CF350 TELESCOPE
50 mm Telescope w/ AZ Table Top Mount
Optical Design
Magnification
Front Lens (clear aperture)
Focal Length
Standard Eyepieces
Finish
Tripod
SUN HAZARD — Never look directly at the sun
with this device.
Instruction Manual
Specifications
WARNING:
CHOKING HAZARD — Small parts.
Not for children under 3 years.
1
Achromatic Refractor
17.5 - 28x
0.965" 12.5mm & 20mm
Silver Carbon Fiber
Table Top
WARNING:
8
88-10052CF
50 mm
350 mm
+ +
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Explore One CF350
Summary of Contents for Explore One CF350
- Page 1 88-10052CF CF350 TELESCOPE 50 mm Telescope w/ AZ Table Top Mount Instruction Manual Specifications Optical Design Achromatic Refractor Magnification 17.5 - 28x Front Lens (clear aperture) 50 mm Focal Length 350 mm Standard Eyepieces 0.965” 12.5mm & 20mm Finish Silver Carbon Fiber...
- Page 2 SUN WARNING WARNING: NEVER ATTEMPT TO OBSERVE THE SUN WITH THIS DEVICE! OBSERVING THE SUN – EVEN FOR A MOMENT – WILL CAUSE INSTANT AND IRREVERSIBLE DAMAGE TO YOUR EYE OR EVEN BLINDNESS. Eye damage is often painless, so there is no warning to the observer that the damage has occurred until it is too late.
-
Page 3: Parts Overview
Parts Overview 1. 50mm Objective Lens 2. Table Top Alt-Azimuth Tripod 3. Optical Tube Assembly (OTA) with Dew Shield 4. Focus Wheel 5. Diagonal 6. 0.965” Eyepieces (12.5mm and 20mm) How To Set Up Assembly: Note: We recommend assembling your telescope for the first time in the daylight or in a lit room so that you can familiarize yourself with assembly steps and all components. -
Page 4: Using Your Telescope
Telescope Terms To Know: Diagonal: A mirror that deflects the ray of light 90 degrees. With a horizontal telescope tube, this device deflects the light upwards so that you can comfortably observe by looking downwards into the eyepiece. The image in a diagonal mirror appears upright, but rotated around its vertical axis (mirror image). - Page 5 scratch the lens. Ask your parents to help if your telescope is really dirty. If necessary, the cleaning cloth can be moistened with an optical glass cleaning fluid and the lens wiped clean using very little pressure. Do not use harsh detergents! Make sure your telescope is always protected against dust and dirt.
-
Page 6: Troubleshooting Guide
Orion Nebula: Right ascension: 05: 35.4 (hours: minutes) Declination: -05: 27 (degrees: minutes) Distance: Approximately 1,344 light years The Orion Nebula is a vast star-forming region located in the “sword” branching off of the famous Orion’s Belt. Also known as Messier 42, this diffuse nebula is bright enough to see with the unaided eye —... - Page 7 NOTES:...
- Page 8 © 2017 Explore Scientific , LLC. ® 1010 S 48th Street, Springdale, AR 72762 exploreone.com | 866.252.3811 All rights reserved. Made in China. CONFORMS TO THE SAFETY REQUIREMENTS OF ASTM F963...
