Installation Instructions
and Homeowner's Manual
INSTALLER / SERVICE TECHNICIAN:
USE THE INFORMATION IN THIS MANUAL FOR THE INSTALLATION
AND SERVICING OF THE FURNACE AND KEEP THE DOCUMENT NEAR
THE UNIT FOR FUTURE REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE
REFERENCE.
X40212 Rev. A
Multi-position
Electric furnace
240 VAC POWER SUPPLY
Variable speed
motor (ECM)
Models:
OFE15000GR-VV
OFE18000GR-VV
OFE20000GR-VV
OFE23000GR-1HVV
OFE27000GR-1HVV
Caution:
the unit or its controls. Call a
qualified service technician.
Manufactured by:
Industries Dettson inc.
Subsidiary of Groupe Ouellet Canada Inc.
3400, boulevard Industriel
Sherbrooke, Québec - Canada
J1L 1V8
www. ouellet.com
2011-10-15
Do not tamper with
1 800 463-7043
Printed in Canada
1
