Assembly Steps
1. Find all parts and accessories. (16 parts)
2. Eyepiece assembly (2 set of 3 eyepiece lens set,
reticle adjusting ring, eyepiece assembly locking
cap)
3. OTA assembly (2 sets of 2 objective lens set,
lens separation ring, assemble to OTA slot.)
4. Finishing. (1/4 nut (screw), assemble eyepiece
set on to the back of the OTA, close the two piece
of the OTA, assemble dew shield, assemble barrel
locking cap, bottom locking cap)
Objects to view
Milky Way
Star Clouds
Moon
Pleiades
Star Cluster
Troubleshooting Guide:
Problem
Solution
Remove dust protection cap and sun-
No picture
shield from the objective opening.
Blurred picture
Adjust focus using focus barrel.
No focus possible
Wait for temperature to balance out.
Never observe through a glass
Bad quality
surface such as a window.
© 2018 EXPLORE ONE
1010 S 48th Street, Springdale, AR 72762
exploreone.com | 866.252.3811
All rights reserved. Made in China.
CONFORMS TO THE SAFETY
REQUIREMENTS OF ASTM F963
50MM Refractor
STEM Telescope Kit
Instruction Manual
WARNING:
SUN HAZARD — Never look directly at the sun
with this device.
WARNING:
CHOKING HAZARD — Small parts.
The lens contains lead that may be harmful.
Wash hands after touching.
Not for children under 3 years.
