CF400 TELESCOPE
70 mm Telescope w/ Pan Handle AZ Mount
Optical Design
Magnification
Front Lens (clear aperture)
Focal Length
Standard Eyepieces
Finish
Tripod
WARNING:
SUN HAZARD — Never look directly at the sun
with this device.
Instruction Manual
Specifications
WARNING:
CHOKING HAZARD — Small parts.
Not for children under 3 years.
1
Achromatic Refractor
20 - 67x
400 mm
1.25" K6 mm & K20 mm
Blue Carbon Fiber
Alt-azimuth Tripod
1
X
CR2032
3V
INCLUDED
WARNING:
Contains button or coin cell battery.
Hazardous if swallowed — see instructions.
10
+ +
88-10072CF
70 mm
Advertisement
Table of Contents
Related Manuals for Explore One CF400
Summary of Contents for Explore One CF400
- Page 1 88-10072CF CF400 TELESCOPE 70 mm Telescope w/ Pan Handle AZ Mount Instruction Manual Specifications Optical Design Achromatic Refractor Magnification 20 - 67x Front Lens (clear aperture) 70 mm Focal Length 400 mm Standard Eyepieces 1.25” K6 mm & K20 mm...
- Page 2 SUN WARNING WARNING: NEVER ATTEMPT TO OBSERVE THE SUN WITH THIS DEVICE! OBSERVING THE SUN – EVEN FOR A MOMENT – WILL CAUSE INSTANT AND IRREVERSIBLE DAMAGE TO YOUR EYE OR EVEN BLINDNESS. Eye damage is often painless, so there is no warning to the observer that the damage has occurred until it is too late.
- Page 3 Parts Overview 1. 70mm Objective Lens 2. Pan- Tilt Alt-Azimuth Mount 3. Tripod with Accessory Tray 4. Optical Tube Assembly with Dew Shield 5. Focus Wheel 6. 45⁰ Erecting Prism Diagonal 7. 1.25” Eyepieces (K6 mm & K20 mm) 8. Red Dot Viewfinder...
- Page 4 How To Set Up Assembly: Note: We recommend assembling your telescope for the first time in the daylight or in a lit room so that you can familiarize yourself with assembly steps and all components. 1. Open the tripod until the tripod spreaders are fully extended. Put the accessory tray in place and turn it clockwise until stable.
- Page 5 magnification of 30x, then an object viewed through the telescope will appear 30 times larger than it would with the naked eye. To calculate the magnification of your telescope setup, divide the focal length of the telescope tube by the focal length of the eyepiece. NOTE: The magnifying power of a telescope is determined by dividing the focal length of the telescope by the focal length of the eyepiece.
- Page 6 It is important to remember that the rotation of the Earth means objects will move out of your eyepiece fairly quickly. For a closer look at an object, you can insert the K6 mm eyepiece. The magnification will increase from 20x to 67x. Cleaning: Your telescope is a precision optical device and keeping the optics free of dust and dirt is crucial for optimal performance.
- Page 7 Orion Nebula: Right ascension: 05: 35.4 (hours: minutes) Declination: -05: 27 (degrees: minutes) Distance: Approximately 1,344 light years The Orion Nebula is a vast star-forming region located in the “sword” branching off of the famous Orion’s Belt. Also known as Messier 42, this diffuse nebula is bright enough to see with the unaided eye —...
- Page 8 © 2017 Explore Scientific , LLC. ® 1010 S 48th Street, Springdale, AR 72762 exploreone.com | 866.252.3811 All rights reserved. Made in China. CONFORMS TO THE SAFETY REQUIREMENTS OF ASTM F963 Colors and styles may vary.
