Installation Guide for the
AV Bridge Nano Audio Video Encoder
Overview
This guide provides information about the AV
Bridge Nano audio video encoder, 999-82600-
000 (worldwide)
About this guide
This guide covers:
n
Tips for a successful installation
Connection diagram
n
Equipment power-on
n
Features
Bridge any HDMI video and audio source into soft conferencing applications
n
Reliable streaming and video capture scenarios over USB or RTSP/RTMP
n
Select USB 3.0 or IP streaming (configurable as RTSP or RTMP)
n
n
IP streaming resolution up to 1080p/30 and USB streaming resolution up to 1080p/60
HDMI pass-through for ease of integration with Cisco codecs
n
Stereo unbalanced line in and line out
n
Audio mixer
n
n
Kensington lock
Document Number 411-0066-31 Rev B – August 2023
Advertisement
Related Manuals for LEGRAND VADDIO AV Bridge Nano
Summary of Contents for LEGRAND VADDIO AV Bridge Nano
- Page 1 Installation Guide for the AV Bridge Nano Audio Video Encoder Overview This guide provides information about the AV Bridge Nano audio video encoder, 999-82600- 000 (worldwide) About this guide This guide covers: Tips for a successful installation Connection diagram Equipment power-on Features Bridge any HDMI video and audio source into soft conferencing applications Reliable streaming and video capture scenarios over USB or RTSP/RTMP...
-
Page 2: Front Panel
