Photon 400 Installation & Quick Start Guide
To install the Photon 400 and get started:
1. Connect power.
2. Connect the Photon 400 to the network.
3. Access the Photon 400.
4. Change the management configuration.
5. Access the Stellar Cyber UI.

Connecting Power

To connect power to the appliance:
1. Connect the included power cables to the power source.
2. Connect the power cables to the rear of the Photon 400.
3. Press the power button on the front of the Photon 400.

Connecting to the Network

To connect the Photon 400 to the network:
1. Connect the Management port to a network accessible by the DP.
2. Use the monitor ports to connect to data sources (mirror ports or taps). There are four 1
GbE monitor ports (eth2...eth5, from left to right) and 2 10GbE monitor ports (eth6...eth7,
left to right).
 Stellar Cyber, 2022. All rights reserved.
October, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Photon 400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stellar Cyber Photon 400

  • Page 1 To connect power to the appliance: 1. Connect the included power cables to the power source. 2. Connect the power cables to the rear of the Photon 400. 3. Press the power button on the front of the Photon 400.
  • Page 2 Photon 400 Installation & Quick Start Accessing the Photon 400 You can access the appliance using a VGA monitor and USB keyboard, using SSH to the Management port, or using a virtual console over the iDRAC port. The ports for these connections are all at the rear of the appliance, as illustrated above.
  • Page 3 7. Set the host name, which is displayed in Stellar Cyber and should be unique for each sensor: set hostname <new hostname> 8. If necessary, set the proxy HTTP server: set proxy http://<proxy IP address:port>...
