SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
OWNER'S MANUAL
f i r e - p a r t s . c o m
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life. Installation and
service must be performed by a qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other Flammable vapours and liquids in the vicinity of
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements: Flexible connector must not be longer than 36in., a
shut off valve must be installed; only direct vent sealed combustion products are approved
for bedrooms/bathrooms. A carbon monoxide detector is required in all rooms containing
gas fired direct vent appliances.
EG28 DV
WHAT TO DO IF YOU SMELL GAS
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
This appliance may be installed in an after market
permanently located, manufactured (mobile) home, where
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
WARNING
FOR YOUR SAFETY
this or any other appliance.
B Y : S H E R W O O D I N D U S T R I E S L T D
not prohibited by local codes.
EG28-120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enviro EG28 DV and is the answer not in the manual?

Questions and answers

Summary of Contents for Sherwood Industries Enviro EG28 DV

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE EG28 DV B Y : S H E R W O O D I N D U S T R I E S L T D OWNER’S MANUAL...
