- Page 1 UIDE VGA M ONITOR PLITTER XTENDER Model: 29503 (2-Port) / 29504 (4-Port)
-
Page 2: Table Of Contents
ABLE OF ONTENTS Introduction..............................2 Features................................3 System Requirements............................4 Package Contents............................5 Device Installation............................6 Technical Specifications...........................7 Important Safety Information..........................8... -
Page 3: Introduction
NTRODUCTION Thank you for purchasing the TruLink VGA Monitor Splitter/Extender. The TruLink VGA Monitor Splitter/Extender enables you to simultaneously distribute a VGA signal to two or four video displays, while boosting the signal up to 210 feet. The device is powerful yet easy to use, with no software or complicated interface cards to install. -
Page 4: Features
EATURES Color-Coded Connectors - HD15 Female Input (1), HD15 Female Outputs (2) or (4) Durable All-Metal Housing Power-Saving Mode No Software Required Transmission distance of up to 210 feet Suitable for XGA, SVGA, VGA, and Multi-Sync monitors Daisy-Chain multiple units together to support additional displays 350MHz Video Bandwidth 1920 x 1440 @80Hz Maximum Resolution... -
Page 5: System Requirements
YSTEM EQUIREMENTS A system with an HD15 VGA video card (1 qty) male to male HD15 cable* (for splitter to computer) (2 qty) (29503) or (4 qty) (29504) male to male HD15 cables* (for splitter to monitors) *UXGA cables recommended for higher resolution applications... -
Page 6: Package Contents
ACKAGE ONTENTS 29503 Package Contents (1) 2-Port VGA Monitor Splitter/Extender 5V AC Power Adapter User Guide 29504 Package Contents (1) 4-Port VGA Monitor Splitter/Extender 5V AC Power Adapter User Guide... -
Page 7: Device Installation
EVICE NSTALLATION One HD15 male to male (M/M) cable is required to connect from the Video Splitter input to a computer’s VGA output. Multiple monitors should be connected to the Video Splitter’s output ports as shown below with HD15 cables. The ACTIVE LED turns on when there is a video signal at the Input port. -
Page 8: Technical Specifications
ECHNICAL PECIFICATIONS Function 29503 29504 Number of VGA output Signal bandwidth 350MHz Signal type VGA, SVGA, XGA, Multi-sync POWER (green) x 1 ACTIVE (amber) x 1 Cable length 65M (210ft) Max. HDB15 female x 1 Connector - Input - Output HD15 HD15 female x 2... -
Page 9: Important Safety Information
MPORTANT AFETY NFORMATION ! Do not plug the unit in any outlet that does not have enough current to allow the device to function. Refer to the specifications in this manual for power level of the unit. ! Liquid: If this unit or its corresponding power adapter has had liquid spilled on or in it, do not attempt to use the unit. Do not attempt to use this product in an outdoor environment as elements such as rain, snow, hail, etc. - Page 11 For more information on this product or to check for updated drivers, manuals or frequently asked questions please visit our website. www.c2g.com . 2.0.12.20.22...
