Introduction...............................................................................
Important Safety Information.............................................
Safety Instructions...................................................................4
Getting to Know Your Unit..................................................
Operating Procedures & Maintenance............................
Using Your Ice Maker..............................................................
Troubleshooting Guide..........................................................
Limited Warranty....................................................................
USA CANADA 1-800-
ICE MAKER
EFIC130-SS,
EFIC130-SSRED,
EFIC130-SSBLACK
2
3
5
7
8
9
10
11
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire EFIC130-SS
Summary of Contents for Frigidaire EFIC130-SS
-
Page 1: Table Of Contents
EFIC130-SS, EFIC130-SSRED, EFIC130-SSBLACK ICE MAKER Introduction................Important Safety Information..........Safety Instructions..............4 Getting to Know Your Unit..........Operating Procedures & Maintenance......Using Your Ice Maker.............. Troubleshooting Guide............Product Specifications............Limited Warranty..............USA CANADA 1-800-... -
Page 2: Introduction
INTRODUCTION When you unpack your ice maker, you may find a small amount of water inside. Your unit is brand new. Any water you may find is from the standard quality control testing that all of our ice makers undergo as part of the manufacturing process. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION Safety Instructions WARNING • DO NOT store or use gasoline, or other flammable liquids in the vicinity Please read all instructions before using of this or any other appliance. Read this appliance. product labels for warnings regarding flammability and other hazards. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS This appliance must be plugged into at least a 15 AMP 110-115 VOLT 60 Hz GROUNDED OUTLET. This appliance must be grounded. It is equipped with a 3-wire cord having a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. -
Page 5: Getting To Know Your Unit
GETTING TO KNOW YOUR UNIT General instrucion 1. Ice shovel 2. Ice full sensor 3. Ice basket 4. Top cover with transparent window 5. Air exhausting 6. Water drain cap: at front btm side of the unit 7. MAXIMUM WATER LEVEL: Remove the ice basket, you can see the water level mark. - Page 6 GETTING TO KNOW YOUR UNIT Postion of control panel & function Control Panel: Easy to use, visible functions touch display setting. A. Selected ice size displaying: Small and Large B. Power indicator C. Ice-Full indicato D .Water shortage indicator E. Button to turn on/o the unit F.
-
Page 7: Operating Procedures & Maintenance
OPERATING PROCEDURES & MAINTENANCE UNPACKING YOUR ICE MAKER 1. Remove the exterior and interior packaging. Check if ice basket and ice scoop inside. If any parts are missing, please contact our customer service. 2. Remove the tapes for fixing ice shovel, ice basket & ice scoop. Clean the tank & ice basket. -
Page 8: Using Your Ice Maker
OPERATING PROCEDURES & MAINTENANCE 4. **Run a Cleaning Cycle:** If your ice maker has a cleaning or descaling cycle, initiate it. If not, turn the ice maker back on and run it until the solution has circulated through the system. 5. -
Page 9: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSES SOLUTION Stop the ice maker, fill “ADD WATER” Lack of Water. water, and press “ON/ indicator light turns on. OFF” button again to restart the unit. Remove ice from ice basket. Continuous press “Select” button 5 seconds, “ICE FULL”... -
Page 10: Product Specifications
PRODUCT SPECIFICATIONS Input Voltage: 115V 60Hz Power Consumption: 90-120 W Daily Ice Output: 12 KGS/24H Ice-Making Amount Per Time: 9 PCS Refrigerant: R600a Dimensions Product Depth (IN.) 11.6 Product Height (IN.) 11.4 Product Width (IN.) 8.7 In Box Weight (lbs): 15.4 Out of Box Weight (lbs): 14.1 Box Dimensions (in.): 9.8X12.2X12.6 Power Cord Length (in.): 70.9... -
Page 11: Limited Warranty
LIMITED WARRANTY To make a warranty claim, please email support2@curtiscs.com or call 1-800-968-9853. 1 Year warranty This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or component found to be defective, at our option;... - Page 12 FRIGIDAIRE is a pending or registered trademark of Electrolux Home Products Inc. and used under a license from Electrolux Home Products, Inc.
- Page 13 EFIC130-SS, EFIC130-SSRED, EFIC130-SSBLACK APPAREIL À GLAÇON Les Instructions de Sécurité Importantes....Préparer Votre Machine À Glaçons Pour L'utiliser. Apprendre À Connaître Votre Unité......Procedures D'exploitation et Maintenance....Utilisation de Votre Machine À glaçons...... Problèmes et Solutions............. Spécifications du Produit..........Carte de Garantie..............
-
Page 14: Les Instructions De Sécurité Importantes
LES INSTRUCTIONS DE SÉCURITÉ IMPORTANTES Votresécuritéetlasécuritédesautressonttrèsimportant Nousavonsfourniplusieursmanuelsdesécuritéimportantsetvotreappareil. Lire et obéir à tous les messages de sécurité, s'il vous plaît C'estlesymboled'alertedesécurité: Touslesmessagesdesécuritésuivrontlesymboled'alertedesécuritéetlesmots« DANGER»ou«ATTENTION». DANGER ATTENTION Lessensdecesmots: Vouspouvezêtretuéougravementblessésivousnesuivezpasinstructions immédiatement. Touslesmessagesdesécuritévousdirontquelestledangerpotentiel, commentréduire lerisquedeblessureetcequipeutarriversilesinstructionsnesontpassuivies. Lorsque vous déballez votre machine à glaçons, vous pouvez trouver une petite quantité... -
Page 15: Préparer Votre Machine À Glaçons Pour L'utiliser
PRÉPARER VOTRE MACHINE À GLAÇONS POUR L'UTILISER LESCONSEILSDESÉCURITÉIMPORTANTS Lors de l'utilisation d'appareils électriques, des précautions de sécurité élémentaires doivent être respectées afin de réduire les risques d'incendie, d'électrocution et de blessures aux personnes ou aux biens. Lisez toutes les instructions avant d'utiliser un appareil. - Page 16 PRÉPARER VOTRE MACHINE À GLAÇONS POUR L'UTILISER IMPORTANT: Les fils de ce cordon d'alimentation sont colorés conformément au code suivant: Vert ou vert avec une bande jaune: mise à la terre Blanc: neutre Noir: Live Pour éviter un danger dû à l'instabilité de l'appareil, celui-ci doit être placé sur une surface plane ou plane.
-
Page 17: Apprendre À Connaître Votre Unité
APPRENDRE À CONNAÎTRE VOTRE UNITÉ Description générale 1. Pelle à glace 2. Capteur de glace 3. Panier de glace 4. Couvercle supérieur avec fenêtre transparente 5. Gaz d'échappement 6. Couvercle de vidange: côté BTM à l'avant de l'unit é 7. NIVEAU D'EAU LE PLUS ÉLEVÉ: Enlevez le panier de glace et vous verrez la ligne d'eau. - Page 18 APPRENDRE À CONNAÎTRE VOTRE UNITÉ Emplacement du panneau de commande et des fonctions Panneau de commande: facile à utiliser, fonction visible, réglage de l'a chage tactile. A. La taille de glace sélectionnée est a chée: petite et grande B. Indicateur de puissance C.
-
Page 19: Procedures D'exploitation Et Maintenance
PROCEDURES D'EXPLOITATION ET MAINTENANCE DÉBALLAGE DE LA MACHINE À GLACE 1. Retirer les emballages extérieurs et intérieurs. Vérifiez si le panier à glace et la cuillère à glace sont à l'intérieur. Si des pièces manquent, veuillez contacter notre service clientèle. 2. - Page 20 PROCEDURES D'EXPLOITATION ET MAINTENANCE 3. **Verser la solution dans le réservoir d'eau :** Versez la solution de détartrage dans le réservoir d'eau de la machine à glaçons. 4. **Lancer un cycle de nettoyage :** Si votre machine à glaçons dispose d'un cycle de nettoyage ou de détartrage, lancez-le.
-
Page 21: Problèmes Et Solutions
PROBLÈMES ET SOLUTIONS Le Problème La Raison La Solution Arrêtez la machine à glace, ajoutez de l'eau et L'indicateur de Manque d'eau. appuyez à nouveau sur remplissage d'eau le bouton marche / arrêt s'allume. pour redémarrer l'unit é. Retirer la glace du panier à... -
Page 22: Spécifications Du Produit
SPÉCIFICATIONS DU PRODUIT Tension D'entrée: 115V 60Hz Consommation Électrique: 90-120 W Débit Quotidien de Glace: 12 KGS / 24H Quantité de Marquage de Glace Par Temps: 9 Pièces Réfrigérant: R600a Dimensions Profondeur du Produit (EN.) 11,6 Hauteur du Produit (EN) 11,4 ... -
Page 23: Carte De Garantie
CARTE DE GARANTIE Pour faire une demande de garantie, veuillez envoyer un courriel électronique à support2@curtiscs.com ou appeler le 1-800-968-9853. 1 ans de garantie Ce produit est garanti contre tout défaut de matériel et de fabrication pendant une période de un (1) ans à compter de la date d'achat d'origine. Pendant cette période, votre seul recours est la réparation ou le remplacement de ce produit ou composant jugé... - Page 24 Notre maison est votre maison. Visitez-nous si vous besoin d'aide pour l'une de ces choses: soutien du propriétaire un service support2@curtiscs.com FRIGIDAIRE est une marque déposée ou en instance d'Electrolux Home Products Inc. Et utilisée sous licence d'Electrolux Home Products, Inc.
Need help?
Do you have a question about the EFIC130-SS and is the answer not in the manual?
Questions and answers
My Efic130-SS ice cube maker is stuck in "add water". I have completely emptied the tank, wiped it down and refilled it. I have unplugged, let it sit and plugged it back in. Still the little red light continues. I have been using it for about 5 months.
If the Frigidaire EFIC130-SS ice maker is stuck in "ADD WATER" mode even after refilling the tank and resetting the machine, check the following:
1. Make sure the water level is filled up to the max water level mark.
2. Allow at least 3 minutes for the refrigerant in the compressor to settle before restarting.
3. Ensure the unit is not exposed to direct sunlight, which can interfere with the infrared sensors.
4. If the problem continues, check for any clogs or issues with the water pump that may prevent water from being injected.
If none of these steps resolve the issue, further inspection or service may be needed.
This answer is automatically generated
After I select ice size it does not go into ice making mode.
The Frigidaire EFIC130-SS may not enter ice making mode after selecting ice size due to the following reasons:
1. Ice basket is full – The “ICE FULL” indicator may be on. Remove ice from the basket and restart the unit.
2. Water shortage – Ensure there is enough water in the tank.
3. Low water temperature – Water should be between 40°F and 90°F.
4. High room temperature – Room temperature should be between 50°F and 105°F.
5. Refrigerant issues or blocked pipes – A technician should check for refrigerant leaks or pipe blockages.
Check these factors and restart the unit after correcting the issue.
This answer is automatically generated
How can I more easily clean item?
To clean the Frigidaire EFIC130-SS ice maker more easily, follow these steps:
1. Empty the Ice Bin: Remove and discard all ice to start with a clean surface.
2. Prepare Descaling Solution: Use a commercial descaling solution or warm water. Mix according to instructions.
3. Pour into Water Reservoir: Add the solution to the ice maker's water reservoir.
4. Run a Cleaning Cycle: Use the cleaning or descaling cycle if available. If not, turn the unit on and let the solution circulate.
5. Let it Sit: Allow the solution to sit in the system to break down mineral buildup.
Use a soft cloth or sponge for wiping, and gloves if desired.
This answer is automatically generated
How can I clean the white scoop and flap inside. They are dirty and I can't see how to clean them without talking the whole icemaker apart.
To clean the white scoop and flap inside the Frigidaire EFIC130-SS ice maker:
1. Unplug the ice maker from the power supply to avoid electric shock.
2. Use warm water and a soft cloth or sponge to wipe the scoop and flap.
3. Do not use any beverages, chemicals, or substances other than water.
4. Dry the parts thoroughly before plugging the unit back in.
This helps maintain safety, performance, and prevents damage.
This answer is automatically generated
My ice maker keeps saying no water but there is water in it
The **** is not working on the ice maker
The issue with the Frigidaire EFIC130-SS ice maker could be identified using the Troubleshooting Guide in the manual. Some possible problems include:
1. Water Inside When Unpacked – This is normal as all units undergo quality control testing.
2. Not Making Ice – Could be due to insufficient water in the tank, the unit not being turned on, or a clogged water line.
3. Slow Ice Production – May be caused by high ambient temperature or a dirty condenser.
4. Ice Sticking Together – Could be due to prolonged ice storage inside the machine.
5. Unusual Noises – Might indicate an issue with internal components or an uneven surface placement.
6. Power Issues – Ensure the unit is plugged in properly and the outlet is functioning.
For specific troubleshooting steps, refer to the manual's guide or check power, water levels, and cleaning requirements.
This answer is automatically generated
@Yolanda
My ice maker isn’t make ice
The Frigidaire EFIC130-SS ice maker may not be making ice due to the following reasons:
1. Water Pump Issue: If the water pump does not fill the machine with water, it will stop automatically, and the "add water" indicator will turn on. To resolve this, add water to the maximum level and restart the unit.
2. Full Ice Basket: When the ice basket is full, the machine stops making ice, and the "ice full" indicator turns on. Remove some ice to continue operation.
3. Sensor Interference: Direct sunlight or reflections can affect the infrared sensor, preventing the machine from stopping correctly. Move the unit to a location without direct sunlight.
4. Improper Restart: If the unit has been restarted too quickly, the refrigerant may not have settled properly. Wait at least 3 minutes before turning it back on.
5. Water Hygiene: If the water in the tank is not changed regularly (every 24 hours), it may affect performance. Replace the water to maintain efficiency.
This answer is automatically generated
