Installation Guide 2175DWRWC — ® Wine Captain Drawer www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2006 U-Line Corporation 06/2006... -
Page 2: Table Of Contents
2175DWRWC — Drawer Model Wine Captain Contents Exterior Cleaning ......Cut-Out Dimensions ......Product Dimensions . -
Page 3: Inspect And Plan
General Precautions Use this appliance for its intended purpose only and follow these general precautions along with those listed throughout this guide: WARNING SHOCK HAZARD — Electrical Grounding Required. • Keep the unit unplugged throughout installation except during testing. • Never remove the round grounding prong from the plug and never use a two-prong grounding adapter. -
Page 4: Exterior Cleaning
® 3 Prepare Site Your U-Line product has been designed for built-in installation. Your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for electrical connection in the rear. -
Page 5: Product Dimensions
Product Dimensions 25-13/16" Including Handle 23-15/16" Black or Stainless Steel Figure 2 Please note that the unit has adjustable feet that can add one additional inch to height during leveling or to match adjacent cabinets (see Figure 19 on Page 11). 06/2006 2175DWRWC —... -
Page 6: Other Site Requirements
60 Hz, 15A circuit (normal household current). See Electrical Specifications on Page 11. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor/marine environments. Special considerations include the following: • The units are designed to operate between 50°F (10°C) and 110°F (40°C). -
Page 7: Adding A Final Finish Coat To Wood Trim
4 Prepare Racks and Caddy ® The U-Line Wine Captain is equipped with wood- trimmed wine racks that are coated at the factory with a clear vinyl sealer, which will adequately protect the wood in normal usage. A final finish coat was not applied so that the wood trim could be stained to match décor. -
Page 8: Checking Drawer Alignment
2175DWRWC — Drawer Model Wine Captain 5 Adjust Drawers Checking Drawer Alignment The unit’s drawers are aligned at the factory before shipment. However, their alignment could have been disturbed during shipment. Aligned Front-to-Back Aligned Top-to-Bottom Figure 6 See Figure 6. Check each drawer to confirm that it is aligned: •... - Page 9 Minor Adjustment: Note: The mounting holes on the slide are slightly larger than the screws’ diameter. 1. Loosen the slide’s mounting screws. 2. Push the slide backward. Push Slide Backward 3. Retighten the screws. See Figure 9. Figure 9 Severe Adjustment: Note: The slides have extra mounting holes that may be used.
- Page 10 2175DWRWC — Drawer Model Wine Captain Top-to-Bottom (and Left-to-Right) Adjustment Not Aligned Top-to-Bottom Not Aligned Left-to-Right Front View of Unit Figure 14 See Figure 14. The drawer will need a Top-to-Bottom Adjustment if, when viewed from the front, the drawer is not level horizontally.
-
Page 11: Electrical Specifications
6 Prepare Power Supply Electrical Specifications CAUTION Electrical installation must observe all state and local codes. This unit requires connection to a grounded (three- prong), polarized receptacle that has been placed by a qualified electrician. The unit requires a grounded and polarized 115 VAC, 60 Hz, 15A power supply (normal household current). -
Page 12: Installation Of The 2175Dwrwc
2175DWRWC — Drawer Model Wine Captain 8 Install the Unit Installation of the 2175DWRWC 1. Plug in the power cord. 2. Gently push the unit into position. Be careful not to entangle the electrical cord. 3. Re-check the leveling, from front to back and side to side. -
Page 13: Installation Troubleshooting
2. Insert the screws through the anti-tip bracket (B) and attach the bracket to the unit. Tighten screws securely. 3. Repeat for the other side. Note: The bracket should be flush with the surface it is being attached to. If it is not, loosen the screws and slide the bracket against the mounting surface. -
Page 14: Start-Up Troubleshooting
2175DWRWC — Drawer Model Wine Captain To display actual temperature of each drawer, press the “ ” and “ ” touch sensors simultaneously for three seconds. The display indicates the actual temperature. After approximately 10 seconds, the set point temperature displays. To adjust the temperature set point, touch and hold either the “... -
Page 15: Service Information
For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in ®...
