Technical Data - Bosch C70 Operating Instructions Manual

Bosch C70 charger I Operating instructions

1 Technical data

Technical data
Input voltage
Starting current
Rated input current
Input power
Rated output voltage
Charging voltage
Charging current
Rated output current
Reverse current 1
Protection rating
Protection class
Battery type
Battery capacity
Fuse (internal)
Fuse (fuse holder)
Noise level
Temperature
Dimensions
The reverse current is the current that the charger consumes from the battery when no mains
1)
power is connected.
230VAC / 50Hz
<50 A
Max. 2 A (RMS value)
190 watts
DC 12 V/24 V
14.4 V/14.7 V (± 0.25 V),
28.8 V/29.4 V (± 0.6 V),
16.5 V/13.6 V (± 0.5 V)
10 A (± 10 %),
5 A (± 10 %),
1.5 A (± 0.3 A)
10 A & 5 A
< 5 mA (no AC input)
IP65 (dustproof, waterproof)
II (double insulated)
12 V & 24 V lead-acid battery (lead acid, EFB, GEL,
AGM and open VRLA)
12 V: 14 Ah - 300 Ah, 24 V: 14 Ah - 120 Ah
5 A
40 A
< 50 dB(A)
0°C to + 40°C
215 x 112 x 65.4 mm (L x W x H)
