Required Tools: (Not included)
A. Phillips screwdriver
B. 8 mm wrench
WARNING
CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect charger before performing any
assembly or maintenance procedures. Failure to follow these steps in the correct order may cause irreparable damage.
Step 1
Using a Phillips screwdriver, remove the six (6) screws
on the deck cover (circled in the image below).
Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
C. Small pointy object
Step 2
Using an 8 mm wrench, remove the two (2) lock nuts at
the back of the deck cover circled in the image below).
1
MOTOR REPLACEMENT
INSTRUCTIONS
PART# W13111612030
E100

Advertisement

loading
Need help?

Need help?

Do you have a question about the E100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Razor E100

  • Page 1 (circled in the image below). the back of the deck cover circled in the image below). Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
  • Page 2 (circled in the below) and remove the chain guard and set aside. image below). Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
  • Page 3 • Re-attach deck cover with six (6) screws and two (2) lock nuts. Attention: Charge battery 12 hours before using. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
