Summary of Contents for Vents Solid
- Page 1 Solid Solid Glass Solid One Wave Wave One Flip Flip One AXIAL FAN User’s manual www.ventilation-system.com...
-
Page 2: Table Of Contents
The manual contains information about purpose, technical details, operating principle, design, and installation of the Vents Solid (Wave/Flip) unit and all its modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country. - Page 3 All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
- Page 4 Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it.
- Page 5 order to incorporate the latest technological developments. Never touch the unit with wet or damp hands. Never touch the unit when barefoot. BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS. This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for...
- Page 6 Cleaning and user maintenance shall not be made by children without supervision. Children shall not play with the appliance. Precautions must be taken to avoid the back-flow of gases into the room from the open flue of gas or other fuel-burning appliances. The appliance may adversely affect the safe operation of appliances burning gas or other fuels (including those in other rooms) due to back flow of combustion gases.
- Page 7 Ensure that the unit is switched off from the supply mains before removing the guard. THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE. DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
-
Page 8: Delivery Set
DELIVERY SET - 1 pc. Screws with dowels - 4 pcs. User’s manual - 1 pc. Packing box - 1 pc. Insulating gasket - 1 pc. BRIEF DESCRIPTION The product is an axial fan for exhaust ventilation of small and medium-sized premises heated in winter. The design of the fan may include a back valve that prevents air from flowing into the room when the fan is off. -
Page 9: Designation Key
DESIGNATION KEY Solid Motor modification _ — basic motor L — motor on ball bearings Additional options V — pull cord switch Fan series Solid Solid Van Solid Glass Wave Wave One Flip Flip One Outlet duct diameter [mm] 100/125... -
Page 10: Mounting
MOUNTING The fan is designed for wall (with the motors on ball and slide bearings) or ceiling (with the motors on ball bearings only, L option) mounting and can be used for direct outdoor air exhaust through a round duct or a duct system. In case of installation through a duct system, select the duct cross section in accordance with the fan size (Fig. -
Page 11: Maintenance
R 600 of its installation. Solid One/Wave One/Flip One/100 Solid Glass models may be installed in Zone 1 of bathrooms where the product cannot be exposed to water jets other than shower spray. -
Page 12: Troubleshooting
TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line No power supply. is connected correctly, otherwise When the unit is connected to power troubleshoot the connection error. mains, the fan does not rotate and does not respond to any controls. Internal connection fault. -
Page 13: Manufacturer's Warranty
MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/ EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 14 components caused by the user. • Redesign or engineering changes to the unit. • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. •...
- Page 15 ø D ] A [ ] B [ ] L [ ] L1 [ 100 Solid (One) (Glass) 100 Wave (One) 100 Flip (One) 125 Solid (Glass) 123,5...
- Page 16 ...2...
- Page 18 100/125 ... 100/125 ... VT Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED Fan runs Contact of the S1 switch or the pull cord switch is OPENED Activation of turn-off delay timer (2-30 minutes)
- Page 23 Quality Inspector’s Stamp Seller (name and stamp of the seller) Manufacture Date Purchase Date...
- Page 24 Certificate of acceptance ______________________________ The fan is recognized as serviceable. V12060_160EN-07...
