PTF30
Features
Best pressure transmission solution for small and
•
middle sized project such as indoor heating and air
conditioning, water and sewer, or incinerator, etc.
Improves noise resistance and minimize effects by
•
external disturbance
Realizes high accuracy measurement by stainless
•
steel diaphragm of pressure sensing part for various
measured subjects
DC4-20mA analog output (2-wire)
•
Various functions:
•
User input range, display scale, output scale, digital
昀椀lter, multi-display selection, error display, TUF (two
unit function), etc.
Explosion class: Ex d ⅡC T6
•
Protection structure: IP67 (IEC standard)
•
Ordering Information
PTF30
①
① Item
② Measurement pressure
③ Pressure range
④ HART communication output
⑤ Mounting bracket
⑥ Pressure port
⑦ User pressure range
※ 1: Write the desired pressure range and it is the default of user pressure range. (select "Z" at ③pressure range)
F-15
Series
G
7
N
N
F8
②
③
④
⑤
⑥
Description
PTF30
Pressure transmitter
G
Gauge pressure
A
Absolute pressure
Absolute pressure, gauge pressure
0 to 0.35kgf/cm
1
0 to 1kgf/cm
2
3
0 to 2kgf/cm
0 to 7kgf/cm
4
5
0 to 20kgf/cm
6
0 to 35kgf/cm
-
Z
Others
N
None
Without bracket
N
With bracket
B
F8
G3/8 (PF)
User pressure range
Please read "Safety Considerations" in operation manual
before using this unit.
2
(0 to 5 kgf/cm
)
⑦
2
2
2
2
2
2
※1
Gauge pressure
7
0 to 70kgf/cm
2
0 to 200kgf/cm
2
8
0 to 350kgf/cm
2
9
-257mmHg to 0kgf/cm
2
A
-760mmHg to 0kgf/cm
2
C
F
-760mmHg to 2kgf/cm
2
H
-760mmHg to 7kgf/cm
2
-760mmHg to 20kgf/cm
M
-760mmHg to 35kgf/cm
O
2
2
