Novus NVIP-2DPT-8731/30/T User Manual

Dual ptz ip camera
Hide thumbs Also See for NVIP-2DPT-8731/30/T:
Table of Contents

Advertisement

Quick Links

Download this manual
U s e r m a n u a l
version 1.0
NVIP-2DPT-8731/30/T
Dual PTZ IP Camera
(Thermal/Visual)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVIP-2DPT-8731/30/T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Novus NVIP-2DPT-8731/30/T

Summary of Contents for Novus NVIP-2DPT-8731/30/T

  • Page 1 U s e r m a n u a l version 1.0 NVIP-2DPT-8731/30/T Dual PTZ IP Camera (Thermal/Visual)

  • Page 2: Table Of Contents

    NVIP-2DPT-8731/30/T User manual version 1.0 TABLE OF CONTENTS 1. WWW INTERFACE ...................... 5 1.1. Thermal module remote viewing window - main page ........5 2. CAMERA OPERATION MODE - PLAYBACK ............6 3. CAMERA OPERATION - PEOPLE COUNTING ............7 4.
  • Page 3 NVIP-2DPT-8731/30/T User manual version 1.0 TABLE OF CONTENTS 4.7.5. “Retrograde” menu ..................21 4.7.6. “Advanced” menu ..................22 4.7.7. “People Counting” menu ................23 4.7.8. “Enter Area” menu (themal module) ............24 4.7.9. “Leave Area” menu (themal module) ............24 4.7.10.
  • Page 4 NVIP-2DPT-8731/30/T User manual version 1.0 PRELIMINARY INFORMATION PRELIMINARY INFORMATION This user manual contains detailed information on how to operate the 8000 series Dual PTZ IP cameras. The following chapters describe all the functionalities of the Dual PTZ IP cameras. However, depending on the firmware version, some of the functions may not be available, not supported or the scope of operation may differ from that described.

  • Page 5: Www Interface

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - MAIN WINDOW Since the remote viewing windows and menus of the vision and thermal imaging modules are functionally almost identical, their description is based on the viewing window and menu of the thermal imaging module. Any differences are marked in the text.

  • Page 6: Camera Operation Mode - Playback

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - PLAYBACK 2. CAMERA OPERATION - PLAYBACK Option not supported. All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.

  • Page 7: Camera Operation - People Counting

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - PEOPLE COUNTING 3. CAMERA OPERATION - PEOPLE COUNTING People Counting menu displays people counting function statistics. When you select a search scope in the Query Condition menu, statistics will be displayed. The statistic can be shown by line chart, histogram or list.

  • Page 8: Camera Operation - Configuration

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4. CAMERA OPERATION - CONFIGURATION This menu allows user to modify and configure all parameters and camera settings available in a given model. Most of the settings can be changed conveniently and safely by selecting a parameter value from the drop-down list.

  • Page 9: Image" Tab

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.3.2. “Image” tab In the "Image" tab, user can adjust the level of brightness, contrast and sharpness (clarity) of the camera image. The vision module menu also allows to adjust color saturation.

  • Page 10: Ffc Control" Tab

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.3.5. “FFC Control” tab The tab allows to configure the operation of the FFC function. The FFC (Flat Field Correction) function improves the quality of the thermal image, which degrades over time due to the accumulation of small sensor errors related to changes in the ambient temperature or the observation of static elements.

  • Page 11: Exposure" Tab (Vision Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.3.6. “Exposure” tab (vision module) This tab allows you to configure how exposure works. 4.3.7. “WB” tab (vision module) The tab allows to set way of working a white balance mechanism.

  • Page 12: Noise Reduction" Tab

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.3.9. “Noise Reduction” tab The tab allows to configure the operation of the noise reduction function. It is possible to set the reduction level manually or select automatic mode. 4.3.10. “Enhance Image” tab (vision module) The tab allows to configure one of the image enhancement functions.

  • Page 13: Device" Group Of Settings

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.4. “Device” group of settings This menu allows you to configure camera parameters and functions. 4.4.1. “Local Network” menu This menu allows to configure the basic network settings. The menu allows to set the method of obtaining the IP address (static or DHCP), allows to select the IP protocol (IPv4 or IPv6), and to set basic network parameters (IP address, subnet mask, gateway, DNS server addresses).

  • Page 14: Audio Input" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.4.6. “Audio Input” menu This menu allows to turn on and set the volume for audio input. 4.4.7. “Audio Output” menu This menu allows to turn on and set the volume for audio output.

  • Page 15: Smoker Detection" Menu (Themal Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.6.2 “Smoker Detection” menu (themal module) This menu allows to recognize smokers. To recognize an object, the camera uses the people recognition function combined with the detection of a point increase in temperature.

  • Page 16: Fire Spot Detection" Menu (Themal Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION Output Channel - selection of the alarm output to be activated when an object is detected Audible Alarm - turning on and selecting the voice message that the camera can play when an object is...

  • Page 17: Intelligent Analysis" Group Of Settings

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7. “Intelligent Analysis” group of settings This menu allows you to configure thermal image analysis functions. 4.7.1. “Intrusion” menu The menu allows you to configure up to eight detection zones. An alarm event is generated when the object crosses the zone boundary in any direction.

  • Page 18: Single Line Crossing" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.2. “Single Line Crossing” menu This menu allows to configure up to eight detection lines. An alarm event is generated when object crossing determined line, and its movement is carried out in a direction specific in the settings.

  • Page 19: Double Line Crossing" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.3. “Double Line Crossing” menu This menu allows to configure up to one pair of detection lines. An alarm event is generated when object crossing both determined lines, and its movement is carried out in a direction specific in the settings.

  • Page 20: Multi - Loitering" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.4. “Multi - Loitering” menu The menu allows you to configure up to eight detection zones. An alarm event is generated when the specified number of objects stays in the detection zone for a specified period of time.

  • Page 21: Retrograde" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.5. “Retrograde” menu The menu allows you to configure up to eight detection zones. An alarm is generated when an object moves in the zone in the direction opposite to that indicated by the arrow.

  • Page 22: Advanced" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.6. “Advanced” menu This menu allows to configure the VCA engine to recognize objects correctly. This menu options should be set before configuring image analysis options. This menu also allow to configure the alarm intervals sent by ONVIF (“Alarm Interval” option).

  • Page 23: People Counting" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.7. “People Counting” menu This menu allows to count people crossing the virtual line. The number of counts is displayed on the OSD and saved and presented in the statistics. The direction of movement of objects is also analyzed and depending on the settings of the detection line, objects are classified as “entering”...

  • Page 24: Enter Area" Menu (Themal Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.8. “Enter Area” menu (themal module) The menu allows to configure up to eight detection zones. An alarm event is generated when the object crosses the zone boundary with movement towards the inside of the zone. It can be any object, or - with object classification turned on - a person and/or a vehicle.

  • Page 25: Smart Motion" Menu (Themal Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.7.10. “Smart Motion” menu (themal module) The menu allows to configure up to eight detection zones. An alarm event is generated when the object crosses the zone boundary with movement towards the inside of the zone. It can be a person and/or a vehicle.

  • Page 26: Intelligent Tracking" Menu (Themal Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.8. “Intelligent Tracking” menu (themal module) The menu allows to configure object tracking features. Intelligent tracking is used to a certain algorithm for the basic features of the target. After comparing and matching with each frame of image, the position of the target in each frame of the video image is generated, and the motion track of the target is generated.

  • Page 27: Alarm" Group Of Settings

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.9. “Alarm” group of settings This menu allows to configure alarm events. 4.9.1. “Alarm Output” menu This menu allows to configure the camera's alarm output options. It is possible to define the active state, operating mode (continuous, timed or pulsating), and output activity schedule.

  • Page 28: Device Communication" Group Of Settings (Vision Module)

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.10. “Device Communication” group of settings (vision module) Option not supported. 4.11. “Thermal” group of settings (themal module) This menu allows to configure parameters related to temperature measurement and imaging. 4.11.1. “Temperature Parameters” menu This menu allows to configure the parameters of the thermal imaging module.
  • Page 29 NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION Area ID Display Mode - selecting the method of displaying the name of the temperature measurement zone Area Temperature Display Mode - selection of temperature display location Font Border, Custom Colors, Font size - font modification...

  • Page 30: Ambient Temperature" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.11.2. “Ambient Temperature” menu This menu allows to configure reference temperature. Ambient Temperature - the temperature in device ambient. If you not setup a parameter here, the device use cavity temperature to calculate the target temperature.

  • Page 31: Privacy Zone Masking" Menu

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION Warning Value - camera will warn when the surveillance object temperature reaches the warning value. At Threshold Alarm and Temperature Difference Alarm this value can be set. Alarm Value - camera will alarm when the surveillance object temperature reaches the alarm value.

  • Page 32: Ai Multiobject" Group Of Settings

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.12. “AI Multiobject” group of settings This menu allows to configure image analysis with object classification. Fullbody Detection - turns on people detection Vehicle Detection - turns on vehicle detection The vision module additionally has the "Face Detection" option.

  • Page 33: Network Service" Group Of Settings

    NVIP-2DPT-8731/30/T User manual version 1.0 WWW INTERFACE - CONFIGURATION 4.15. “Network Service” group of settings This menu allows to configure the network services, like 802.1x, DDNS, PPPoE and others. 4.16. “Privilege Manager” group of settings This menu allows to manage the rights of the camera users. The camera allows to add, remove and change permissions.

  • Page 34: Common Emission Rate Table

    NVIP-2DPT-8731/30/T User manual version 1.0 EMISSION RATE TABLE Common emission rate table The emission rate is the capability of an object to emit or absorb energy. An ideal transmitter provides an emission rate of emitting 100% of intake energy. An object with an emission rate of 0.8 can absorb 80% of intake energy, and reflect the remaining 20%.
  • Page 35 NVIP-2DPT-8731/30/T User manual version 1.0 EMISSION RATE TABLE All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA sp. z o.o.
  • Page 36 AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o. 431 Pulawska St., 02-801 Warsaw, Poland tel.: +4822 546 0 546, kontakt@aat.pl www.novuscctv.com 26.09.2023 TF, MK v.1.0...
