- Page 1 Installer manual 01506 By-me KNX router BUILDING AUTOMATION WELL-CONTACT PLUS...
- Page 2 BUILDING AUTOMATION...
-
Page 3: Table Of Contents
BUILDING AUTOMATION Index 1. Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 .1 Front view of the device . -
Page 4: Product Description
By-me BUS . Router 01506 conforms to the KNX Secure requirements on the datapoints defined in the routing table . A datapoint on the KNX side can be defined for the heartbeat signal . 1.1 Front view of the device... -
Page 5: Commissioning
1.4 Secure Commissioning To launch the secure download of the configuration settings and/or individual address, you first need to add the individual Certificate of device 01506 to the ETS project . To add it, the ETS project must be password-protected . -
Page 6: Important Notes
BUILDING AUTOMATION Product description The individual Certificate of the device is always included with the KNX Secure product . For the product to be configured by the user, make sure you do not lose the device Certificate (see chapter 2 .6 Keeping the device Certificate) . 1.5 Important notes We recommend you attend standardised courses at a certified KNX training centre before installing, programming and commissioning a KNX system . -
Page 7: Keeping The Device Certificate
1.7 Summary of functions • The device Certificate guarantees that only authorised persons may access device 01506 . • When the ETS “Secure Commissioning” function is active, the configuration data are only downloaded in encrypted KNX Data Secure format . -
Page 8: The Knx Secure Protocol
BUILDING AUTOMATION The KNX Secure protocol 2. The KNX Secure protocol The device is used to activate the “KNX SECURE” data encryption protocol, entering the QR code or the digits in ETS and also creating a password associated to the project . - Page 9 BUILDING AUTOMATION The KNX Secure protocol 3. The device is displayed with the Secure part disabled . Transparent icon = Secure disabled Secure disabled 4. No password is associated with the project . 5. No certificate is associated to the project .
-
Page 10: Description Of Operation
(Group objects, Parameters, DCA) created in ETS for the specific device . It can be used normally without activating the Security function and in ETS projects in which the Security function is active . After connection to KNX IP, router 01506 works with its default settings . A valid individual address must be set . -
Page 11: Programming
BUILDING AUTOMATION Description of operation 3.3 Programming 3.3.1 Programming the individual address (and application) To download the individual address in a device, the Programming mode must be active . Press the programming button to activate or deactivate the program- ming mode . A red lit configuration LED (I) indicates the programming mode is active . When the download from ETS is activated and you press the programming button, the device stores the new individual address in the memory . -
Page 12: Network Backbone Configuration With Knx Secure Active
Backbone is Secure . Once the Backbone secure is activated, the configuration status of the various Secure devices will show as not up to date and so the ap- plication programmes will have to be downloaded again . 3.3.3 01548 interface configuration For the correct operation of the router 01506 configuration procedure, the physical addresses on the secondary line (TP) must be filtered . -
Page 13: Organising The Dca For Customising Associations
BUILDING AUTOMATION Organising the DCA for customising associations 4. Organising the DCA for customising associations To simplify the definition of the association between By-me group and KNX group, there is a tab called DCA available (as in the figure below) . 4.1 Controls •... -
Page 14: Tab
Organising the DCA for customising associations 4.4 Tab This is the section of ETS which contains all the default “Tab Group Object” and “Parameters” . A specific “DCA” tab is dedicate to “01506 Router By-me KNX” for the definition of the routing rules . -
Page 15: Non-Configured By-Me Plus System
BUILDING AUTOMATION Organising the DCA for customising associations 4.8 Non-configured By-me Plus system Before importing the By-me Plus xml file, manually add all the Communication Objects on the KNX side using icon Once you have done this, you can import the By-me Plus system and complete the definition of associations . In this case the name of the communication object is not automatically prompted by the procedure but is left up to the installer, who can also set the direction of the messages and the type of data transported (1 .xxx will be valid for 1 .001, 1 .002, 1 .003, etc .) . -
Page 16: Assigning By-Me Data To Communication Objects
BUILDING AUTOMATION Organising the DCA for customising associations To complete configuration, you need to specify the KNX format that the By-me Plus KNX SECURE Router should adopt; the options are: • 2 levels • 3 levels . Next, the installer can set the KNX group address of the communication object they have just defined . The group address is inserted in the “By-me Addr”... -
Page 17: Copying The By-Me/Knx Gateway From Ets
BUILDING AUTOMATION Organising the DCA for customising associations 4.13 Copying the By-me/KNX gateway from ETS After defining the By-me/KNX Gateway, ETS can be used to duplicate the device inside the same KNX system and set its characteristics (see figure below) . 4.14 Completing the ETS configuration On completion of the By-me Plus KNX SECURE Router definition, tap the “Group Objects”... -
Page 18: Cloning A Room/Area
BUILDING AUTOMATION Organising the DCA for customising associations 4.15 Cloning a room/area This option allows you to clone a room (or area) already configured in another . In the following example, room 101 is copied to room 102 . You can now rename Room 101 – Copy in Room 102 and attribute the physical address of the Gateway . -
Page 19: Usage Examples
BUILDING AUTOMATION Usage examples 5. Usage examples 5.1 Mixed system with 01506 TP/IP, configuration 5.2 Mixed system with 01506 TP/IP, supervision... - Page 20 Viale Vicenza 14 36063 Marostica VI - Italy 01506 IT 03 2401 www.vimar.com...
