Table Of Contents - U-Line Echelon 2175DWRWC Installation Manual

Contents
Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cut-Out Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clearances Information . . . . . . . . . . . . . . . . . . . . . . . . .
Other Site Requirements . . . . . . . . . . . . . . . . . . . . . . . .
Adding a Final Finish Coat to Wood Trim . . . . . . . . . .
Staining Wood Trim a Different Color . . . . . . . . . . . . .
Checking Drawer Alignment . . . . . . . . . . . . . . . . . . . .
Adjusting Drawer Alignment . . . . . . . . . . . . . . . . . . . .
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 11
Leveling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation of the 2175DWRWC . . . . . . . . . . . . . . . . . . 12
Anti-Tip Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation Troubleshooting . . . . . . . . . . . . . . . . . . . . . 13
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Start-Up Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 14
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
www.U-LineService.com
2175DWRWC - Drawer Model Wine Captain
®
1 Follow Safety Precautions
4
4
5
PLEASE READ all instructions completely before
5
attempting to install or operate the unit.
6
7 • This unit requires connection to a grounded (three-
prong), polarized receptacle that has been placed by a
7
qualified electrician in accordance with applicable
8
electrical codes.
8
Safety Alert Definitions
Safety items throughout this guide are labeled with a
Danger, Warning or Caution based on the risk type:
Danger means that failure to follow this safety
statement will result in severe personal injury or
death.
Warning means that failure to follow this safety
statement could result in serious personal injury,
or death.
Caution means that failure to follow this safety statement
may result in minor or moderate personal injury, property
or equipment damage.
