Summary of Contents for Vimar 01507
- Page 1 Installer manual 01507 By-me KNX router BUILDING AUTOMATION WELL-CONTACT PLUS...
- Page 2 BUILDING AUTOMATION...
-
Page 3: Table Of Contents
7 .1 Protecting the front-end Web of 01507 . . . . . . . . . . . . . . . . -
Page 4: System Requirements
By-me BUS . Router 01507 conforms to the KNX Secure requirements on the datapoints defined in the routing table . A datapoint on the KNX side can be defined for the heartbeat signal . 2.1 Front view of the device... -
Page 5: Commissioning
2.4 Secure Commissioning To launch the secure download of the configuration settings and/or individual address, you first need to add the individual Certificate of device 01507 to the ETS project . To add it, the ETS project must be password-protected . -
Page 6: Important Notes
BUILDING AUTOMATION Product description The individual Certificate of the device is always included with the KNX Secure product . For the product to be configured by the user, make sure you do not lose the device Certificate (see chapter 2 .6 Keeping the device Certificate) . 2.5 Important notes We recommend you attend standardised courses at a certified KNX training centre before installing, programming and commissioning a KNX system . -
Page 7: Keeping The Device Certificate
. The communication stack and application software are downloaded . The firmware update procedure via IP can be carried out from the front-end Web of router 01507, which is independent of the ETS and which uses special messages... -
Page 8: The Knx Secure Protocol
BUILDING AUTOMATION The KNX Secure protocol 4. The KNX Secure protocol The device is used to activate the “KNX SECURE” data encryption protocol, entering the QR code or the digits in ETS and also creating a password associated to the project . - Page 9 BUILDING AUTOMATION The KNX Secure protocol 3. The device is displayed with the Secure part disabled . Transparent icon = Secure disabled Secure disabled 4. No password is associated with the project . 5. No certificate is associated to the project .
-
Page 10: Description Of Operation
(Group objects, Parameters, DCA) created in ETS for the specific device . It can be used normally without activating the Security function and in ETS projects in which the Security function is active . After connection to KNX IP, router 01507 works with its default settings . A valid individual address must be set . -
Page 11: Adding The Device Certificate
BUILDING AUTOMATION Description of operation 5.4 Adding the device Certificate Each KNX Secure device uses its own Certificate . The device Certificate must be entered in ETS before activating or using the KNX security functions . The device Certificate is printed on a label affixed to the side of the casing . The device Certificates can be entered manually or by scanning the QR code with the webcam . -
Page 12: Programming
BUILDING AUTOMATION Description of operation 5.5 Programming 5.5.1 Programming the individual address (and application) To download the individual address in a device, the Programming mode must be active . Press the programming button to activate or deactivate the program- ming mode . A red lit configuration LED (I) indicates the programming mode is active . When the download from ETS is activated and you press the programming button, the device stores the new individual address in the memory . -
Page 13: Network Backbone Configuration With Knx Secure Active
Backbone is Secure . Once the Backbone secure is activated, the configuration status of the various Secure devices will show as not up to date and so the ap- plication programmes will have to be downloaded again . 5.5.3 01548 interface configuration For the correct operation of the router 01507 configuration procedure, the physical addresses on the secondary line (TP) must be filtered . -
Page 14: Ip Configuration
5.5.4 IP configuration The IP configuration of 01507 can be specified in the ETS properties window . To activate DHCP/AutoIP, set the option: “Obtain an IP address automatically” . For further details and information about IP network configuration, please contact your local network administrator . -
Page 15: Organising The Dca For Customising Associations
BUILDING AUTOMATION Organising the DCA for customising associations 6. Organising the DCA for customising associations To simplify the definition of the association between By-me group and KNX group, there is a tab called DCA available (as in the figure below) . Section A Section B 6.1 Controls... -
Page 16: Tab
Organising the DCA for customising associations 6.4 Tab This is the section of ETS which contains all the default “Tab Group Object” and “Parameters” . A specific “DCA” tab is dedicate to “01507 Router By-me KNX” for the definition of the routing rules . -
Page 17: Non-Configured By-Me Plus System
BUILDING AUTOMATION Organising the DCA for customising associations 6.8 Non-configured By-me Plus system Before importing the By-me Plus xml file, manually add all the Communication Objects on the KNX side using icon Once you have done this, you can import the By-me Plus system and complete the definition of associations . In this case the name of the communication object is not automatically prompted by the procedure but is left up to the installer, who can also set the direction of the messages and the type of data transported (1 .xxx will be valid for 1 .001, 1 .002, 1 .003, etc .) . -
Page 18: Assigning By-Me Data To Communication Objects
BUILDING AUTOMATION Organising the DCA for customising associations To complete configuration, you need to specify the KNX format that the By-me Plus KNX SECURE Router should adopt; the options are: • 2 levels • 3 levels . Next, the installer can set the KNX group address of the communication object they have just defined . The group address is inserted in the “By-me Addr”... -
Page 19: Copying The By-Me/Knx Gateway From Ets
BUILDING AUTOMATION Organising the DCA for customising associations 6.13 Copying the By-me/KNX gateway from ETS After defining the By-me/KNX Gateway, ETS can be used to duplicate the device inside the same KNX system and set its characteristics (see figure below) . 6.14 Completing the ETS configuration On completion of the By-me Plus KNX SECURE Router definition, tap the “Group Objects”... -
Page 20: Cloning A Room/Area
BUILDING AUTOMATION Organising the DCA for customising associations 6.15 Cloning a room/area This option allows you to clone a room (or area) already configured in another . In the following example, room 101 is copied to room 102 . You can now rename Room 101 – Copy in Room 102 and attribute the physical address of the Gateway . -
Page 21: Front-End Web
7.2 Accessing the front-end Web of router 01507 You can access the front-end Web of 01507 in two ways . You can access it directly from Windows Explorer or from a web browser . To access via web browser, you need to know the IP address or the MAC address and the HTTP port . -
Page 22: Information About The Device
BUILDING AUTOMATION Front-end Web 7.3 Information about the device After accessing the front-end Web, the Device Info chart is displayed, which contains general information about the current device parameters (addresses, name, software versions) . 7.4 KNX The specific KNX addresses are shown on this screen . Checking the settings is simple . Click on "ON" to activate the programming mode (which is the equivalent to pressing the programming button) . -
Page 23: Special Functions
7.5 Special functions 7.5.1 IP firmware update request Press the H button followed by button L on router 01507 (steps 1 and 2 in Table 8); then activate “request update” to enter boot mode . This displays ”Status: update authorised” . -
Page 24: Updating The Ip Firmware
“Abort” button the firmware updating procedure is cancelled and the device exits boot mode. 7.5.3 Resetting the device The reset button (H) activates the factory reset . The settings of device 01507 can be restored to the default manufacturer settings with the factory reset function . -
Page 25: Usage Examples
Usage examples 8. Usage examples Caution: Devices 01507 and 01548 cannot be configured on the same area/line since the former is TP and the other IP . 8.1 KNX system with supervision from Well-contact Suite and configuration with ETS 8.2 By-me system with 01507 TP/IP, configuration with interface 01548... - Page 26 BUILDING AUTOMATION Usage examples 8.3 By-me system with 01507 TP/IP, WCS supervision 8.4 Mixed system with 01507 TP/IP, WCS supervision...
- Page 27 BUILDING AUTOMATION Usage examples 8.5 Mixed system with 01507 TP/IP, configuration with 01540.1 8.6 Mixed system with 01507 TP/IP, supervision with 01540.1...
- Page 28 Viale Vicenza 14 36063 Marostica VI - Italy 01507IT 01 2309 www.vimar.com...
