Installer manual
01506
By-me KNX router
BUILDING AUTOMATION
WELL-CONTACT PLUS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WELL-CONTACT PLUS 01506 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vimar WELL-CONTACT PLUS 01506

Summary of Contents for Vimar WELL-CONTACT PLUS 01506

  • Page 1 Installer manual 01506 By-me KNX router BUILDING AUTOMATION WELL-CONTACT PLUS...
  • Page 2 BUILDING AUTOMATION...

  • Page 3: Table Of Contents

    BUILDING AUTOMATION Index 1. Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 .1 Front view of the device .

  • Page 4: Product Description

    BUILDING AUTOMATION System Requirements - Product description 1. Product description The By-me/KNX router enables communication between parts of a system comprising By-me devices, grouped together within an “island”, with a system comprising KNX devices . The messages are transmitted in both directions according to criteria which define the correspondence of the communication objects belonging to the specific domains .

  • Page 5: Commissioning

    BUILDING AUTOMATION Product description 1.3 Commissioning For commissioning with the default settings, keep the following in mind: • To activate the security function and Secure Commissioning you will need the device Certificate • Security function activation requires a specific minimum ETS version number Art.

  • Page 6: Important Notes

    BUILDING AUTOMATION Product description The individual Certificate of the device is always included with the KNX Secure product . For the product to be configured by the user, make sure you do not lose the device Certificate (see chapter 2 .6 Keeping the device Certificate) . 1.5 Important notes We recommend you attend standardised courses at a certified KNX training centre before installing, programming and commissioning a KNX system .

  • Page 7: Keeping The Device Certificate

    BUILDING AUTOMATION Product description - KNXnet/IP 1.6 Keeping the device Certificate The device Certificate is on the label affixed to the side of the casing . To avoid unauthorised access, the device Certificate should be removed from the device once it has been commissioned .

  • Page 8: The Knx Secure Protocol

    BUILDING AUTOMATION The KNX Secure protocol 2. The KNX Secure protocol The device is used to activate the “KNX SECURE” data encryption protocol, entering the QR code or the digits in ETS and also creating a password associated to the project .
  • Page 9 BUILDING AUTOMATION The KNX Secure protocol 3. The device is displayed with the Secure part disabled . Transparent icon = Secure disabled  Secure disabled 4. No password is associated with the project . 5. No certificate is associated to the project .

  • Page 10: Description Of Operation

    BUILDING AUTOMATION Description of operation 3. Description of operation In KNX network systems, router 01506 is used to transfer messages from KNX bus to By-me bus and vice-versa . The message exchange rules are totally defined by the installer using the dedicated folder (Group objects, Parameters, DCA) created in ETS for the specific device . It can be used normally without activating the Security function and in ETS projects in which the Security function is active .

  • Page 11: Programming

    BUILDING AUTOMATION Description of operation 3.3 Programming 3.3.1 Programming the individual address (and application) To download the individual address in a device, the Programming mode must be active . Press the programming button to activate or deactivate the program- ming mode . A red lit configuration LED (I) indicates the programming mode is active . When the download from ETS is activated and you press the programming button, the device stores the new individual address in the memory .

  • Page 12: Network Backbone Configuration With Knx Secure Active

    BUILDING AUTOMATION Description of operation 3.3.2 Network backbone configuration with KNX Secure active. If you want to use KNX Secure we recommend you set the Backbone IP to Secure (by default ETS sets it to “Automatic”) . To set the backbone to secure, display the Topology and edit the “Security”...

  • Page 13: Organising The Dca For Customising Associations

    BUILDING AUTOMATION Organising the DCA for customising associations 4. Organising the DCA for customising associations To simplify the definition of the association between By-me group and KNX group, there is a tab called DCA available (as in the figure below) . 4.1 Controls •...

  • Page 14: Tab

    BUILDING AUTOMATION Organising the DCA for customising associations 4.4 Tab This is the section of ETS which contains all the default “Tab Group Object” and “Parameters” . A specific “DCA” tab is dedicate to “01506 Router By-me KNX” for the definition of the routing rules .

  • Page 15: Non-Configured By-Me Plus System

    BUILDING AUTOMATION Organising the DCA for customising associations 4.8 Non-configured By-me Plus system Before importing the By-me Plus xml file, manually add all the Communication Objects on the KNX side using icon Once you have done this, you can import the By-me Plus system and complete the definition of associations . In this case the name of the communication object is not automatically prompted by the procedure but is left up to the installer, who can also set the direction of the messages and the type of data transported (1 .xxx will be valid for 1 .001, 1 .002, 1 .003, etc .) .

  • Page 16: Assigning By-Me Data To Communication Objects

    BUILDING AUTOMATION Organising the DCA for customising associations To complete configuration, you need to specify the KNX format that the By-me Plus KNX SECURE Router should adopt; the options are: • 2 levels • 3 levels . Next, the installer can set the KNX group address of the communication object they have just defined . The group address is inserted in the “By-me Addr”...

  • Page 17: Copying The By-Me/Knx Gateway From Ets

    BUILDING AUTOMATION Organising the DCA for customising associations 4.13 Copying the By-me/KNX gateway from ETS After defining the By-me/KNX Gateway, ETS can be used to duplicate the device inside the same KNX system and set its characteristics (see figure below) . 4.14 Completing the ETS configuration On completion of the By-me Plus KNX SECURE Router definition, tap the “Group Objects”...

  • Page 18: Cloning A Room/Area

    BUILDING AUTOMATION Organising the DCA for customising associations 4.15 Cloning a room/area This option allows you to clone a room (or area) already configured in another . In the following example, room 101 is copied to room 102 . You can now rename Room 101 – Copy in Room 102 and attribute the physical address of the Gateway .

  • Page 19: Usage Examples

    BUILDING AUTOMATION Usage examples 5. Usage examples 5.1 Mixed system with 01506 TP/IP, configuration 5.2 Mixed system with 01506 TP/IP, supervision...
  • Page 20 Viale Vicenza 14 36063 Marostica VI - Italy 01506 IT 01 2310 www.vimar.com...
