｃｒｏｓｓｉｎｇ， ｔｗｉｓｔｉｎｇ， ｏｒ ｃｒａｃｋｉｎｇ． ３．２．２ Ｄｏ ｎｏｔ ｌａｙ ｔｈｅ ｃａｂｌｅ ｔｏｇｅｔｈｅｒ ｗｉｔｈ ｈｉｇｈ－ｖｏｌｔａｇｅ ｐｉｐｅｌｉｎｅｓ， ｆｉｒｅ ｐｉｐｅｌｉｎｅｓ， ｏｒ ｂｕｉｌｄｉｎｇ ｌｉｇｈｔｎｉｎｇ ｐｒｏｔｅｃｔｉｏｎ ｓｙｓｔｅｍｓ ｔｏ ａｖｏｉｄ ｉｎｔｅｒｆｅｒｅｎｃｅ ｆｒｏｍ ｓｔｒｏｎｇ ｅｌｅｃｔｒｉｃｉｔｙ ｏｒ ｍａｇｎｅｔｉｓｍ． ３．２．３ Ｕｓｅ ＰＶＣ ｐｉｐｅｓ， ｉｒｏｎ ｐｉｐｅｓ， Ｐｒｉｌｋａ ｐｉｐｅｓ， ｏｒ ｃａｂｌｅ ｔｒａｙｓ ｆｏｒ ｃａｂｌｅ ｌａｙｉｎｇ． Ｔｈｅ ｃａｂｌｅ ｔｒａｙｓ ｓｈｏｕｌｄ ｂｅ ｐｌａｃｅｄ ａｇａｉｎｓｔ ｔｈｅ ｗａｌｌ， ｗｉｔｈ ｎｅａｔ ａｎｄ ｂｅａｕｔｉｆｕｌ ｒｏｕｔｉｎｇ． Ｓｏｆｔ ｈｏｓｅｓ ｏｒ ｅｌｂｏｗ ｊｏｉｎｔｓ ｓｈｏｕｌｄ ｂｅ ｕｓｅｄ ａｔ ｔｕｒｎｉｎｇ ｐｏｉｎｔｓ． Ｔｈｅ ｃａｂｌｅ ｔｒａｙｓ ｓｈｏｕｌｄ ｂｅ ｓｅｃｕｒｅｄ ｗｉｔｈ ｃａｂｌｅ ｔｉｅｓ， ｈａｎｇｅｒｓ， ａｎｄ ａｎｇｌｅ ｓｔｅｅｌｓ ａｔ ａ ｓｐａｃｉｎｇ ｏｆ １ ｔｏ １．５ ｍｅｔｅｒｓ． Ｉｆ ａ ｍｅｔａｌ ｃａｂｌｅ ｔｒａｙ ｉｓ ｕｓｅｄ， ｉｔ ｓｈｏｕｌｄ ｂｅ ｇｒｏｕｎｄｅｄ ａｔ ｂｏｔｈ ｅｎｄｓ． ３．２．４ Ｆｏｒ ｏｕｔｄｏｏｒ ｈｏｒｉｚｏｎｔａｌ ｗｉｒｉｎｇ， ｐｌｅａｓｅ ｕｓｅ ａ ｓｌｏｔ ｅｖｅｒｙ ６ ｍｅｔｅｒｓ ｕｎｄｅｒ ｔｈｅ ＰＶＣ ｐｉｐｅ ａｓ ａ ｄｒａｉｎ ｔｏ ｐｒｅｖｅｎｔ ｗａｔｅｒ ａｃｃｕｍｕｌａｔｉｏｎ ｉｎｓｉｄｅ ｔｈｅ ｐｉｐｅ． ３．２．５ Ｔｈｅ ｗａｌｌ ｐｅｎｅｔｒａｔｉｏｎ ｆｏｒ ｔｈｅ Ｅｔｈｅｒｎｅｔ ｃａｂｌｅ ｓｈｏｕｌｄ ｂｅ ｓｅａｌｅｄ ｗｉｔｈ ｗａｔｅｒｐｒｏｏｆ ａｎｄ ｆｌａｍｅ－ｒｅｔａｒｄａｎｔ ｍａｔｅｒｉａｌｓ Ｃａｕｔｉｏｎｓ： Ｗａｔｅｒｐｒｏｏｆ Ｅｔｈｅｒｎｅｔ ｃａｂｌｅｓ ｓｈｏｕｌｄ ｂｅ ｗｉｔｈ ａ ｐｒｏｔｅｃｔｉｖｅ ｓｈｅａｔｈ． ＣＡＴ５ｅ／６ ｃａｂｌｅｓ ａｒｅ ｒｅｃｏｍｍｅｎｄｅｄ． ３．３ Ｉｎｓｐｅｃｔｉｏｎ Ｉｎｓｐｅｃｔ ｔｈｅ ｉｎｓｔａｌｌｅｄ ｅｑｕｉｐｍｅｎｔ ｂｅｆｏｒｅ ｐｕｔｔｉｎｇ ｉｔ ｉｎｔｏ ｏｐｅｒａｔｉｏｎ： Ｍａｋｅ ｓｕｒｅ ｔｈｅ Ｅｔｈｅｒｎｅｔ ｃａｂｌｅ ｃｏｎｎｅｃｔｉｏｎ ｉｓ ｃｏｒｒｅｃｔ． Installation... - Page 13 Qualification Card PASS Ｃｒｅａｔｉｖｅ Ｌｉａｎｊｉｅ Ｎｅｔｗｏｒｋ Ｔｅｃｈｎｏｌｏｇｙ Ｃｏ．Ｌｔｄ www.procetpoe.com...
