AE4-1486 R1
`
6-15 Ton YA*K1 and YP*K1 Copeland™ Scroll Compressors
IMPORTANT SAFETY INFORMATION ........................... 2
No table of contents entries found.
Terminal Venting and Other Pressurized System
Hazards ........................................................................ 2
Flammable Refrigerant Hazards .................................. 3
Electrical Hazards ........................................................ 3
Hot Surface and Fire Hazards ..................................... 3
Lifting Hazards ............................................................. 3
POE Oil Hazards .......................................................... 3
Precautions .................................................................. 3
Signal Word Definitions ................................................ 4
INTRODUCTION ............................................................... 5
Nomenclature ............................................................... 5
Operating Envelopes ................................................... 5
High Pressure Control .................................................. 5
Low Pressure Control .................................................. 5
Discharge Temperature Protection .............................. 6
Shut Down Device ....................................................... 6
Discharge Check Valve ................................................ 6
Shell Temperature ....................................................... 6
Compressor Cycling ..................................................... 6
Suction and Discharge Fittings .................................... 7
System Tubing Stress .................................................. 7
Accumulators ............................................................... 7
Off-Cycle Migration Control .......................................... 7
Crankcase Heaters ...................................................... 7
Pump Down Cycle ....................................................... 8
Pump Out Cycle ........................................................... 8
Reversing Valves ......................................................... 8
Contaminant Control .................................................... 8
Oil Type ........................................................................ 9
Power Factor Correction .............................................. 9
Soft Starters ................................................................. 9
Manifolded Compressors ............................................. 9
VARIABLE SPEED OPERATION .................................... 9
Introduction .................................................................. 9
APPLICATION TESTS ..................................................... 9
ASSEMBLY LINE PROCEDURES ................................ 10
Installing the Compressor .......................................... 10
Mounting .................................................................... 10
© 2020 Emerson Climate Technologies, Inc.

TABLE OF CONTENTS

Suction and Discharge Fittings .................................. 10
Assembly Line Brazing Procedure ............................. 10
Unbrazing System Components ................................ 11
Removing Compressors ............................................. 11
Pressure Testing ........................................................ 11
Final Run Test ............................................................ 12
SERVICE PROCEDURES .............................................. 12
Field Replacement ..................................................... 12
Removing Oil .............................................................. 12
Electrical ..................................................................... 12
Manifolded Compressor Replacement ....................... 12
Refrigerant Retrofits ................................................... 13
New Installations ........................................................ 14
Field Service ............................................................... 14
Figures & Tables
Figure 1 - ASTP Label ....................................................... 6
Figure 2 - Scroll Tube Fitting Brazing .............................. 14
Figure 3 - YA YP Scroll Nomenclature ............................ 15
Figure 4 - Crankcase Heater Location ............................ 16
Figure 5 - Operating Envelope YA67K1 - YA91K1 ......... 17
Figure 6 - Operating Envelope YA104K1, YA122K1 ....... 18
Figure 7 - Operating Envelope YA137K1 - YA182K1 ..... 19
Figure 8 - Operating Envelope YP137K1 - YP182K1 ..... 20
Figure 9 - Operating Envelope YP72K1 - YP97K1 ......... 21
Figure 10 - Operating Envelope YP105K1, YP123K1 ..... 22
Figure 11 - Oil Dilution Chart ........................................... 23
Table 1- Product Features ............................................... 24
Table 2 - Torque Values .................................................. 24
Table 3 - Refrigerant Charge Limits ................................ 25
1
April 2023

Advertisement

Table of Contents
loading

Summary of Contents for Emerson Copeland YA K1 Series

  • Page 1: Table Of Contents

    Table 2 - Torque Values ..........24 Introduction ..............9 Table 3 - Refrigerant Charge Limits ........ 25 APPLICATION TESTS ............. 9 ASSEMBLY LINE PROCEDURES ........ 10 Installing the Compressor .......... 10 Mounting ..............10 © 2020 Emerson Climate Technologies, Inc.
  • Page 2: Important Safety Information

    Additionally, a compressor’s refrigerant lines keep refrigerant and oil under pressure. When removing or recharging refrigerant from this component during service, this can pose a pressurized fluid hazard. © 2020 Emerson Climate Technologies, Inc.
  • Page 3: Flammable Refrigerant Hazards

    Never reset a breaker or replace a blown fuse without performing appropriate electrical testing. A tripped breaker or blown fuse may indicate an electrical fault in the compressor. Energizing a compressor with an electrical fault can cause terminal venting. Perform checks to rule out an electrical fault. © 2020 Emerson Climate Technologies, Inc.
  • Page 4: Signal Word Definitions

    WARNING indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury. CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if not CAUTION avoided, could result in minor or moderate injury © 2020 Emerson Climate Technologies, Inc.
  • Page 5: Introduction

    (See Table 1). Events such as loss of may increase the risk of malfunction and serious injury charge, evaporator blower failure, or low side charging or death. with inadequate pressure will cause the discharge gas © 2020 Emerson Climate Technologies, Inc.
  • Page 6: Discharge Temperature Protection

    Figure 1 - ASTP Label tube (available from Emerson) and install it in a system with the longest connecting lines and highest internal volume that the system may have. The minimum on time...
  • Page 7: Long Pipe Lengths / High Refrigerant Charge

    Table 1 for rotalock torque requirements. To properly install the crankcase heater, the heater should be installed in the location illustrated in Figure 4. Tighten the clamp screw carefully, ensuring that the © 2020 Emerson Climate Technologies, Inc.
  • Page 8: Pump Down Cycle

    It is generally accepted that system manufacturer's data. Low ambient heating conditions moisture levels should be maintained below 50 ppm. A © 2020 Emerson Climate Technologies, Inc.
  • Page 9: Oil Type

    Tandem and trio compressor assemblies are available interconnecting tubing plus contaminants for purchase from Emerson. In lieu of purchasing the introduced during field installation process. assembled tandem or trio, OEMs can purchase the...
  • Page 10: Assembly Line Procedures

    ▪ In single compressor systems: to check oil return, in the head of the compressor after Emerson’s run test testing conditions shall be at minimum mass flow and and may also result in oil mist coating the suction tube minimum density of suction gas in continuous and making brazing difficult.
  • Page 11: Unbrazing System Components

    Most of the charge should be pumped in the high side of the system to prevent low voltage starting difficulties, hipot motor test failures, and bearing washout during the first-time start on the © 2020 Emerson Climate Technologies, Inc.
  • Page 12: Final Run Test

    In the case of a motor burn, most of the contaminated result in terminal venting. oil will be removed with the compressor. The rest of the oil is cleaned with the use of suction and liquid line filter © 2020 Emerson Climate Technologies, Inc.
  • Page 13: Refrigerant Retrofits

    UL ruining the compressor by operating with no refrigerant recognition. flow. For a list of Emerson approved refrigerants please refer to Form 93-11, Refrigerants and Lubricants Approved for Use in Copeland Compressors.
  • Page 14: New Installations

    ✓ Recommended brazing materials: Silfos with minimum 5% silver or silver braze material with flux. ✓ Insert tubing stubs into fitting and connect to the system with tubing connectors. ✓ Follow New Installation brazing instructions above. © 2020 Emerson Climate Technologies, Inc.
  • Page 15 AE4-1486 R1 Figure 3 - YA YP Scroll Nomenclature © 2020 Emerson Climate Technologies, Inc.
  • Page 16 AE4-1486 R1 Figure 4 - Crankcase Heater Location YA, YP 67 - 122 YP 137 -182 Connect the heater so the connection point straddles the compressor weld seam © 2020 Emerson Climate Technologies, Inc.
  • Page 17 AE4-1486 R1 Figure 5 - Operating Envelope YA67K1 - YA91K1 Evaporating Temperature (°C) 50-60 HZ 9F SH Envelope 20F SH Envelope Evaporating Temperature (°F) © 2020 Emerson Climate Technologies, Inc.
  • Page 18 AE4-1486 R1 Figure 6 - Operating Envelope YA104K1, YA122K1 Evaporating Temperature (°C) 50-60 HZ 9F SH Envelope 20F SH Envelope Evaporating Temperature (°F) © 2020 Emerson Climate Technologies, Inc.
  • Page 19 AE4-1486 R1 Figure 7 - Operating Envelope YA137K1 - YA182K1 Evaporating Temperature (°C) 50-60 Hz 45-70 Hz 40-75 Hz 40-60 35-75 Hz 9F SH envelope 20F SH Envelope Evaporating Temperature (°F) © 2020 Emerson Climate Technologies, Inc.
  • Page 20 AE4-1486 R1 Figure 8 - Operating Envelope YP137K1 - YP182K1 Evaporating Temperature (°C) 50-60HZ 9F SH Envelope 20F SH Envelope Evaporating Temperature (°F) © 2020 Emerson Climate Technologies, Inc.
  • Page 21 AE4-1486 R1 Figure 9 - Operating Envelope YP72K1 – YP97K1 Evaporating Temperature (°C) 50-60HZ 9F SH Envelope 20F SH Envelope Evaporating Temperature (°F) © 2020 Emerson Climate Technologies, Inc.
  • Page 22 AE4-1486 R1 Figure 10 - Operating Envelope YP105K1, YP123K1 Evaporating Temperature (°C) 9F SH Envelope 20F SH Envelope 50-60Hz Evaporating Temperature (°F) © 2020 Emerson Climate Technologies, Inc.
  • Page 23 AE4-1486 R1 Figure 11 © 2020 Emerson Climate Technologies, Inc.
  • Page 24 Schrader Valve 3.3-5.0 40-60 4.5-6.8 Terminal Block Screws 1.0-1.3 12-15 1.4-1.7 Oil Access Fitting (Threads Into Oil Rotalock) 16.7-18.3 200-220 22.6-24.9 Crankcase Heater 1.7-2.1 20-25 2.3-2.8 M8 Terminal Box Mounting Stud Nuts 3.5-3.9 42-47 4.7-5.3 © 2020 Emerson Climate Technologies, Inc.
