3. Connect Data Cables

Connect the data cables and
secure them tightly by hand.
Tie the data cables together with
the outlet hose using a zip tie.
Do not include the pull down
hose in the zip tie.
4. Install Counterweight
Install the counterweight on the pull
down hose at the marked position
(It should be placed on the line,
but can be moved in either
direction if necessary).

5. Insert Batteries

Remove the battery pack cover and
battery pack. Insert 4 AA batteries.
Ensure the batteries are inserted
properly accordingly to polarity.
Put the battery pack back in the
control box and replace the cover
firmly. The batteries should be charged
or changed when the sensor flashes
a red light three times per second.
12
6. Connect Supply Lines
Connect the hot and cold supply
lines onto the matching water
valves and secure the connection
with an adjustable wrench. The
hoses are color coded for
convenience. Afterwards, turn the
water supply clockwise to turn it on.
7. Attach Spray Head
Screw the spray head clockwise
onto the pulldown hose. (You may
need to pull the hose down.)
8. Check For Leaks
Open the faucet handle and wave
your hand over the sensor. Set
the water temperature to desired
setting. The water temperature
changes by manipulating the
handle. The water will stop if the
motion sensor is activated again,
or after 3 minutes. Check for leaks.
Pull out the spray head. The water
will run when the spray head is
pulled out. Slide the spray head
back in original position, and the
water will turn off. Repeat this
operation several times and check
for errors. If none, then the faucet
installation is complete.
