CF400SP TELESCOPE
70 mm Telescope Pan Handle AZ Mount
WARNING:
SUN HAZARD — Never look directly at the sun
with this device.
WARNING:
CHOKING HAZARD — Small parts.
Not for children under 3 years.
w/Smartphone Adapter
Instruction Manual
CR2032
3V
Contains button or coin cell battery.
Hazardous if swallowed — see instructions.
1
X
The lens contains lead that may be harmful.
INCLUDED
Wash hands after touching.
WARNING:
This product can expose you to chemicals including lead,
which is known to the State of California to cause cancer
and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
1
88-10073CF
WARNING:
WARNING:
10+
EN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Explore One CF400SP
Summary of Contents for Explore One CF400SP
- Page 1 88-10073CF CF400SP TELESCOPE 70 mm Telescope Pan Handle AZ Mount w/Smartphone Adapter Instruction Manual WARNING: WARNING: SUN HAZARD — Never look directly at the sun The lens contains lead that may be harmful. CR2032 INCLUDED with this device. Wash hands after touching.
-
Page 2: Important Safety Instructions
Customer Service: Call 1-866-252-3811 READ AND FOLLOW THE INSTRUCTIONS BEFORE USE. IMPORTANT SAFETY INSTRUCTIONS KEEP THESE INSTRUCTIONS FOR LATER USE. • SUN WARNING: WARNING: NEVER ATTEMPT TO OBSERVE THE SUN WITH THIS DEVICE! OBSERVING THE SUN – EVEN FOR A MOMENT – WILL CAUSE INSTANT AND IRREVERSIBLE DAMAGE TO YOUR EYE OR EVEN BLINDNESS. -
Page 3: Parts Overview
Parts Overview 1. 70mm Objective Lens 2. Pan- Tilt Alt-Azimuth Mount 3. Tripod with Accessory Tray 4. Optical Tube Assembly with Dew Shield 5. Focus Wheel 6. 45⁰ Erecting Prism Diagonal 7. 1.25” Eyepieces (K6 mm & K20 mm) 8. Red Dot Viewfinder 9. - Page 4 How To Set Up Assembly: Note: We recommend assembling your telescope for the first time in the daylight or in a lit room so that you can familiarize yourself with assembly steps and all components. 1. Open the tripod until the tripod spreaders are fully extended. Put the accessory tray in place and turn it clockwise until stable.
- Page 5 NOTE: The magnifying power of a telescope is determined by dividing the focal length of the telescope by the focal length of the eyepiece. This means that as the focal length of your eyepiece increases, the magnifying power decreases. Using/Aligning the Red Dot Viewfinder: The viewfinder is powered by a CR-2032 battery that is included.
-
Page 6: Troubleshooting Guide
Cleaning: Your telescope is a precision optical device and keeping the optics free of dust and dirt is crucial for optimal performance. To clean the lenses (objective and eyepiece) use only a photo-grade soft brush or a lint-free cloth, like a microfiber cloth. Do not press down too hard while cleaning, as this might scratch the lens. - Page 7 Using the Smartphone Adapter: SUPERVISION BY ADULTS Read and follow the instructions, safety rules and first aid information The Smartphone Adapter will allow you to connect almost any “smart” device to a 1.25” eyepiece. To use the adapter, place it directly onto the selected eyepiece and secure it by tightening the setscrew until snug.
-
Page 8: Observing Tips
Observing Tips: Star hopping Star hopping is a technique used by amateur astronomers to navigate the night sky. By using easily recognizable constellations and asterisms as a guide, an observer can locate stars and other objects. For example, Polaris, which is Merak Dubhe commonly referred to as The North... - Page 9 Pleiades Star Cluster(M45): Right ascension: 03: 47.0 (hours: minutes) Declination: +24: 07 (degrees: minutes) Distance: Approximately 444 light years The Pleiades Star Cluster is a group of brilliant blue stars located in the Taurus Constellation. Also known as Messier 45 or “Seven Sisters”, this open star cluster consists of more than 1,000 confirmed stars, although an average of only six are visible to the unaided eye.
- Page 10 Types Of Telescopes: Focuser Light Focuser Primary Mirror Secondary Mirror (Objective) Light Light Focuser Primary Mirror Secondary Mirror Reflector (Objective) Light A reflector telescope uses mirrors to gather and focus light. Light enters the telescope through its open front end and Light travels to the concave primary mirror at the back.
- Page 11 Telescope Terms to Know: Focal Length Objective Lens Eyepiece Eyepiece (mm) Focuser Aperture (mm) Diagonal Focal Point Focal Length Telescope (mm) Focal Length Eyepiece Eyepiece (mm) Focuser Focal Point Aperture Primary Mirror Secondary (mm) (Objective) Mirror Focal Length Telescope (mm) Aperture: This figure, which is usually expressed in millimeters, is the diameter of a telescope’s light-gathering surface (objective lens in a refractor or primary mirror in a reflector).
- Page 12 Aperture 102mm Eyepiece Focal Length 20mm Telescope Focal Length Magnification: 1000mm The magnification corresponds to the difference between observation with the naked eye and observation through a magnifying device like a telescope. If a telescope configuration has a magnification of 30x, then an object viewed through the telescope will appear 30 times larger than it would with the naked eye.
- Page 13 Eyepiece Lens Short Eye Relief Distance Long Eye Relief Distance Exit Pupil (mm) Eyepiece Lens Eyepiece Lens Eyepiece Lens Eye Relief Eye relief is all about a comfortable viewing experience because it is the distance at which you need to position your eye from the eyepiece’s outermost surface to enjoy the full field of view.
- Page 14 NOTES...
- Page 15 NOTES...
- Page 16 ©2020 Explore Scientific, LLC., Explore One 1010 S 48th Street, Springdale, AR 72762 explorescientificusa.com | 866.252.3811 All rights reserved. Made in China. CONTENTS AND COLORS MAY VARY CONFORMS TO THE SAFETY REQUIREMENTS OF ASTM F963 V062020...
