d)
Replace the computer's housing cover.
Note: If you already have a SCSI card installed in your computer:
When installing the scanner driver, you will be asked to choose TYPICAL or
CUSTOM installation, choose CUSTOM and select "Adaptec or other ASPI
Compatible Interface Card". Otherwise, the scanner will not work properly.

4. Connect the SCSI Cable

Connect the SCSI cable to the SCSI interface card and the other end of the SCSI
cable to the scanner.
If your scanner is not chained to other SCSI devices or at the end of the SCSI chain,
please connect the terminator to the remaining SCSI port of your scanner.

5. Connect the Power

Connect the power cord to the scanner and plug the other end of the power cord
into an available outlet (socket).
6. Power Up
a)
Turn the scanner power switch on. When the Ready indicator is on, your
scanner is ready to use.
b)
Turn on your computer.
Power Switch
v
