Summary of Contents for LEGRAND VADDIO EasyIP Decoder
- Page 1 Installation Guide for EasyIP Systems Featuring the EasyIP Decoder and EasyIP 10 Camera Document 411-0041-39 Rev B February 2020...
-
Page 2: Table Of Contents
Contents Overview What's in this Guide The EasyIP Ecosystem EasyIP Decoder EasyIP Cameras PoE+ Switch Decoder Features Camera Features Unpacking the EasyIP System Components A Quick Look at the System Components Front of the Decoder Front of the Camera Back of the Decoder Back of the Camera Installation Don’t Void Your Warranty! -
Page 3: Overview
Overview This guide discusses the following products: EasyIP Decoder AV-over-IP switching USB endpoint, 999-60210-000 (worldwide) EasyIP 10 AV-over-IP PTZ camera, 999-30200-000 (black, worldwide) EasyIP 10 AV-over-IP PTZ camera, 999-30200-000 (black, worldwide) At a minimum, an EasyIP system includes one decoder and one camera. See Basic Connections. -
Page 4: The Easyip Ecosystem
Installation Guide for EasyIP Systems The EasyIP Ecosystem ® Vaddio EasyIP products are designed to be used together. A basic EasyIP system includes an EasyIP Decoder managing up to four EasyIP cameras. Typically the EasyIP system is powered by a PoE+ switch. EasyIP cameras deliver video in Vaddio's proprietary EasyIP format. -
Page 5: Unpacking The Easyip System Components
Installation Guide for EasyIP Systems Unpacking the EasyIP System Components Make sure you received all the items you expected. EasyIP Decoder AV-over-IP switching USB endpoint Worldwide: 999-60210-000 The box should contain one of each item listed here: EasyIP Decoder USB 3 cable, 6 ft. (1.8 m) Cat-5e cable, 3 ft. -
Page 6: A Quick Look At The System Components
Installation Guide for EasyIP Systems A Quick Look at the System Components EasyIP Decoder – Decodes the AV-over-IP signal from the camera(s) and originates a USB stream. EasyIP 10 camera – Great video, simple installation, minimal set-up. Front of the Decoder Status light –... -
Page 7: Back Of The Decoder
Installation Guide for EasyIP Systems Back of the Decoder Network/PoE+ – RJ-45 connector. Connect to a powered port on the PoE+ switch. USB 3.0 – USB Type B connector. Connect to a computer for use with soft conferencing applications. Provides uncompressed USB 3.0 stream. EasyMic –... -
Page 8: Installation
Installation Guide for EasyIP Systems Installation Please refer to the Installation Guide for EasyIP AV-over-IP Systems for a more system-oriented view of EasyIP product installation. It includes information not available in this manual. This section covers: Selecting the location for the camera Installing the mount Cabling notes Connection diagrams... -
Page 9: Before Installing A Camera
Installation Guide for EasyIP Systems Before Installing a Camera Things to keep in mind when deciding where to install the camera: Consider camera viewing angles, lighting conditions, line-of-sight obstructions, and in-wall obstructions where the camera is to be mounted. Ensure that the camera body can move freely and will normally point away from the ceiling and lights. The camera will not perform well if it is pointed toward a light source such as a light fixture or window. -
Page 10: Cabling Notes
Installation Guide for EasyIP Systems Cabling Notes Caution When building cables for Vaddio products, do not use pass-through RJ-45 connectors. Incorrectly crimped pass-through connectors can damage the connectors on the product, which will void your warranty. Damaged – Bent contact fingers Intact –... -
Page 11: Basic Connections
Installation Guide for EasyIP Systems Basic Connections Here is an example of a simple EasyIP deployment. In this setup, an EasyIP Decoder manages up to four EasyIP 10 cameras and provides hard-wired audio connections. A PoE+ switch provides power and network connectivity to the EasyIP products. -
Page 12: Installing The Camera
Installation Guide for EasyIP Systems Installing the Camera 1. Route the cable through the opening in the mounting shelf and connect it to the camera. 2. Place the camera on the mount. 3. Attach the camera to the mount using the mounting screw supplied with the camera. Note If the camera is jostled or bumped while it is connected to power, it may require a pan-tilt reset. -
Page 13: Powering Up The Easyip System
Installation Guide for EasyIP Systems Powering Up the EasyIP System Vaddio recommends making all connections while the PoE+ switch is turned off. To power the system, turn on the PoE+ switch. The EasyIP Decoder's status light turns blue when the device is ready. The connected computer recognizes it as a USB peripheral. -
Page 14: Specifications
Installation Guide for EasyIP Systems Specifications Specifications are subject to change without notice. EasyIP Decoder USB Streaming, Audio, and Control USB Stream Video and Audio Input Power PoE+ Up to 1080p/60 Resolution (Full USB Audio 2 Channel (UAC) EasyMic Inputs RJ-45 16-bit resolution 12V, bidirectional... -
Page 15: Operation, Storage, And Care
Installation Guide for EasyIP Systems Operation, Storage, and Care For smears or smudges on the product, wipe with a clean, soft cloth. Use a lens cleaner on the lens. Do not use any abrasive chemicals. Keep this device away from food and liquids. Do not operate or store the device under any of the following conditions: Temperatures above 40°... -
Page 16: Compliance And Conformity Statements
Installation Guide for EasyIP Systems Compliance and Conformity Statements Compliance testing was performed to the following regulations: FCC Part 15 (15.107, 15.109), Subpart B Class A ICES-003, Issue 54: 2012 Class A EMC Directive 2014/30/EU Class A EN 55032: 2015 Class A EN 55024: November 2010 Class A... -
Page 17: European Compliance
Installation Guide for EasyIP Systems European Compliance This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Standard(s) To Which Conformity Is Declared: EMC Directive 2014/30/EU EN 55032: 2015 –... -
Page 18: Warranty And Return Policy
Warranty and Return Policy Hardware warranty: Two (2) year limited warranty on all parts and labor for Vaddio manufactured products. Vaddio warrants its manufactured products against defects in materials and workmanship for a period of two years from the day of purchase, to the original purchaser, if Vaddio receives notice of such defects during the warranty. - Page 19 Installation Guide for EasyIP Systems General RMA Terms and Procedures: RMA’s are valid for 30 days and will be issued to Vaddio dealers only. End users must return products through Vaddio dealers. Before a defective product can be authorized to send in for repair, it must first go through the troubleshooting process with a member of the Vaddio Technical Support team.
- Page 20 Installation Guide for EasyIP Systems Advance Replacement Procedures: The Vaddio Dealer must submit a non-revocable purchase order for advance replacement equipment at normal dealer pricing. Credit shall be issued upon complete product return (including all accessories) for dealers with Net 30 terms. For credit card accounts, charges will be assessed to the credit card for the replacement and credited back upon complete product return.
- Page 21 Installation Guide for EasyIP Systems Non-Warranty Repair Charges: Total repair charges (per unit) for a non-warranty repair consist of the following: Cost of any replacement parts needed to repair the defect. Labor costs billed per hour after minimum charges/time. Labor charges include troubleshooting and repair time only. Burn-in time and final test time is not included in the labor charges.
-
Page 22: Photo Credits
Installation Guide for EasyIP Systems Photo Credits This guide may include some or all of these photos. European Space Agency (ESA) astronaut Samantha Cristoforetti, a Flight Engineer with Expedition 42, photographs the Earth through a window in the Cupola on the International Space Station By NASA - https://blogs.nasa.gov/ISS_Science_Blog/2015/03/06/women-in-space-part-two-whats- gender-got-to-do-with-it/, Public Domain, https://commons.wikimedia.org/w/index.php?curid=38834990 Carl Sagan, Bruce Murray, Louis Friedman (founders) and Harry Ashmore (advisor), on the occasion of... -
Page 23: Index
Index minimum requirements, EasyIP system 9 mount 7, 10 installing 7 mounting the camera 10 anatomy of the camera 4 anatomy of the decoder 4 audio 5 network port 5 ports 5 operating environment 6, 13 behavior on power-up 11 buttons and indicators 4 packing list 3 part numbers 3... - Page 24 Installation Guide for EasyIP Systems visual packing list 3 visual parts identification 4-5 wall mount 7 installing 7 warranty 6, 16...
- Page 25 ©2020 Legrand AV Inc. Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
