Summary of Contents for Vornado EXO51 HD
- Page 1 EXO51 HD & EXO61 HD WHOLE ROOM CIRCULATOR OWNER’S GUIDE READ AND SAVE THESE INSTRUCTIONS vornado.com...
- Page 2 We expect this If it is not, we product to be will make it perfect. right. vornado.com 800-234-0604 help@vornado.com English...
-
Page 3: Table Of Contents
CONTENTS Important Safety Instructions ............. 4 Warranty .................... 14 Features ....................7 Getting Started ................... 8 Controls ....................9 How to Use ..................10 Cleaning .................... 11 Troubleshooting ................13 English... -
Page 4: Important Safety Instructions
Do not use this product in a bathtub or shower or position together with the product, to any future owner. See www.vornado. product where it may fall into a bathtub, laundry, swimming pool com/circulators-manuals to view, download and print the most or other water container. - Page 5 Prior to cleaning, turn off the power on your product order to avoid a hazard. Contact Vornado Consumer Service and unplug. Do not use gasoline, thinners, solvents, ammonias at 1-800-234-0604 (phone) or consumerservice@vornado.com or other chemicals for cleaning.
- Page 6 5. Remove fuse by using the screwdriver to gently lift each end of the fuse (See Fig. B). 6. Install the replacement fuse by using the screwdriver to gently push each metal end of the fuse into the receptacle one at a time. Do not push on the center of the fuse—it is fragile and may break (See Fig.
-
Page 7: Features
FEATURES POWERFUL IP-54 RATED MOTOR FINGER FRIENDLY DESIGN Dust proof, long life motor that will endure the rigors of the job site Resists curious fingers TOOL FREE ASSEMBLY REMOVABLE GRILLE Everything in the box you For easy cleaning need to get started HIGH IMPACT HOUSING Impact-resistant EXTRA LONG 8’... -
Page 8: Getting Started
GETTING STARTED BASE ASSEMBLY 1. Loosen the pivot knobs (A) by turning each counter-clockwise. 2. Insert the base between the large rubber washer (B) and the small metal washer (C). 3. Once both sides of the base are installed, tighten the pivot knobs by turning clockwise. Note: Assemble base only as shown below. -
Page 9: Controls
CONTROLS POWER ON/OFF Select High (III), Medium (II), Low (I) fan speed or power off (O) English... -
Page 10: How To Use
1. Locate the Key Holes (A) on the back of the product. 2. Find and mark two circles on the wall where the product will be mounted. For EXO51 HD, the circles need to be 5” apart from center to center. For EXO61 HD, the circles need to be 5.5”... -
Page 11: Cleaning
CLEANING GRILLE REMOVAL Screwdriver required. WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing grille. 1. Remove the 6 screws located on the front of Screw Screw the grille. 2. Dust or wash the Front Grille with a mild dishwashing soap. - Page 12 CLEANING BLADE REMOVAL Pliers recommended. WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing blade. 1. First, remove the nut from the shaft by turning the nut clockwise to loosen. Remove the washer. Pull the blade straight out from the shaft.
-
Page 13: Troubleshooting
Under certain conditions, it is possible for a reset GFCI (Ground Fault Circuit Interrupter) outlet to trip when the user is changing speeds on a Vornado circulator. In this event, change to an outlet that is not connected to a GFCI device. It could also indicate a weak or defective GFCI outlet. Contact a qualified electrician to check the GFCI outlet. -
Page 14: Warranty
(5) years from the date of purchase. If any such defect is discovered within used in the country intended. REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS the warranty period, Vornado, at its discretion, will repair or replace the Product at no cost. WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. VORNADO SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF For warranty service: Call 1-800-234-0604 or email help@vornado.com to obtain a Return... - Page 15 Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | vornado.com CL3-0704 RA, V00...
