Sunnydaze Decor AGR-355 Assembly Instructions Manual

3-door sideboard cabinet with drawers
Hide thumbs Also See for AGR-355:

Advertisement

Quick Links

Download this manual
3 - DOOR SIDEBOARD CABINET
Carefully review assembly and care instructions before using this product. Save this document for future reference.
Assemble components on a soft, clean surface to avoid scratching or damaging the finish.
HELPFUL HINTS
Sunnydaze Decor advises reviewing this manual fully, and assembling the unit soon after purchase.
Check that all parts are accounted for and familiarize yourself with the assembly before beginning.
CA636
Purchase Date:
Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at
If you have any questions, comments or concerns, feel free to contact us by phone at 833-982-1977, by email:
customerservice@sunnydazedecor.com, or via our contact us page at
WITH DRAWERS
SAVE THIS MANUAL FOR FUTURE REFERENCE.
/
/
Order/Customer Reference Number:
2-PERSON
ASSEMBLY
RECOMMENDED
03/2023
https://tiny.cc/SunnydazeWarranty
https://tiny.cc/SunnydazeContact
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
Save the packing slip.
SCAN THIS CODE
WITH YOUR
SMARTPHONE
TO VIEW OUR
ASSEMBLY VIDEO
Tools Required
(not included)
Phillips Screwdriver
Rubber Mallet
Hammer
Power Drill,
6mm Drill Bit,
2mm Drill Bit
(only use for installing wall anchor kit)
Page 1 / 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the AGR-355 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunnydaze Decor AGR-355

Summary of Contents for Sunnydaze Decor AGR-355

  • Page 1 Order/Customer Reference Number: Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell. Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with the date of purchase as well as photos of the merchandise defect, must be provided.
  • Page 2 INTRODUCTION Read the manual carefully to ensure you fully understand all use, care, assembly, and safety information. Assemble on a soft, flat, clean, and Read this manual carefully and dry surface. follow the assembly instructions in the order listed. Pay close Use a soft, protective barrier when attention to assembly drawings.
  • Page 3 COMPONENTS Inspect packaging to ensure all parts are accounted for before disposing of packing materials. Save the packing slip. Seq. Part Name Qty. Right Side Panel Left Side Panel Right Stile Left Stile Hardware Qty. Shelf Wood Dowel Bottom Frame M4.5x28mm Pan Screw Left Cabinet Face Frame Connector...
  • Page 4 ASSEMBLY Carefully review all steps and fully understand assembly before beginning. IMPORTANT: Take care not to over-tighten screws as doing so may crack the wood or strip the screw hole, causing a weak connection and reduced stability. STEP 1 02: 1 03: 1 14: 2 23: 3...
  • Page 5 STEP 3 08: 1 09: 1 10: 1 11: 1 12: 2 13: 1 15: 2 16: 2 A: 44 Locate Left Cabinet Bottom Frame (08), Face Frame (09), Right Cabinet Face Frame (10), Center Face Frame (11), two Vertical Drawer Face Frames (12), Top Face Frame (13), two Center Drawer Rails (15), and two Back Supports (16).
  • Page 6 STEP 5 19: 1 G: 3 Align the top of Bottom Panel (29) with the back supports, as shown. Secure the bottom panel to each back support using one M4x40mm Flat Screw (G). Align Leg (19) with the bottom, center of the bottom panel and secure using one M4x40mm Flat Screw (G). STEP 6 B: 6 Identify the front, back, top and bottom of Right Side Panel (02) and Left Side Panel (03).
  • Page 7 STEP 7 7: 1 Identify the finished edge of Shelf (07). Slide the shelf into the cabinet, ensuring it is on top of the shelf pins, as shown. STEP 8 IMPORTANT: Ensure the components are tight against M: 4 each other before fastening the screws. IMPORTANT: Ensure the mounting holes on Part 08 are installed as...
  • Page 8 STEP 9 IMPORTANT: Ensure the components are tight against M: 4 each other before fastening the screws. IMPORTANT: Ensure components are installed in the correct direction, as indicated in the diagrams. Installation direction is very important in this step. Identify the longer gap between the dowel mounting holes and the edge of Vertical Drawer Face Frames (12); it is marked with a + and - symbol to indicate there is a lesser and greater distance between the dowel mounting holes and the edges, the plus (+) side must be on top.
  • Page 9 STEP 11 IMPORTANT: Ensure the hinge plates are installed as indicated by the arrows. K: 12 Q: 6 Align six Hinge Plates (Q) with indents on the backside of the front frame, as shown. Secure each hinge plate using two M3.5x14mm Pan Screws (K). STEP 12 B: 8 Align the assembled front frame with the cabinet, as shown.
  • Page 10 STEP 13 01: 1 K: 2 N: 6 On the bottom of the unit, identify the indent on the backside of the bottom frame and the indent in the bottom, center of the bottom panel. Align one Bracket (F) with the indents and secure using two M3.5x14mm Pan Screws (K). Lay Top (01) on a flat, clean surface.
  • Page 11 STEP 15 B: 8 K: 2 IMPORTANT: Ensure the drawer rails are installed in the correct direction, as indicated in the diagram. Identify the two indents on Outside Drawer Rails (14), the indent with the shortest distance between the indent and the edge of the rail must be installed toward the front of the cabinet.
  • Page 12 STEP 17 22: 3 25: 3 26: 3 B: 12 D: 3 E: 12 H: 6 Ensuring the inside grooves align, secure Right Drawer Side (23) and Left Drawer Side (24) to Drawer Face (22) using four M4.5x38mm Pan Screws (B). Slide Drawer Bottom (25) into the grooves, as shown.

  • Page 13: Door Installation

    STEP 19 Assistance is recommended for this step. IMPORTANT: Ensure each door is properly aligned before fully securing any screws. HINGE ADJUSTMENT INSTRUCTIONS Door Installation: Please note, the cabinet box must be level and plumb for the door to work properly. Under certain conditions, wall surfaces may not be plumb, which results in a slight gap, either at the top or bottom, or between the doors.
  • Page 14 STEP 21 20: 2 21: 1 Gently lay the unit face-down on a soft, clean surface. Place two Backing Boards (20) on the back of the unit and slide Divider (21) between them. Ensure the backing boards are snug within the lips of the top and side panels. Then, secure the backing board using thirty 8x8mm Nails (Z).
  • Page 15 SAFETY STATEMENTS & WARNINGS • Residential use only. Not for commercial or industrial use. • For indoor use only. • Ensure fittings are tight before use. Periodically check fitting to ensure they are tight. • Only use this unit on a flat, level surface. •...
