Installation Types - BEMIS FLOW MOTION ACTIVATED User Manual

3.93 in
1.37 in
2 in
9/16-24
UNEF-2B
10.25 in
Features
•
Motion Sensor
•
SmartLatch Pull Down Activation
•
Single or Three Hole Installation
•
Drip-free Ceramic Cartridge
•
3 Function Spray Head
•
Easy Installation With Quick Connections
8
13°
1.73 in
1.1 in
8.38 in
2.5 in
M32 x 1.5

2 Installation Types

Single Hole
Installation
Finishes
•
Chrome
•
Brushed Nickel
•
Oil Rubbed Bronze
•
Champagne
•
Matte Black
Three Hole
Installation
Complies with:
•
ASME A 112.18.1/
CSA B125.1 (cUPC)
•
NSF/ ANSI/
CAN 61 : Q≤1
•
NSF/ ANSI/
CAN 372 (AB1953)
9
